Summary of Contents for DIEBOLD NIXDORF BEETLE/Multi IO Hub Gen.2
- Page 1 BEETLE /Multi IO Hub Generation 2 User manual 01750354402A DieboldNixdorf.com...
-
Page 2: Table Of Contents
Table of Content Manufacturer´s Certification ..................3 Important notes........................ 3 Safety Information ........................3 System maintenance ........................4 Introduction ........................5 About This Manual ........................5 Warranty ............................5 Recycling ............................6 Before Putting Into Service .................... 6 Checking the Scope of Supply ....................6 Setting up the Hub Gen.2 ...................... -
Page 3: Manufacturer´s Certification
Manufacturer´s Certification 1 Manufacturer´s Certification This device meets the requirements of the EU Guidelines 2014/30/EU "Electromagnetic Compatibility" and 2014/35/EU “Low Voltage Directive” and 2011/65/EU "Restriction of Hazardous Substances". For this, it bears the CE label on the rear side or the icon is printed on the packaging. -
Page 4: System Maintenance
– penetration of liquids or foreign bodies), switch the device off immediately, pull the power plug and inform the technical customer service of Diebold Nixdorf or the authorized service partner of your dealer. Your BEETLE /Multi IO Hub Gen.2 is the result of state-of-the-art technical –... -
Page 5: Introduction
Please inform yourself by studying the respective manuals. 3.2 Warranty In general, Diebold Nixdorf (DN) guarantees a warranty of 12 months after delivery or acceptance date. This warranty covers all defects that have occurred during normal use of the product. -
Page 6: Recycling
You are helping us with the recycling if you do not attach any labels to the device. For materials which currently cannot be used for a new purpose, Diebold Nixdorf offers environmentally friendly disposal at a recycling center that is certified in accordance with ISO 9001 and ISO 14001. -
Page 7: Setting Up The Hub Gen.2
The serial number is located on the label next to the barcode. The following parts should be considered for the operation of the Multi IO Hub Gen.2 when ordering: D:CRNT-24V-V1 (01750266555) Power Supply 24 V/5 A (is required only if not already available with DN BEETLE /A1xx0 POS system) D:CRKB-D1-3M (01750341520) USB-C Cable, 3m (uplink to DN BEETLE /A1xx0 system) Alternative/optional available for ordering:... -
Page 8: Horizontal
Use commercially available screws for the fastening which are adapted to the subsurface. To fasten the Multi IO Hub Gen.2, use screws with a screw head diameter of 5-8 mm (0.20-0.31 inches), with a shaft diameter of max. 4.2 mm (0.17 inches). Even if you want to incorporate the device, it is mandatory that you adhere to the specified minimum distances and ensure constant aeration and ventilation. -
Page 9: Vertical
4.2.2 Vertical In order to ensure that correct ventilation continues to be guaranteed, the following minimum distances must be maintained for free convection, even with vertical setup. Around all 5 sides of the device: 50 mm (1.97 inch) You can fasten the suspended BEETLE /Multi IO Hub Gen.2 on either the left or the right. -
Page 10: Exterior
5 Exterior The following illustration shows the BEETLE /Multi IO Hub Gen.2. Front view Rear view 01750354402A BEETLE /Multi IO Hub Gen.2 – User Manual... -
Page 11: Interfaces
6 Interfaces 1 COM a Standard RS232 (plug) 11 LAN Pass-through (RJ45/RJ45) 2 COM b Standard RS232 (plug) 12 Status LED 3 COM c* RS232 powered (socket) 13 2x USB-A 2.0 4 LAN 10/100/1000 Mbit/s 14 2x USB-A 3.0 5 USB-C 3.1 - 1 (DP) 15 3 x powered USB 2.0/12V 6 USB-A 2.0 16 PoweredUSB 2.0/24V... -
Page 12: Com A And Com B
6.1 COM a and COM b Connect for example a scale with dedicated power supply to the COM a or COM b interface. COM a and COM b are designed as standard 9-pin D-Sub plugs (male). The COM Interface connector with knurled screw can be disengaged by hand. PIN Function DCD –... -
