Manual Thinking MT-VP L180 Assembly Instructions Manual page 6

MT-VP L180
Assembly
EN
Montaje
ES
Muntatge
CA
!
Place wheels with brake on the back.
Coloca las ruedas con freno por detrás.
Col . loca les rodes amb fre per darrere.
MT-WL100-X
B
MT-WL100
6
2x (A)
MT-WL100-X
Wheel with brake.
Rueda con freno.
Roda amb fre.
Dept.
A
B
MT-WL100
2x (B)
MT-WL100
Wheel without brake.
Rueda sin freno.
Roda sense fre.
Technical reference Created by
Gerrit Jan Veldman
Document type
Title
Rueda 100 M10 breaks
A
Approved by
13/01/2020
Dept. Technical reference
Document status
DWG No.
Rev.
!
Use the indicated holes only.
Usa los agujeros indicados.
Fes servir els forats indicats.
4x
M6x50
Dept. Technical ref
Created by
Gerrit Jan Veldman 13/01/202
Document type
Title
Rueda 100 M10
Date of issue Sheet
1/1
