Parktron BPS2000 User Manual

Barcode parking system
Hide thumbs Also See for BPS2000:
Table of Contents

Advertisement

Quick Links

Download this manual
BPS2000 Barcode Parking System
Auto Pay Station - BAPS208
User's Manual
Version 4.0
Issue Date: 2014.01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BPS2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Parktron BPS2000

Summary of Contents for Parktron BPS2000

  • Page 1 BPS2000 Barcode Parking System Auto Pay Station - BAPS208 User’s Manual Version 4.0 Issue Date: 2014.01...

  • Page 2: Table Of Contents

    3.7. Install paper roll on thermal printer: ..............26 4.Solutions to frequent encountered problems: ............27 Revision History: Version Released Date Revision Notes 2009.11 First edition release 2011.11 Cabinet design change 2012.03 Content update 2014.01 Change document format © 2014 - 2024 Parktron Technology Ltd.

  • Page 3: Introduction

    1.1. Functional description: BAPS208 is an Auto Pay Station used in BPS2000 parking system. It supports barcode (Code: 128C) tickets and provides a convenient payment service in a parking facility. In case of network disconnection, BAPS208 can be operated under stand-alone mode, off-line data will be saved and then sent back to Central Management Server after network reconnected.

  • Page 4: Exterior

    Infra-red sensor: To detect user and activate station system. d. Receipt and change outlet. e. Banknote insert inlet for payment. f. Coin insert inlet for payment. g. Sub-intercom device for communicating to operator at master intercom station. © 2014 - 2024 Parktron Technology Ltd.

  • Page 5: Interior

    1.3. Interior: Figure 2 a. IPC: Industrial Personal Computer to handle system operation and data processing. © 2014 - 2024 Parktron Technology Ltd.
  • Page 6 Circuit breaker: Main power switch of AC input and over current, leakage protection to the device. g-2 EMI filter: Filtering power noise to provide a clean power to device. g-3 Terminal block: Device AC power connection point. © 2014 - 2024 Parktron Technology Ltd.
  • Page 7 Adjust the level angle of the LP1 detector for detection sensitivity (manually push the cabinet to observe the status of LED D5, and adjust to an acceptable sensing range). 5. SW1/SW2: DC power main switch of APS main control board. © 2014 - 2024 Parktron Technology Ltd.

  • Page 8: Display Screen Introduction

    Fourth light: Connection to sever station (central management station). c-5. Fifth light: Currently not in used. Function buttons: Provide text description for options to match with physical buttons next to the display screen to users. © 2014 - 2024 Parktron Technology Ltd.

  • Page 9: Power On / Shut Down

    (Display screen shows “System Starting… Please Wait…). Step 3: After system program completes device check, the system is ready for service with idle page (Please Insert Ticket) displayed on the screen. © 2014 - 2024 Parktron Technology Ltd.

  • Page 10: Shut Down Procedure

    IPC. Step 3: Please wait for another minute after monitor shut down before switch off main circuit breaker(No. 1 in Figure 3) to allow system completes data read/write. © 2014 - 2024 Parktron Technology Ltd.

  • Page 11: Payment Process

    Step 3: After calculation, the required payment amount of parking will be shown on the display. If any problem tickets found or ticket read error, the system will reject the ticket to the user. © 2014 - 2024 Parktron Technology Ltd.
  • Page 12 Step 6: Payment operation completed, user take the ticket (card) back for exit validation. © 2014 - 2024 Parktron Technology Ltd.

  • Page 13: Season Card Operation

    …continue to section 3.2.2 below. c. [Cancel]: Push to cancel operation and card returned back to user. System display goes back to idle page. © 2014 - 2024 Parktron Technology Ltd.

  • Page 14: Season Card Renewal (Optional Feature)

    [1 Month]: Extend 1 months from expiration. [Cancel]: Cancel season card renewal operation and get card returned. Step 4: Conduct payment with banknote(s) or coin(s). Ticket (card) will be returned and receipt will be provided after payment completed. © 2014 - 2024 Parktron Technology Ltd.

  • Page 15: Hourly Payment With Season Cards

    Step 4: Pay with banknote(s) and/or coin(s). Amount paid will be displayed on the screen instantly. Note：Press [Cancel] can bail out the payment operation and get the ticket and all paid money returned. © 2014 - 2024 Parktron Technology Ltd.

  • Page 16: Login To Maintenance Page

    (2); Click on [Other functions] in maintenance page (2) to switch to maintenance page (3); And click on [Other functions] in maintenance page (3) to switch back to maintenance page (1). © 2014 - 2024 Parktron Technology Ltd.

  • Page 17: Maintenance Page (1)

    Show total number of coins in  different denomination coin hopper. Disc. coupon(s) collected: Numbers of discount coupon received by  current shift. Accumulated disc. coupons collected: Historical accumulated  discount coupons ever received. © 2014 - 2024 Parktron Technology Ltd.

  • Page 18: Reprint Revenue Settlement Report

    Step 3: Push [Print] button for the thermal printer to print out 2 copies of the report. Step 4: Push [Close] button to leave the reprint page and back to maintenance page (1). © 2014 - 2024 Parktron Technology Ltd.

  • Page 19: Maintenance Page (2)

    Step 1: Push the [Coin Test] button in Maintenance page (2) to enter the testing page as below. Step 2: Insert coins from the coin inlet on APS front panel to test. Accepted number of © 2014 - 2024 Parktron Technology Ltd.

  • Page 20: Bill Testing

    And number of failed validation will be also recorded in the bottom column. Step 3: After testing, push [Return Bills] button to get all the accepted bills returned back to change outlet. And push [End] button to go back to Maintenance page (2). © 2014 - 2024 Parktron Technology Ltd.

  • Page 21: Replenish Change Coins

    Insert coin(s) one by one - Manually insert coin(s) from the coin inlet on APS  front panel. System will validate and accept inserted coin(s), and update [Actual coin number] column for each coin denomination hopper accordingly on the screen. © 2014 - 2024 Parktron Technology Ltd.

  • Page 22: Maintenance Page (3)

     [Bill Dispenser]: Push to enter bill dispenser operation page.  Note： Bill dispenser is an optional function device with extra cost. [Other functions](next page): Push to go back to maintenance page (1). © 2014 - 2024 Parktron Technology Ltd.

  • Page 23: Revenue Settlement

    Step 2: Push [Full Settlement] or [Daily Settlement] to conduct revenue settlement operation. Note：Before pushing a settlement button, place coin collecting box under every coin discharge outlets or close device cabinet door to allow coins to drop in the change and receipt outlet. © 2014 - 2024 Parktron Technology Ltd.
  • Page 24 Full or Daily settlement receipt will have its bill data listed all 0. Step 6: Push [Close] button to quit out of revenue settlement page and go back to maintenance page (3). © 2014 - 2024 Parktron Technology Ltd.

  • Page 25: Bill Dispenser Operation: (Bill Dispenser Device Is Optional)

    (more than 1 dispenser can be installed). Liquidate and refill required number of bills to the dispenser(s) cassette. Step 4: When finish bill refilling, push [Close] button to go back to Maintenance page (3). © 2014 - 2024 Parktron Technology Ltd.

  • Page 26: Install Paper Roll On Thermal Printer

    The protruded paper section will then be cut off and the blinking LED light for out of “paper” will be off. © 2014 - 2024 Parktron Technology Ltd.

  • Page 27: Solutions To Frequent Encountered Problems

    4.6 Receipt not printed: Push the [Feed] button on the thermal printer to check if thermal paper is normally feeding to the printer. © 2014 - 2024 Parktron Technology Ltd.
