E3845 (Dual Core / Quad Core) CPU,
2 x LAN / LVDS / Touch Screen / USB / COM
Intel Bay Trail-I E3825 / E3845 CPU, 2 x Intel GbE LAN,
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
NO. 2I386EW
Release date: Feb. 26 2018
2I386EW
Intel Bay Trail-I E3825 /
DDR3L SODIMM 1333 MT/s,
All-In-One eIO extension SBC
2 x mini PCIe, VGA, Audio, SATA, USB, COM,
LVDS, Touch Screen, eIO, Wide Range DC-IN

Advertisement

Table of Contents
loading

Summary of Contents for Tera 2I386EW

  • Page 1 2 x mini PCIe, VGA, Audio, SATA, USB, COM, LVDS, Touch Screen, eIO, Wide Range DC-IN CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS NO. 2I386EW Release date: Feb. 26 2018...

  • Page 2: Table Of Contents

    CHAPTER 2 HARDWARE INSTALLATION ..............2-1 UNPACKING PRECAUTION ..................2-2 UNPACKING CHECKUP ....................2-3 DIMENSION-2I386EW ....................2-4 LAYOUT-2I386EW-CONNECTOR AND JUMPER ............2-4-1 LAYOUT-2I386EW-CONNECTOR AND JUMPER BOTTOM ........2-4-2 LAYOUT-2I386EW-FUNCTION MAP ................ 2-4-3 LAYOUT-2I386EW-FUNCTION MAP BOTTOM ............2-5 DIAGRAM-2I386EW ....................2-5-1 DIAGRAM-2I386EW ....................
  • Page 3 3-9 LAN INTERFACE......................3-10 I BUS INTERFACE ......................3-11 DC POWER INPUT ......................3-12 PANEI INVERTER POWER INTERFACE ..............3-13 DC +12V / +5 VOLTAGE POWER OUTPUT ..............3-14 TOUCH SCREEN (2x5 PIN 2.0MM WAFER) USB INTERFACE ........3-15 USB INTERFACE ......................3-16 LVDS1: LVDS INTERFACE (2x15 PIN 1.25MM WAFER) ..........
  • Page 4 5-6 MBI INSTALL INTEL MBI DRIVER (FOR WIN 8/8.1 ONLY) ......... 5-7 TXE INSTALL INTEL TXE DRIVER ................5-7-1 TXE INSTALL FOR WIN8/WIN8.1 ................5-7-2 TXE INSTALL FOR WIN7 ..................5-8 HOW TO UPDATE INSYDE BIOS ................APPENDIX A:POWER CONSUMPTION TEST ..............APPENDIX B:RESOLUTION LIST ..................
  • Page 5 Copyright This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.

  • Page 6: Warning

    Warning ! Battery Batteries on board are consumables. The life time of them are not guaranteed. 2. Fanless solution with HDD The specifi cation & limitation of HDD should be considered carefully when the fanless solution is implemented. We will not give further notifi cation in case of changes of product information and manual.

  • Page 7: Hardware Notice Guide

    Hardware Notice Guide 1. Before linking power supply with the motherboard, please attach DC-in adapter to the motherboard fi rst. Then plug the adapter power to AC outlet. Always shut down the computer normally before you move the system unit or remove the power supply from the motherboard.
  • Page 8 Photo 1 Insert Unplug...

  • Page 9: Chapter 1 General Information

    fl exible expansion. Especially 2I386EW with an eIO ( 1 x PCIe +USB ) expansion function that offer the ideal platforms for high performance applications in Digital Signage, medical devices, POS/Kiosk, gaming machines, automation, military &...

  • Page 10: Major Feature

    1-1 Major Feature Intel Bay Trail-I E3845 1.91GHz SOC (Quad core), E3825 1.33GHz (Dual Core) Intel Bay Trail-I Integrated Graphics chipset, E3845 542 MHz / E3825 533 MHz render clock frequency DDR3L SODIMM Socket x 1, up to 8GB Support 2 x 10 / 100 / 1000 Mbps Intel LAN ports Support 4 x COM ports and 1 USB 3.0, 3 x USB 2.0 Support extended 2 x Mini PCIe card (full size) and one eIO with 1 USB and 1 PCIe x 1 siganl.

  • Page 11: Specification

    1-2 Specifi cation SOC: Intel Bay Trail-I E3845 1.91GHz / E3825 1.33 GHz (Quad / Dual Core) Memory: DDR3L SODIMM Socket x 1, up to 8GB Graphics: Intel Bay Trail-I / Bay Trail-D Integrated Graphics chipset, E3845 542 MHz / E3825 533MHz render clock frequency SATA: One SATA connector with independent DMA operation supported, signal shared with mSATA LAN: 2 x INTEL 210-IT PCIe LAN of 10 / 100 / 1000 Mbps...

  • Page 12: Installing The So-Dimm

    1-3 Installing the SO-DIMM 1. Align the SO-DIMM with the connector at a 45 degree angle. 2. Press the SO-DIMM into the connector until you hear a click.
  • Page 13 Notices: 1.The connectors are designed to ensure the correct insertion. If you feel resistance, check t h e connectors & golden fi nger direction, and realign the card. 2. Make sure the retaining clips (on two sides of the slot) lock onto the notches of the card fi...

