SkyLink KP-433 User Instructions

Introduction
We have included screws, wall anchors and a template to aid in the
The Keypad Transmitter functions
as an external keypad control for installation of the keypad transmitter.
Use the template to install the keypad transmitter:
the Security Control Panel SC-001
1. Tape the template to the wall where
and the Audio Alarm AA-433. You
you would like the keypad trans-
may place the transmitter by a
mitter to be.
second entrance (back door, patio
2. Screw part way into the surface where
door etc.). If used in conjuction
the holes are marked on the template.
with the Security Control Panel,
3. Unscrew the screws and remove the
the keypad transmitter functions
template.
the same as the keypad on the
4. Screw the keypad transmitter in place
control panel, except the keypad
where you started the screws.
transmitter cannot be used to
5. Align the two holes located at the
program sensors. If used with
back of the keypad transmitter with
AA-433, the key pad transmitter
the screws on the wall.
is able to arm/disarm the audio
alarm.
O peration of the Keypad Transmitter for Security
Control Panel SC-001
Once the keypad transmitter is "learned" to the control panel, it works the
same way as the keypad on the control panel, except you cannot use it to
program sensors to the control panel. You can arm and disarm the security
control panel using the keypad transmitter.

Personalizing your password

The password(s) on the keypad transmitter can be different than the one(s)
on the control panel. There are also two kinds of passwords:
1. Master Personal Identification Number (MPIN)
2. Secondary Personal Identification Number (SPIN)
Since the keypad transmitter is unable to program any sensors, the MPIN
and the SPIN perform the same functions. You can have one MPIN and up
to 3 separate SPIN.
The MPIN is factory preprogrammed with 0 0 0.

Installation

To change your MPIN:
1. Enter the current MPIN, (or 0 0 0 if you have
never changed the MPIN)
2. Press [ * ]
3. Press [ 0 ]
4. Press [ * ]
5. Enter your new MPIN, (your number must be a
minimum of 3 digits)
6. Press [ * ]
If the system accepts the new MPIN, you will hear a long
beep. If you hear three short beeps, the system did not
accept the new MPIN. Start again from the beginning.
Note: If you enter an incorrect MPIN or SPIN, the alarm
will sound after the forth incorrect attempted.
Note: If you forget the current MPIN, remove the batter-
ies from the keypad transmitter. The MPIN will automati-
cally return to the factory default of 0 0 0.
Make sure you do not install this unit outdoor, otherwise
the MPIN could be reset to the default value if the
batteries are removed.
Program the Keypad Transmitter to the Security
Control Panel SC-001
1. Enter the current MPIN (Master Personal Identification Number)
on the control panel SC-001.
2. Press [B] on the control panel.
3. If you are programming the tramsmitter to the security control
panel SC-001, press [5] on the control panel. This is the zone
where the keypad transmitter will communicate with the security
control panel. ONLY PROGRAM THE KEYPAD TRANSMITTER
TO THE DESIGNATED ZONE, OTHERWISE THE TRANSMITTER
WILL NOT WORK PROPERLY.
4. Press [*] within 8 seconds on the control panel, you will hear a
long beep from the control panel.
5. Activate the keypad transmitter by pressing the panic button
(red key) on the keypad transmitter. The "ON" light on the
transmitter will be on. You will hear a long beep from the control
panel, the keypad transmitter will now communicate to the
control panel.
Secondary Personal Identification number (SPIN)
The keypad transmitter provides you with the option of adding up to 3 separate SPIN.

Adding a SPIN

1. Enter the current MPIN
2. Press [ * ]
3. Press the number key to identify user, either [ 1 ], [ 2 ] or [ 3 ]
4. Press [ * ]
5. Enter the new SPIN (your number must be a minimum of 3 digits)
6. Press [ * ]
If the system accepts the new SPIN, you will hear a long beep. If you hear three
short beeps, the system did not accept the new SPIN. Start again.

Deleting a SPIN

1. Enter the current MPIN
2. Press [ * ]
3. Press the number to identify the user, either [ 1 ], [ 2 ] or [ 3 ]
4. Press [ * ]
5. Press [ * ] one final time.
If the SPIN was successfully deleted, you will hear a long beep.
Program the Keypad Transmitter to
the Audio Alarm (AA-433)
1. With only the "ON" light lit on the Audio Alarm,
press and hold the learn button located on the
bottom of the Audio Alarm.
2. While pressing down on the learn button,
activate the Key pad Transmitter by pressing
the panic button (red key) on the Keypad Trans-
mitter. The "ON" light on the Keypad Transmitter
will flash.
3. If a connection has been made, the Audio
Alarm will stop beeping and make a continuous
tone until the black learn button on the Audio
Alarm is released.
4. Now test the keypad transmitter by pressing
the panic button on the transmitter again. If
the Audio Alarm beeps, they are communicating.
