M odel : S PK-520
3.
4.
5.
1. Cable Management Tray (1PC)
2. Connecting Bracket (2PCS)
M4x6mm
St4.2x16mm
2.5x2.5mm
Allen Key
(2PCS)
(4PCS)
(1PC)
1
3
2
Length*Width*Height
500*120*90MM
STEP1
Attach the connecting bracket to the cable management tray.
1
3
2
4
STEP2
Attach the cable management tray to the tabletop.
Tabletop
Tabletop
Tighten the screws
5
Advertisement
Table of Contents
Summary of Contents for Spacetronik SPK-520
- Page 1 M odel : S PK-520 1. Cable Management Tray (1PC) 2. Connecting Bracket (2PCS) M4x6mm St4.2x16mm 2.5x2.5mm Allen Key (2PCS) (4PCS) (1PC) Length*Width*Height 500*120*90MM STEP1 Attach the connecting bracket to the cable management tray. STEP2 Attach the cable management tray to the tabletop. Tabletop Tabletop Tighten the screws...
- Page 2 Specifications CAUTION This product contains small items that could be a choking hazard if swallowed. Keep these items away from young children. ● Make sure these instructions are read and completely understood before attempting installation. If you are unsure of any part of this installation, please contact a professionalinstaller for assistance.