  • Page 14: Removing The So-Dimm

    1-3-1-1 Removing the SO-DIMM 1. Release the SO-DIMM by pulling outward the two retaining clips and the SO-DIMM pops up slightly. 2. Lift the SO-DIMM out of its connector carefully.

  • Page 15: Directions For Installing The Mini Card

    1-4 Directions for installing the Mini Card 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.

  • Page 16: Packing List

    1-5 Packing List Option Option Option Material Code Description Detail Specifi cation Quantity 7G1901-1710001-0 MB-2I386EW-I4-001 LF,2I386EW-I4,Rev.:001 6G6003-7330-0100 Power Cable LF,L=9cm,2.0 1*4/DC JK LF,L=25cm,1*4/2.0 to 180° SATA 6G6003-1009-0100 SATA Power Cable 1(Option) 6G6001-2203-0100 SATA DATA Cable (Red) LF,L=25cm 1(Option) LF,support Intel Baytrail 6G8006-2349-0100 LEX Product Driver DVD Driver,Windows 7/8.1 32/64...

  • Page 17: Chapter 2 Hardware Installation

    Chapter-2 Hardware Installation 2-1 Unpacking Precaution This chapter provides the information how to install the hardware of 2I386EW. Please follow section 1-5, 2-1 and 2-2 to check the delivery package and unpack carefully. Please follow the jumper setting procedure. NOTE! 1.

  • Page 18: Unpacking Checkup

    2-2 Unpacking checkup First of all, please follow all necessary steps of section 2-1 to protect 2I386EW from electricity discharge. With reference to section 1-5 please check the delivery package again with following steps: 1. Unpack the 2I386EW board and keep all packing material, manual and driver disc etc, do not dispose ! 2.

  • Page 19: Dimension-2I386Ew

    2-3 Dimension-2I386EW...

  • Page 20: Layout-2I386Ew-Connector And Jumper

    2-4 Layout-2I386EW-Connector and Jumper JVL1...

  • Page 21: Layout-2I386Ew-Connector And Jumper Bottom

    2-4-1 Layout-2I386EW-Connector and Jumper Bottom...

  • Page 22: Layout-2I386Ew-Function Map

    2-4-2 Layout-2I386EW-Function MAP...

  • Page 23: Layout-2I386Ew-Function Map Bottom

    2-4-3 Layout-2I386EW-Function MAP Bottom...

  • Page 24: Diagram-2I386Ew

    2-5 Diagram- 2I386EW JSB1 CFP1 CIO1 CBT1 CALR1 MPCE2 CU11 SODIMM1 LVDS1 JVL1 MPCE1 CPO1 CPP1 JVC1 CPI1 EIO1...

  • Page 25: Diagram-2I386Ew

    2-5-1 Diagram- 2I386EW SATA1...

  • Page 26: Function Map-2I386Ew

    2-5-2 Function MAP- 2I386EW COM4 COM2 CMOS Clear Jumper Audio Amplifi er 4DI/4DO COM3 Line-IN, LAN2 Line-OUT, MIC-IN Front Panel LAN1 mSATA/ USB/ SMBus USB2.0 DDR3L- DODIM LVDS 24 / 18bit PCIE / Pannel Power USB/ Select Jumper SMBus 5V / 12V OUT...

  • Page 27: List Of Jumpers

    2-6 List of Jumpers JSB1: CMOS DATA clear JVL1: LCD panel power select JVC1: COM1 PIN9 RI / +12V / +5V Selec 2-7 Jumper Setting Description A jumper is ON as a closed circuit with a plastic cap covering two pins. A jumper is OFF as an open circuit without the plastic cap.

  • Page 28: Jsb1: Cmos Data Clear

    2-8 JSB1: CMOS DATA Clear A battery must be used to retain the motherboard confi guration in CMOS RAM. Close Pin1 and pin 2 of JSB1 to store the CMOS data. To clear the CMOS, follow the procedures below: 1. Turn off the system and unplug the AC power 2.

  • Page 29: Jvl1: Lcd Panel Power Select

    2-9 JVL1: LCD panel power select (OEM) JVL1 DESCRIPION *2-3 +3.3V Note: Attention! Check Panel Power in spec JVL1 *+3.3V 2-10 JVC1: COM1 PIN9 RI / +12V / +5V Selec JVC1 DESCRIPION *1-2 COM port pin9 use RI signal COM port pin9 use +5V voltage COM port pin9 use +12V voltage JVC1 1 3 5...

  • Page 30: Chapter 3 Connection

    Chapter-3 Connection This chapter provides all necessary information of the peripheral's connections, switches and indicators. Always power off the board before you install the peripherals. 3-1 List of Connectors CBT1: CMOS battery 1x2 pin (1.25mm) wafer CA3: Line-out / Line-in / Mic-in 2x5 pin (2.0mm) Wafer (OEM) CALR1: Amplifi...

