UFlyMike HARMONY Aviation Quick Start Manual

HARMONY
1
3
6
(Pro Only) Connect the HARMONY Headphone
Cable to the Aviation Cable by aligning the Red
Marks and inserting the plug, locking in place.
Disconnect by grabbing the plug by the Sliding
Sleeve and pulling away from the Aviation
Cable (retracts locks, then slides apart).
Position the Microphone so the
White Dot is pointed directly at your
mouth. The mic should be close
enough that the windscreen barely
touches your lips when pursed.
Quick Start Guide

1) Left Ear Audio Volume

2) Right Ear Audio Volume

2

3) Mono/Stereo Source Select

1-bar for Mono Panels, 2-bar for Stereo

4) Microphone Gain

4
Adjusts Microphone Sensitivity & Volume

5) Aircraft / Auxiliary Audio

5
Microphone Routing Select
Device Microphone Output is Connected

6) Headphone Jack

Connect HARMONY Headphone Cable
7

7) Auxiliary Audio Jack

Connect Additional Audio Device
Aviation
™
(Pro only)
