Janus Nokē ONE Quick Start Manual

SETUP HARDWARE
Remove Battery Holder
A: Slide removal tool onto Nokē ONE so the
edge of tool and left edge of Nokē ONE connect
B: While tightly holding removal tool in place, use opposite hand to firmly push in battery holder to release it
*Use only battery supplied with Nokē One. Do not attempt to
use other batteries as they will not have the necessary voltage,
current, and capacity required for optimal performance
C: Insert battery into battery holder. Be sure positive end is on the right
D: With battery in holder, insert the battery
holder back into the device. Press firmly on
top and bottom to engage both hooks
TESTING HARDWARE
*Be sure Nokē ONE is functioning correctly before installing on door
Unlock and Lock Nokē ONE
A: Before being added to the site and receiving electronic keys, you can unlock
Nokē ONE by touching the plastic window on the front of the device three times.
The light will turn blue when touch is accepted
B: After touching three times, the light will turn green to indicate that the
Nokē ONE device is now ready for unlocking
C: Slide the hasp left to the open position and right to lock.
The light will turn red to confirm device is locked
Unlocked Position
Removal Tool Nokē ONE
Battery Holder
Locked Position
INSTALLATION
*Remove the existing Hasp from the door before installing Nokē ONE Device
*See back side of guide
for instructions on how
to use the included
alignment template
A: Confirm the four existing holes line up with bolts
on Nokē ONE. *Drill new holes if needed
C: Remove backing from adhesive
mounting tape on back side of Nokē ONE
E: Open door and go inside unit and then
pull door back down. You are now inside
unit and can see the back of the device
G: Place mounting plate over holes.
Be sure to orient the plate so center
hole is closer to the bottom
ADDING Nokē ONE TO SITE
A: Use the Nokē Smart-Entry App to
B: Using web portal, be sure
scan QR code on the device and add
electronic keys are sent to
device to the Smart-Entry system
Nokē ONE via gateways
SUPPORT
If you need support, please call 1(833) 257-0240
B: If door does not have a middle hole for cam lock, an
additional hole will need to be drilled to accommodate
the plastic back window for the motion sensor
D: Push Nokē ONE firmly onto door
F: While looking at four bolts, pull firmly on
each of them to extend them through door
H: Add the four nuts to ends of
bolts and tighten
UNLOCK
C: Use the app to unlock the device
after it has been synced to the system.
The QR sticker can now we removed