  • Page 31: Cmos Battery Connector

    MPCE1 : Full size mini card port 1 sockets 52pin MPCE2 : Full size mini card port 2 sockets 52pin EIO1: eIO port 2x20 pin (1.27mm) Wafer SODIMM1: DDR3L-SODIMM sockets 204pin 3-2 CMOS battery connector CBT1: CMOS Battery 1x2pin (1.25mm) Wafer PIN NO.

  • Page 32: Audio Interface

    3-3 Audio interface (OEM) CA3: Line-out / Line-in / Mic-in 2x5 pin (2.0mm) Wafer PIN NO. DESCRIPTION PIN NO. DESCRIPTION Line-out-R MIC-IN Line-in-R Line-in-L Line-out-L MIC-IN pin1 3-4 Audio Amplifi er (OEM) CALR1: Amplifi er Line-out Right / Left channel 1x4pin (1.25mm) wafer PIN NO.

  • Page 33: Com Interface

    3-5 COM interface CC1: COM1 DB9 Connector (RS232 Mode) PIN NO. Description PIN NO. Description RI / Voltage Note: Pin 9 RI and Voltage setting only for COM 1 ports, JVC1 for COM1. Default is RI signal. CC1: COM1 DB9 Connector (RS485 Mode) PIN NO.
  • Page 34 CC2: COM2 wafer connector (2x5pin 2.0mm) (RS232 Mode) PIN NO. Description PIN NO. Description RI/Voltage Note: The pin9 RI can be modify to Power to supply device. The power voltage can be set +12V or +5V. The RI change Voltage function is OEM need change BOM. Default is RI signal. CC2: COM2 wafer connector (2x5pin 2.0mm) (RS485 Mode) PIN NO.
  • Page 35 CC3 / CC4: COM3 / COM4 2x5pin (2.0mm) wafer (RS232 Mode) PIN NO. Description PIN NO. Description pin1...

  • Page 36: Front Panel Pin Header

    3-6 Front Panel Pin Header CFP1: Front Panel connector 2x5pin (2.0mm) wafer PIN NO. Description PIN NO. Description Power button pin Power button GND Reset pin Reset GND Power LED Power LED+ HDD LED- HDD LED+ LAN LED- LAN LED+ CFP1 pin1 3-7 VGA Display interface...

  • Page 37: Digital Input/Output/Watch Dog Time

    3-8 Digital Input / Output / Watch Dog Time CIO1: DIO 0—3 2x5pin (2.0mm) wafer PIN NO. Description PIN NO. Description DI-0 DO-3 DI-1 DO-2 DI-2 DO-1 DI-3 DO-0 Note: 1. DI pin default pull up 10KΩ to +5V 2. If use need isolate circuit to control external device 3.

  • Page 38: Io Device: F75111 Under Dos

    3-8-1 IO Device: F75111 under DOS The Sample code source you can download from http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_DOS Source fi le: F75111_Dos_Src.rar Binary fi le: F75111_Dos_Bin.rar USERNAME & PASSWORD: sf How to use this Demo Application 1.Boot Ms-Dos Operating System 2.execute "75WDT.EXE" binary fi le 3.Input 1 to Enable WDT timer or input 0 to Disable it.
  • Page 39 Introduction How to use this Demo Application WriteI2CByte(I2CADDR, CONFIG, 0x03);//Set Watch Dog Timer function WriteI2CByte(I2CADDR, WDT_TIMER, timer);//Set Watch Dog Timer range from 0-255. WriteI2CByte(I2CADDR, WDT_TIMER_CTL, 0x73);//Enable Watch Dog Timer in second and pulse mode How to use this Demo Application WriteI2CByte(I2CADDR, WDT_TIMER_CTL, 0x00);...

