Summary of Contents for IOT HF2111
- Page 1 User Manual and Test Guide HF2111 Operation Guide http://www.iotworkshop.com Copyright © 2013 . All rights reserved...
-
Page 2: Table Of Contents
Content 1. SERIAL SERVER CONNECTION ..................3 1. 1 HF2111 Connection ..................... 3 2. SERIAL CONFIGURTION ..................... 3 2.1. Serial Tool SecureCRT ....................4 2.2. Configure Serial Parameter ..................4 3. CREATE NETWORK CONNECTION BY IOTSERIALTOOL ........5 3.1. IOTSerialTool Introduction ..................5 3.2. -
Page 3: Serial Server Connection
China Unicom/China Mobile 2/3/4G standard sim card, not for China Telecom. After HF2111 is powered on and connect to network successfully, it needs about 30s to wait light Net turn to be green. If any data transmit to server by HF2111, light Active will blink. -
Page 4: Serial Tool Securecrt
Data Bits：8 Parity Check Bit：None Stop Bit：1 Flow Control： None（Please tick off “√”before RTS/CTS） Notes: HF2111 the default serial data is as above and user can modify device working parameter by IOTService. http://www.iotworkshop.com Copyright © 2013 . All rights reserved... -
Page 5: Create Network Connection By Iotserialtool
IOTSerialTool download address: http://gb.hi-flying.com/download_detail/downloadsId=107.html IOTSerialTool is a visual software based on HF2111 serial optimization and it is developed for convenient network connection. When using this software, other serial tool can not be opened at the same time(because port will be ocqupied). - Page 6 Step 2：Open IOTSerialTool and click serial port->read device parameter(sim card information) http://www.iotworkshop.com Copyright © 2013 . All rights reserved...
- Page 7 Note: Why reading data fails? 1. Check if sim card is successfully used(only for Unicom and Mobile card) 2. Check if serial cable is successfully connected(please use cross serial line) 3. It needs about 30s to generate network connection(led Net lights on). It cannot read information of sim card before device boots up.
- Page 8 Step 3：Configure relative serial parameter according to user lower-layer device. Step 4：Configure socket to generate network connection. Confirm and restart product. http://www.iotworkshop.com Copyright © 2013 . All rights reserved...
- Page 9 Step 5：Parameter of socketa from upper figure is IP address and port number of our test server. User can configure and check if HF2111 is working normally. After configure successfully and close IOTSerialTool, open SecureCrt. After sending data from serial port, it can show the responding data.
-
Page 10: Test Case Two: Congifure By Network
Step 6：If product cannot build generation with server, please type the following command. Output log information from SecureCRT and discuss solution with Hi-flying. Test Case Two: Congifure by Network 3.3. Step 1：Open SecureCRT and input command +++ and a to enter into command mode. - Page 11 Step 2：Input AT+UART to search and configure serial parameter. Specific situation can refer to chapter 4 in HF2111 user manual. http://www.iotworkshop.com Copyright © 2013 . All rights reserved...
- Page 12 Step 3：Input command ＂AT+SOCKA=TCP,3006,nat1.iotworkshop.com,LONG＂to set socket. And type AT+Z to restart HF2111. http://www.iotworkshop.com Copyright © 2013 . All rights reserved...
- Page 13 Step 4：By sending data from serial port, it can show responding data from server.(Default mode is transparent). If not, please type ＂AT+ENTM＂to enter in. http://www.iotworkshop.com Copyright © 2013 . All rights reserved...
- Page 14 http://www.iotworkshop.com Copyright © 2013 . All rights reserved...