Page 13: Lan (Rj45)
6.3 LAN (RJ45) The cable for the connection to a network (LAN) will be plugged in here. LEDs Left LED Constant green Network connection established Flashes green Data transfer Right LED 10 MBit Constant green 100 MBit Constant orange 1000 MBit This LAN connection is provided through an internal USB 3.1 interface. -
Page 14: Lan Pass Through (2X Rj45)
6.4 LAN pass through (2x RJ45) It may happen in some installation environments that the installed LAN connection (via USB) cannot be used. The Multi IO Hub Gen.2 therefore offers a so-called LAN pass- through, meaning the Multi IO Hub Gen.2 can be used to loop the LAN through to the POS system. -
Page 15: Usb-C Uplink
6.5.1 USB-C Uplink This connection is used to set up the connection between the BEETLE /Multi IO Hub Gen.2 and the DN A-family POS system via USB-C Uplink cable. Take care to ensure while doing so that this cable matches the current USB specifications. 6.5.2 USB-C 1 (DP) This connection is used to set up the connection between the BEETLE /Multi IO Hub Gen.2 and a USB-C display via USB-C Display Port (DP) and Power Delivery (PD). -
Page 16: Poweredusb 2.0
6.8 PoweredUSB 2.0 USB peripherals, whose energy demand is higher than the supply provided by the standard USBs, e.g. printers, barcode scanners or displays, can be operated at PoweredUSB ports. WARNING The power supply is 24 V (marked in red, for POS printers) or 12 V (marked in turquoise) (see chapter "Total Power Consumption"). -
Page 17: Status Led
The connection of sub-drawers (the so-called looping through) and the connection of 12 V OEM cash drawers is not permitted! Function FG – Frame ground OPEN1 – Opening signal for drawer KLE1N – Status drawer (open/closed) +24 V – Supply voltage <not used>... -
Page 18: Power Supply (24 V Dc In)
The power supply of the AURES YUNO POS system is provided through this socket as an alternative to the 24 V DC out. Use the power supply cable that can be ordered from Diebold Nixdorf (see chapter "Checking the Scope of Supply"). -
Page 19: Cabling The Beetle /Multi Io Hub Gen.2
Cabling the BEETLE /Multi IO Hub Gen.2 All devices that are part of the BEETLE /Multi IO Hub Gen.2 and that have their own dedicated mains voltage cable must be connected to the same circuit. – Ensure that the USB-C uplink cable from the POS system USB-C is connected, all data cables are plugged into the Multi IO Hub Gen.2 and peripherals. -
Page 20: Appendix
Appendix 8.1 Technical Data Size Width 310 mm (12.20 in.) Depth 157 mm (6.18 in.) Height 58 mm (2.28 in.) Weight approx. 1.2 kg (2.64 lb) Ambient conditionen (Temperature) Operation - 5°C to + 40°C (5%-85% r.h.) Transport - 25°C to + 60°C (15%-98% r.h.) Storage - 5°C to + 40°C (15%-85% r.h.) Power supply... -
Page 21: Block Diagram
8.2 Block Diagram 01750354402A BEETLE /Multi IO Hub Gen.2 – User Manual... -
Page 22: Total Current Consumption Of Interfaces
Multi IO Hub Gen.2. The 24 V PoweredUSB interface is provided for the operation of retail thermal printers authorized by Diebold Nixdorf. 01750354402A BEETLE /Multi IO Hub Gen.2 – User Manual... -
Page 23: Abbreviations
Abbreviations Abbreviations Descriptions Ampere European Symbol of Conformity RS232 interface COM* RS232 interface, power supplied Deutschen Institut für Normung (German Institute for Standards) D-Sub D-Shaped Subminiature Electronic funds transfer Electrostatic Sensitive Devices European Union Internationale Organisation für Normung (International Organization for Standardization) Local Area Network Light Emitting Diode PEN conductor... -
Page 24: Notes
8.5 Notes 01750354402A BEETLE /Multi IO Hub Gen.2 – User Manual... - Page 25 Diebold Nixdorf D-33094 Paderborn Order No.: 01750354402A 01750354402A BEETLE /Multi IO Hub Gen.2 – User Manual...