  • Page 40: Io Device: F75111 Under Windows

    3-8-2 IO Device: F75111 under Windows The Sample code source you can download from Source fi le: F75111_DIO_Src_v2.8W(32bit).zip http://tprd.info/lexwiki/index.php/IO_Device:F75111 Binary fi le: F75111_DIO_Bin_v2.8W(32bit).zip USERNAME & PASSWORD: sf We do the demo test with a test tool which DIx connect to DOx with Relay.
  • Page 41 How to use this Demo Application one F75111 two F75111 Attention Please: You must be install vcredist_x86.exe when fi rst time you run the F75111_DIO.exe DEMO AP,The vcredist_x86.exe include all required DLL fi le. WARNING: win7 system architecture, use the system administrator to open DIO utility 1.
  • Page 42 p.s. f75111 send "F75111_SetWDTEnable(BYTE byteTimer)" including a parameter "timer", if there's no disable signal (F75111_SetWDTDisable()) to stop it before timer countdown to 0, System will reboot. if there's disable signal received, resent Enable WDT signal, for a loop to prevent from reboot F75111 Layout Picture Introduction Initial Internal F75111 port address (0x9c)
  • Page 43 Enable/Disable WDT Enable : F75111_SetWDTEnable (BYTE byteTimer) Disable: F75111_SetWDTDisable () PULSE mode Sample to setting GP33, 32, 31, 30 output 1mS low pulse signal. this->Write_Byte(F75111_INTERNAL_ADDR, GPIO3X_PULSE_CONTROL, 0x00); //This is setting low pulse output this->Write_Byte(F75111_INTERNAL_ADDR, GPIO3X_PULSE_WIDTH_CONTROL, 0x01); //This selects the pulse width to 1mS this->Write_Byte(F75111_INTERNAL_ADDR, GPIO3X_CONTROL_MODE, 0x0F);...
  • Page 44 Get Input value BYTE F75111::InterDigitalInput() BYTE byteGPIO1X = 0; BYTE byteGPIO3X = 0; BYTE byteData = 0; this->Read_Byte(F75111_INTERNAL_ADDR,GPIO1X_INPUT_DATA,&byteGPIO1X) ; // Get value from GPIO1X this->Read_Byte(F75111_INTERNAL_ADDR,GPIO3X_INPUT_DATA,&byteGPIO3X) ; // Get value from GPIO3X byteGPIO1X = byteGPIO1X & 0xF0; // Mask unuseful value byteGPIO3X = byteGPIO3X &...
  • Page 45 //-------------------------------------------------------------------------------------------------------- #defi ne GPIO1X_INPUT_DATA 0x12 // GPIO1X Input #defi ne GPIO3X_INPUT_DATA 0x42 // GPIO3X Input //-------------------------------------------------------------------------------------------------------- #defi ne GPIO2X_OUTPUT_DATA 0x21 // GPIO2X Output //-------------------------------------------------------------------------------------------------------- #defi ne GPIO1X_PULSE_CONTROL 0x13 // GPIO1x Level/Pulse Control Register // 0:Level Mode // 1:Pulse Mode #defi ne GPIO1X_PULSE_WIDTH_CONTROL 0x14 // GPIO1x Pulse Width Control Register #defi...

  • Page 46: Io Device: F75111 Vb6 Under Windows

    3-8-3 IO Device: F75111 VB6 under Windows The Sample code source you can download from Source fi le: 75111_VB_v1.2.rar http://tprd.info/lexwiki/index.php/IO_Device:F75111_VB6 Binary fi le: 75111_VB_Src1.2.rar USERNAME & PASSWORD: sf How to use this Demo Application ● A Function - Choose your motherboard model ●...
  • Page 47 F75111 Layout Picture SDK Function Introduction Function EnableWDT Function EnableWDT(timer As Integer) Call WriteI2CByte(&H3, &H3) Call WriteI2CByte(&H37, timer) Call WriteI2CByte(&H36, &H73) End Function Function DisableWDT Function DisableWDT() Call WriteI2CByte(&H36, &H0) End Function...
  • Page 48 Function SetDOValue Function SetDOValue(dovalue As Integer) Dim Data As Integer Dim Value As Integer Data = 0 Value = dovalue If (Value And &H1) <> 0 Then Data = Data + &H1 End If If (Value And &H2) <> 0 Then Data = Data + &H2 End If If (Value And &H4) <>...
  • Page 49 Function CheckDIValue Function CheckDIValue() Dim GPIO1X As Integer Dim GPIO3X As Integer Dim DI1Xhex As String Dim DI3Xhex As String Dim Data As Long Data = 0 Call ReadI2CByte(&H12, GPIO1X) Call ReadI2CByte(&H42, GPIO3X) GPIO1X = GPIO1X And &HF0 GPIO3X = GPIO3X And &HF If (GPIO1X And &H10) <>...

  • Page 50: Io Device: F75111 Under Linux

    3-8-4 IO Device: F75111 under linux The Sample code source you can download from Source fi le: F75111v2.4L_SRC.tar.gz http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_linux Binary fi le: F75111v2.4L_BIN.tar.gz USERNAME & PASSWORD: sf How to compile source code 1. Compile source code with Code::Blocks download and install the Code::Block with command "apt-get install codeblocks" Open an exist project(F75111.cbp) in Code::Blocks, click the compile button ( add an option 'pkg-config --libs gtk+-2.0 gthread-2.0' in "Project->Build Option- >Linker Setting->Other linker option")
  • Page 51 1. Press the "Start" button to test DIO function 2. Press the "Enable" button to test WDT function 3. Press the "Disable" button to disable WDT 4. Check the "Enable Loop" box and press "Enable" to do WDT loop test 5.
  • Page 52 Introduction IO function In fi le SMBus.c void SMBusIoWrite(BYTE byteOffset,BYTE byteData) outb( byteData , m_SMBusMapIoAddr + byteOffset); BYTE SMBusIoRead(BYTE byteOffset) DWORD dwAddrVal; dwAddrVal = inb(m_SMBusMapIoAddr + byteOffset); return (BYTE)(dwAddrVal & 0x0FF); Initial internal F75111 void F75111::InitInternalF75111() this->Write_Byte(F75111_INTERNAL_ADDR,GPIO1X_CONTROL_MODE ,0x00); //set GPIO1X to Input function this->Write_Byte(F75111_INTERNAL_ADDR,GPIO3X_CONTROL_MODE ,0x00);...
  • Page 53 Get Input value BYTE F75111::InterDigitalInput() BYTE byteGPIO1X = 0; BYTE byteGPIO3X = 0; BYTE byteData = 0; this->Read_Byte(F75111_INTERNAL_ADDR,GPIO1X_INPUT_DATA,&byteGPIO1X) ; // Get value from GPIO1X this->Read_Byte(F75111_INTERNAL_ADDR,GPIO3X_INPUT_DATA,&byteGPIO3X) ; // Get value from GPIO3X byteGPIO1X = byteGPIO1X & 0xF0; // Mask unuseful value byteGPIO3X = byteGPIO3X &...
  • Page 54 //-------------------------------------------------------------------------------------------------------- #defi ne F75111_INTERNAL_ADDR 0x9C OnBoard F75111 Chipset #defi ne F75111_EXTERNAL_ADDR 0x6E External F75111 Chipset //-------------------------------------------------------------------------------------------------------- #defi ne F75111_CONFIGURATION 0x03 Confi gure GPIO13 to WDT2 Function //-------------------------------------------------------------------------------------------------------- #defi ne GPIO1X_CONTROL_MODE 0x10 Select Output Mode or Input Mode #defi ne GPIO2X_CONTROL_MODE 0x20 Select GPIO2X Output Mode or Input Mode #defi...

