Summary of Contents for Precision CAM Cow Cam

  • Page 2: Table Of Contents

    Expansion Pack ………………………………………………………………… 14 High Gain Antenna ……………………………………………………..………. 14 Thank you for purchasing your PTZ-IR Livestock Monitoring System (Cow Cam) from us. You will get many years of use from your new wireless video system, it comes with a one-year warranty on parts and labor, and we guarantee it to work when installed according to our assessment.
  • Page 3: Warranty

    If you are within Manitoba or Saskatchewan please do not forget to send one copy of your invoice back to us with your section/township/range and signature for Cow Cam to be PST exempt! WARRANTY COVERAGE: Allen Leigh Security is proud to offer one year warranty on our livestock monitoring systems which covers parts and manufacturer defects.
  • Page 4 Your Complete PTZ CowCam Kit comes with: 1. 1 - Transmitter Box 2. 1 - PTZ Camera (Large/ Mini) - 10X PTZ shown above 3. 2 -30 ft. Power Cables (red with black & Orange ends) 4. 1 - 6 pin 30 ft. PTZ Camera Cable (Black) 5.
  • Page 5: General Information

    General Information The system consists of two main parts, a barn side, and a house side. On the end where the camera will be located (the barn) is also where the transmitter box and power supply will be mounted (on the outside of the building facing the house where the receiver will be located) The transmitter and camera will be connected together with the camera cable.
  • Page 6 note of what the address of the camera is from the TV s when it does its startup routine, and then enter in that address number on the keypad of the PTZ Controller followed by the CAM button. (Eg Dome ID: 001, on the keypad of the controller press: 01 on the PTZ controller then CAM button.
  • Page 7 Camera Mounting Instructions Small PTZ Kit Includes: (1) LMS-MNT-PTZ-SM universal mount bracket (4) 1‖ X 1/4‖ track bolts for camera attachment (4) 1/4‖ lock washer nuts (1) 5/16‖ flat washer (for setting track bolts) Step #1: Installing track bolts  Choose the camera mount bolt pattern before installing track bolts.
  • Page 8 Large PTZ The large camera mount LMS -MNT-PTZ-LRG can be used to mount the camera on a telephone pole or exterior corner of a building. It is made of stainless steel and supplied with 3/8‖ course thread track bolts and flange nuts. The track bolts must be installed in the mount so that they project out toward the camera mount.
  • Page 9 Instructions include the following:  How to pull track bolts into the mounting plate.  How to fasten the mounting plate to top of pole.  How to fasten camera to the mounting plate.  Step #1 – Setting Track Bolts: -Put your track bolt through one of the 4 holes.
  • Page 10 -When fastening the mounting plate to a proper -If mounting surface is big enough, outside holes can pole, much more holes can be utilized for added also be used. strength. Step #3 – Fastening Camera to Mounting Plate: -To ensure camera cable does not get pinched, and make the running of the cables easier, first feed connectors through the oval shaped hole in the plate (Only if Mounting surface allows an opening underneath!) Lastly put camera on the mounting plate with bolts coming through the mounting holes on camera.
  • Page 11: Programming /Camera Operation

    Programming / Camera Operations Moving Camera To move the camera you push the joystick left to move to left and right to move the camera to the right. The harder you push the joystick, the faster the camera moves; a slight push moves the camera slowly. You can also use the joystick for zooming out by turning the knob clockwise and zoom in by turning the knob counter clockwise.
  • Page 12: Creating Preset Location Points

    To Stop the Auto Scan, just move the joystick, to restart use the appropriate speed number and CALL button again Creating Preset Location Points Position your camera on the point of interest that you want to view, you can zoom in/out on the object location.
  • Page 13: Tour

    You can set the tour to start with any one of your pre-set locations, and have it stay on for the length of time you want in seconds. You can have up to 12 tour locations set if you like. Once you have the tour set to your liking, press the ―OPEN‖...
  • Page 14: Troubleshooting

    Picture Problems If you do not get a picture right away, upon completing your connection you may have to unplug and plug the transmitter back in, this does a system reset, and usually rectifies the problem if there is no picture from the system.
  • Page 18: Dvr

    DVR Installation Instructions: Step 1: Unpack everything from the DVR box. You should have: (1) DVR (1) Remote (1) Mouse (1) Power supply (1) HDMI cable (*) RCA to BNC connectors 1 per receiver (1) Data Box Step 2: connect the RCA to BNC connectors to the back of the DVR. Step 3: plug the mouse into the USB port on the front of the DVR Step 4: plug one end of the HDMI cable into the HDMI port on the back of the DVR.
  • Page 19 Step 3: get your Serial Number and QR scan Code From the main menu go to Info>System On the left hand side go to Version. This will show your scan code and Serial Number. Keep this screen up for the next part.
  • Page 20: Audio Mod

    Audio Modification Installation Steps: If the Audio Modification Box option was purchased, you will have two cable ends, they are setup so that the camera end will fit into one side and the camera cable into the other the connectors, the connectors on the audio box are opposites.
  • Page 21 replace it with the coax from the High Gain Antenna. The antenna will then be mounted outside facing toward the transmitter, please note the orientation arrows on the back of the unit. Make your analog system smart phone compatible!! Watch from the comforts of home or take your work with you and monitor your system from your smart phone.
