30W ZIGBEE 3.0 DIMMABLE LED DRIVER
•
ZigBee CCT LED product, based on ZigBee 3.0 protocol.
•
Compatible with various ZigBee systems such as Philips Hue, Amazon Alexa, etc.
•
Can be controlled directly (without ZigBee Hub) via Touch Link
•
100-240VAC wide input voltage range
•
2 adjustable constant current outputs
•
Supports ZigBee Green power and can be operated with up to 20 ZigBee Green power remote controls
•
IP20 protection class, suitable for indoor lighting projects
•
5 years warranty
Subject to change without notice. Specifications without guarantee. / 08.01.2021
SRP-9101-30-TW-CC
Product features
1
Advertisement
Table of Contents
Summary of Contents for Ranger SRP-9101-30-TW-CC
- Page 1 SRP-9101-30-TW-CC 30W ZIGBEE 3.0 DIMMABLE LED DRIVER Product features • ZigBee CCT LED product, based on ZigBee 3.0 protocol. • Compatible with various ZigBee systems such as Philips Hue, Amazon Alexa, etc. • Can be controlled directly (without ZigBee Hub) via Touch Link •...
- Page 2 Technical Data Voltage Range 200-240VAC Frequency Range 50/60Hz Power Factor (typ.) >0.9@230VAC Total Harmonic Distortion THD ≤ 15% (@ full load /230VAC) INPUT Efficiency typ. 83% @ 230VAC full load AC Current (typ) 0.17A @ 230VAC Inrush Current (typ) Cold start max. 2A@230VAC Leakage Current <...
- Page 3 Product Dimension Functions Prog. button: - Press briefly to switch the unit on/off AC 200-240V Input - Press and hold to increase / dim the brightness of the strip Wiring Diagram The ZigBee device is a wireless receiver that communicates with various ZigBee compatible systems. Subject to change without notice.
- Page 4 Installation SAFETY AND WARNINGS • Do not install the unit when it is connected to the mains. • Do not expose the unit to moisture (incl. splashing or dripping water). • Approved cable diameter: AWG16—AWG20 / 0.5mm -1.5mm Connecting to / disconnecting from the ZigBee network If the device was already in operation, remove the device from a previous ZigBee network.
- Page 5 Connecting via TouchLink with a ZigBee remote control 1. Method 1: Press the Prog. button 4 times in succession (or disconnect the unit from the mains 4 times). The connected strip flashes 2 times. You have 180s for the further steps. Method 2: Disconnect the unit from the power supply and reconnect it.
- Page 6 Find and Bind Mode 1. Press the Prog. button 3 times in quick succession (or disconnect the unit from the mains 3 times) to start the Find and Bind mode (the Connected light flashes slowly). You now have 180 seconds for the following actions. 2.
- Page 7 Disconnecting a ZigBee TouchLink remote control Check that the unit is on a network. The remote control must be integrated in the same network or not connected to any other network. 1. Disconnect the unit from the mains and reconnect it after 15 seconds. If you could not perform the following actions within 180s, repeat the action.
- Page 8 Create a ZigBee network & integrate other products to the network without a hub 1. Press the Prog. button 3 times in quick succession (or disconnect the unit from the power supply 3 times and reconnect it). You have 180s for the following actions. 2.