  • Page 55: Lan Interface

    3-9 LAN Interface CL1 / CL2: RJ45 LAN port Giga / 100Mb (RJ45 Jack) PIN NO. Description PIN NO. Description TR0-/TX+ TR2-/NC TR0+/TX- TR2+/RX- TR1-/RX+ TR3-/NC TR1+/NC TR3+/NC CL11 / CL21: LAN port Giga / 100Mb 2x5pin (2.0mm) wafer (option) PIN NO.

  • Page 56: Bus Interface

    3-10 I C Bus Interface CO1: I C Bus 1x4pin (1.25mm) Wafer PIN NO. Description +3.3V C Clock C DATA pin1 3-11 DC Power Input CPI1: DC-in 1x4 (2.0mm) Wafer Internal connector (Red) PIN NO. Description DC-IN (12V, 24V) Note: Very important check DC-in Voltage type for 12V or 9~48V model spec CPI1 pin1...

  • Page 57: Panei Inverter Power Interface

    3-12 Panei Inverter Power Interface (OEM) CPP1: Panel POWER 1x5pin (2.0mm) Wafer PIN NO. Description +12V PWM dimming ENBKL (3.3V) ENBKL (5V) CPP1 pin1 3-13 DC +12V / +5 Voltage Power Output CPO1: +12V / +5V DC voltage output 1x4pin (2.0mm) Wafer (Black) PIN NO.

  • Page 58: Touch Screen (2X5 Pin 2.0Mm Wafer) Usb Interface

    3-14 Touch screen (2x5pin 2.0mm wafer) USB interface (OEM) CT1: For 8-wire type pin defi ne PIN NO. DESCRIPTION PIN NO. DESCRIPTION Bottom Bottom Sense Top Sense Right Right Sense Left Left Sense Note: For eight wire type cable Pin 3 and Pin4 need short CT1: For 4-wire type pin defi...

  • Page 59: Usb Interface

    3-15 USB Interface CU1: USB3.0 Port Type A Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VBUS USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX- Note: CU1 USB2.0 Shared with CU11 signal CU2: USB2.0 Port Type A Connector PIN NO. DESCRIPTION DATA- DATA+ USB 3.0 USB 2.0 CU3 / CU4 / CU11: USB2.0 port 1x4pin (1.25mm) Wafer...

  • Page 60: Lvds1: Lvds Interface (2X15 Pin 1.25Mm Wafer)

    3-16 LVDS1 : LVDS interface (2x15 pin 1.25mm wafer) (OEM) PIN NO. DESCRIPTION PIN NO. DESCRIPTION PWM dimming +LCD(5V or 3.3V) +LCD(5V or 3.3V) Channel-1-DATA3+ Channel-0-DATA3+ Channel-1-DATA3- Channel-0-DATA3- Channel-0-DATA2+ Channel-0-CLK+ Channel-0-DATA2- Channel-0-CLK- Channel-0-DATA1+ Channel-0-DATA0+ Channel-0-DATA1- Channel-0-DATA0- +LCD(5V or 3.3V) +LCD(5V or 3.3V) Channel-1-DATA2+ Channel-1-CLK+ Channel-1-DATA2-...

  • Page 61: Sata Interface

    3-17 SATA Interface SATA1: SATA Port 1x7pin connector PIN NO. Description Note: 1. SATA1 support SATA 2.0 spec update 3Gb/sec. 2. CPO1 provide SATA HDD power +12V, GND, +5V. SATA1...

  • Page 62: Pci Express Mini Card

    3-18 PCI Express Mini card MPCE1 / MPCE2: Support USB and PCIe and mSATA by one Interface (Mini card socket 52pin) MPCE1 / MPCE 2: Full size mini card PIN NO. Description PIN NO. Description +3.3V +1.5V PCIe-CLK-/NC PCIe-CLK+/NC Reset MPCE2 PCIe-RX-/mSATA-RX+ +3.3V...

