Prepare for Installation

Before you begin installation, it is important to review the installation instructions and check the hardware
to confirm that you have all of the required equipment.
Securing the Cable with Tape
Clearing the Mounting Holes (AS 12RD2KW)
Clearing the Mounting Holes (AS 21RD4KW)
Installation
4 Mounting Holes
4 Mounting Holes
Supplies: In addition to the hardware included in this
box, you will also need vinyl tape, a powered hand drill
and various drill bits, various hand tools, safety glasses,
a dust mask, and sealant.
1.
Unpack the box and confirm the contents
with the illustration shown on the next
page.
2.
Coil the cable and place the cable on top of
the scanner. Secure the cable with tape.
3.
Invert the scanner and make sure the four
mounting holes are clear to accept bolts.