  • Page 63: Lex Eio Connector

    3-19 LEX eIO connector. Description Description +12V +12V RESET PCIe_TX0_P RESERVED PCIe_TX0_N PCIe_P0_RX_N PCIe_CLK0_P PCIe_P0_RX_P PCIe_CLK_0_N PCIe_P1_RX_N PCIe_TX1_P PCIe_P1_RX_P PCIe_TX1_N RESERVED PCIe_CLK1_P RESERVED PCIe_CLK1_N SMB_CLK USB_P SMB_DATA USB_N SLP_S3_N +12V RESERVED +12V +12V +12V EIO1 pin1...

  • Page 64: Connextor Wafer Of Compatible Brand And Part Number List

    3-20 Connector wafer of Compatible Brand and part number list Location CKTS PITCH Brand Name Mating connector Cable housing 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CALR1 1x4 4Pin 1.25mm MOLEX 53047-0410 51021-0400 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS 2x5 10Pin 2.0mm...

  • Page 65: Introduction Of Bios

    Chapter-4 Introduction of BIOS The BIOS is a program located in the Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program gains control. The BIOS fi rst operates an auto-diagnostic test called POST (Power on Self Test) for all the necessary hardware, it detects the entire hardware devices and configures the parameters of the hardware synchronization.

  • Page 66: Bios Menu Screen & Function Keys

    4-2 BIOS Menu Screen & Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us fi rst see a short description of the function keys you may use here: ●...

  • Page 67: Getting Help

    4-3 Getting Help Status Page Setup Menu/ Option Page Setup Menu Press F1 to pop up a help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press <Esc>. 4-4 Menu Bars There are six menu bars on top of BIOS screen: Main To change system basic confi...

  • Page 68: Main

    4-5 Main Main menu screen includes some basic system information. Highlight the item and then use the <+> or <-> and numerical keyboard keys to select the value you want in each item. System Date Set the Date. Please use [Tab] to switch between data elements. System Time Set the Time.

  • Page 69: Advanced

    4-6 Advanced Boot Confi guration Please refer section 4-6-1 PCI Express Confi guration Please refer section 4-6-2 Video Confi guration Please refer section 4-6-3 Thermal Confi guration Please refer section 4-6-4 SATA Confi guration Please refer section 4-6-5 Console Redirection Please refer section 4-6-6 ACPI Table/Features Control Please refer section 4-6-7...

  • Page 70: Boot Configuration

    4-6-1 Boot Confi guration Numlock Select Power-on state for Numlock, default is <ON>...

  • Page 71: Pci Express Configuration

    4-6-2 PCI Express Confi guration PCIe 1/2/3/4 confi guration settings...

  • Page 72: Pci Express Root Port 1/2/3/4

    4-6-2-1 ► PCI Express Root Port 1/2/3/4 Control the PCI Express Root Port. The optional settings are: Enabled(default), Disabled. Select PCI Express port speed. The optional settings are: Gen1(default), Gen2 Select PCIE TXE ROM support The optional settings are: Disabled(default), Enabled...

  • Page 73: Video Configuration

    4-6-3 Video Confi guration Confi gure LVDS Panel Number as (for OEM Model) The Panel resolution supported are below: 640 x 480 18bit 800 x 600 18bit 1024 x 768 18bit (default) 800 x 480 18bit 1024 x 600 18bit 1280 x 800 18bit 1366 x 768 18bit 800 x 600 24bit...

  • Page 74: Thermal Configuration

    IGD - DVMT Pre-Allocated Use this item to select DVMT 5.0 pre-allocated (fixed) graphics memory size used by the internal graphics device. The optional settings are: 64(default)/96/128/160/192/224/256/288/320/352/384/416/448/480/512MB IGD - DVMT Total Gfx Mem Use this item to select DVMT 5.0 total graphics memory size used by the internal graphics device The optional settings are:128M, 256M(default), MAX 4-6-4 Thermal Confi...

  • Page 75: Sata Configuration

    4-6-5 SATA Confi guration SATA Controller Use this item to Enable or Disable SATA Device. The optional settings are: Enabled(default) or Disabled Chipset SATA Mode Determine how SATA controller(s) operate. The optional settings are: IDE Mode(default), AHCI Mode. SATA Speed Indicates the maximum speed the SATA controller can support.

  • Page 76: Console Redirection

    SATA Port 0 Connected to an ODD Use this item to Enable or Disable SATA Port0 ODD function The optional settings are: Enabled(default) or Disable SATA Port 1 Connected to an ODD Use this item to Enable or Disable SATA Port1 ODD function The optional settings are: Enabled(default) or Disable 4-6-6 Console Redirection Console Serial Redirect...

  • Page 77: Acpi Table/Features Control

    Data Bits The optional settings are: 8 Bits(default) , 7 Bits Parity The optional settings are: None(default) , Even , Odd Stop Bits The optional settings are: 1 Bit(default) , 2 Bits Flow Control The optional settings are: None(default) , RTS/CTS , XON/XOFF 4-6-7 ACPI Table/Features Control ACPI Table/Features Control Select ACPI sleep state the system will enter when the SUSPEND button is pressed.

  • Page 78: Security

    4-7 Security Supervisor Password To set up an Supervisor password 1. Select Supervisor Password. The screen then pops up an Create New Password dialog. 2. Enter your desired password that is no less than 3 characters and no more than 10 characters. 3.

  • Page 79: Power

    4-8 Power Wake on LAN Determines the action taken when the system power is off and the PCI power management Enable wake up event occurs. The optional settings: Enabled, Disabled(default) Power Button Instant OFF(default) : The system will be turn off directly when push the power button. Delay 4 sec : The system will be turn off when push the power button for 4 sec.

  • Page 80: Boot

    4-9 Boot Boot type Select boot type for Dual type ,Legacy boot type or UEFI boot type, default is Dual boot type Quiet Boot The optional settings are: Enabled(default), Disabled. EFI/Legacy Device order Determine EFI device fi rst or legacy device fi rst. The optional settings: EFI device fi...

  • Page 81: Legacy

    4-9-1 Legacy Normal Boot Menu Select Normal Boot option priority or Advance Boot option priority. The optional settings: Normal(default), Advance...

  • Page 82: Boot Type Order

    4-9-2 Boot Type Order Boot Type Order Setting the boot type priority. The default settings is 1.USB drive 2.Hard Disk Drive 3.CD/DVD ROM drive 4.Others...

  • Page 83: Exit

    4-10 EXIT Exit Saving Changes This item allows user to reset the system after saving the changes. Save Change Without Exit This item allows user to saving the changes but doesn’t restart. Exit Discard Changes This item allows user restart the system but no saving the changes Load Optimal Default Use this item to restore the optimal default for all the setup options.

  • Page 84: Device Manaager

    4-11 Device Manager Please press the key F10 when boot up to go into the Device Manager menu Serial Port 1/2/3/4 Confi guration Please refer section 4-11-1...

  • Page 85: Sio Fintek81216D/Dg

    4-11-1 SIO FINTEK81216D/DG Serial Port 1 / 2 / 3 / 4 Use this item to enable or disable serial port (COM1 or COM2). The optional settings are: Enabled (default), Disabled. Serial Port 1 Base IO Address / Interrupt / Serial Mode Use this item to select an optimal setting for super IO device.
  • Page 86 IO=3E8h; IRQ=3,4 IO=3F8h; IRQ=3,4 Serial Port 3 Base IO Address / Interrupt Use this item to select an optimal setting for super IO device. The optional settings are: IO=3E8h; IRQ=10 (default) IO=2F8h; IRQ=3,4,5,6,7,10,11 IO=2E8h; IRQ=3,4,5,6,7,10,11 IO=3F8h; IRQ=3,4,5,6,7,10,11 IO=4F8h; IRQ=3,4,5,6,7,10,11 IO=4E8h; IRQ=3,4,5,6,7,10,11 Serial Port 4 Base IO Address / Interrupt Use this item to select an optimal setting for super IO device.

  • Page 87: Chapter 5 Driver Installation

    Chapter-5 DRIVER INSTALLATION There is a system installation DVD in the package. This DVD does not only include all the drivers you need but also some other free application programs and utility programs. In addition, this DVD also includes an auto detect software telling you which hardware is installed and which driver is needed so that your system can function properly.
  • Page 88 AUTOMATIC DRIVER INSTALLATION menu...
  • Page 89 1. INF Install Intel Baytrail chipset driver 2. VGA Install onboard VGA driver 3. Serial IO Install Serial IO driver (FOR Win 7 only) 4. xHCI Install Intel USB 3.0 xHCI driver (FOR Win 7 only) 5. HD Audio Install HD Audio Codec driver 6.

  • Page 90: Inf Install Intel Baytrail Chipset Driver (Example For Win8 64Bit)

    5-1 INF Install Intel Baytrail Chipset Driver (example for WIN8 64bit) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Intel® Chipset Device Software" menu" screen, click "INF". screen, click "Next". 3. At the "License Agreement" 4. At the "Readme File Information" screen, screen,click "Yes"...
  • Page 91 5. Click "Next" 6. Click "Finish" & restart computer. NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 64/32-bit, X:\driver\INTEL\BAY\INF\WIN7\infi nst_autol.exe For Windows 8 / 8.1 32/64-bit X:\driver\INTEL\BAY\INF\WIN_8_64\infi nst_autol.exe...

  • Page 92: Vga Install Intel Baytrail Vga Driver (Example For Win8 64Bit)

    5-2 VGA Install Intel Baytrail VGA Driver (example for WIN8 64bit) 1. At the"AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup Program menu"screen, click "VGA". screen, Click "Next". 3. At the "License Agreement” screen, 4. At the "Readme File Information” screen, Click "Yes"...
  • Page 93 6. Click "Finish" to restart computer 5. At the "Setup Progress" screen, Click "Next". NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32-bit, X:\driver\INTEL\BAY\VGA\WIN_7_32\Setup.exe For Windows 7 64-bit X:\driver\INTEL\BAY\VGA\WIN_7_64\Setup.exe For Windows 8 / Windows 8.1 32-bit X:\ \driver\INTEL\BAY\VGA\WIN_8_32\Setup.exe For Windows 8 / Windows 8.1 64-bit X:\driver\INTEL\BAY\VGA\WIN_8_64\Setup.exe...

  • Page 94: Serial Io Install Driver Baytrail Serial Io Driver (For Windows 7 Only)

    5-3 Serial IO Install Driver Baytrail Serial IO Driver (FOR Windows 7 only) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup menu" screen, click "Serial IO". Programscreen, Click "Next". 3. At the "License Agreement" screen, 4.
  • Page 95 5. At the "Ready to install the program" screen, 6. Click "Finish" and restart computer Click "Install" NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32-bit, X:\driver\INTEL\BAY\SERIALIO\WIN7_32Bit.msi For Windows 7 64-bit X:\driver\INTEL\BAY\SERIALIO\Win7_64Bit.msi...

  • Page 96: Xhci Install Intel Usb 3.0 Xhci Driver (For Windows 7 Only)

    5-4 xHCI Install Intel USB 3.0 xHCI Driver (FOR Windows 7 only) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup Programscreen, "Next" menu" screen, click "xHCI". Click 3. At the "License Agreement" screen, 4. At the "Readme File Information" screen, Click "Yes".
  • Page 97 6. Click "Finish" to restart computer 5. At the "Setup Progress" screen, Click "Next". NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32 / 64-bit, X:\driver\INTEL\BAY\XHCI\Driver_Installer\Setup.exe...

  • Page 98: Hd Audio Install High Definition Audio Driver

    5-5 HD Audio Install High Defi nition Audio Driver (example for WIN8 64bit) 1. At the "AUTOMATIC DRIVER 2. Click "Next". INSTALLATION menu", click "HD Audio" 3. Click "Finish" to restart computer NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32 / 64-bit, Windows 8/8.1 32 / 64-bit X:\driver\INTEL\BAY\SOUND\Win7_Win8_Win81_R273.exe...

  • Page 99: Mbi Install Intel Mbi Driver (For Win 8/8.1 Only)

    5-6 MBI Install Intel MBI Driver (FOR Win 8/8.1 only) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup Program menu", click "HD Audio" screen, Click “Next”. 3. At the "License Agreement" screen, 4. At the "Setup Progress" screen, Click "Yes".
  • Page 100 5. Click "Finish" to restart computer NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 8/8.1 32 / 64-bit, X:\driver\INTEL\BAY\MBI\Setup.exe...

  • Page 101: Txe Install Intel Txe Driver

    5-7 TXE Install Intel TXE driver 5-7-1 TXE Install for WIN8/WIN8.1 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Setup" screen, Click "Next". menu", click "TXE" 3. At the "License Agreement" screen, 4. Click "Next". Click "Yes".
  • Page 102 5. Click “Finish” & restart computer NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 8 32 / 64-bit, X:\driver\INTEL\BAY\TXE\WIN_8\SetupTXE.exe For Windows 8.1 32 / 64-bit, X:\driver\INTEL\BAY\TXE\WIN_8.1\SetupTXE.exe...

  • Page 103: Txe Install For Win7

    5-7-2 TXE Install for WIN7 Please install PXE Patch fi rst. 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Windows Update" screen, menu", click "TXE Patch " Click "Yes". 3. Click "Finish" & restart computer 4. At the "AUTOMATIC DRIVER INSTALLATION menu", click "TXE "...
  • Page 104 5. At the "TXE Setup" screen, Click "Next". 6. At the "License Agreement" screen, Click "Yes". 8. Click "Finish" & restart computer 7. Click "Next". NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32 / 64-bit, TXE Patch X:\driver\INTEL\BAY\TXE\WIN_7\kmdf-1.11-Win-6.1-x86.msu X:\driver\INTEL\BAY\TXE\WIN_7\kmdf-1.11-Win-6.1-x64.msu...

  • Page 105: How To Update Insyde Bios

    5-8 How to update Insyde BIOS Under DOS Mode STEP 1. Prepare a bootable disc. (Storage device could be USB FDD or USB pen drive.) STEP 2. Copy utility program to your bootable disc. You may download it from our website. STEP 3.

  • Page 106: Appendix A:power Consumption Test

    Appendix A: Power Consumption Test Condition ( 2I386EW ) Item Spec Atom E3845 1.91 GHz / Celeron J1900 1.99GHz Memory DDR3L 1600 4GB Operating System Windows 7 Ultimate 64bit Test Program 3D Mark 06 HDD 2.5" SATA 128GB mSATA 32GB...

  • Page 107: Appendix B:resolution List

    Appendix B: Resolution list 640 x 480 x ( 256 / 16bit / 32bit ) 800 x 600 x ( 256 / 16bit / 32bit ) 1024 x 768 x ( 256 / 16bit / 32bit ) 1152 x 864 x ( 256 / 16bit / 32bit ) 1280 x 600 x ( 256 / 16bit / 32bit ) 1280 x 720 x ( 256 / 16bit / 32bit ) 1280 x 768 x ( 256 / 16bit / 32bit )
