Jump Starter 12000mAh TX-120
The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar "Konformitätserklärung"). Before using the
device the first time, please read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
This device has a rechargeable battery. It must be fully charged before first
use. NOTE: Charge the battery of the device every 2–3 month if it is not used!
Important Hints * This device is only suitable for CARS (12V) !
This device has 5 indicator lights (= LED). When only 3 LEDs are shining, or
less, then do NOT use the device to start your car! But you can use it for
charging digital devices.
success, stop starting it. Disconnect the device to avoid damaging other parts
of the car.
Check the power of the device 1x per month and also charge it to
ensure it can work in an emergency case.
time for charging. Maybe then it will not have enough power for starting a car
in an emergency situation.
loading other external devices.
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Enjoy your product. Share your experience and opinion on one of the
®
Technaxx
Free Email: support@technaxx.de
When trying to start your car more than 3x without
Device shuts down automatically when it is not
well-known internet portals.
Hints for Environment Protection: Packages materials are
raw materials and can be recycled. Do not disposal old devices
or batteries into the domestic waste. Cleaning: Protect the
device from contamination and pollution (use a clean drapery).
Avoid using rough, coarse-grained materials or solvents/
aggressive cleaner. Wipe the cleaned device accurately.
Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr.
105, 60388 Frankfurt a.M., Germany
* User Manual
Do NOT use the device all the
Warranty 2 years
Advertisement
Related Manuals for Technaxx TX-120
Summary of Contents for Technaxx TX-120
- Page 1 Jump Starter 12000mAh TX-120 The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the device the first time, please read the user manual carefully. Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line and 42 cent/minute from mobile networks).
- Page 2 –10°C up to +60°C Weight / Dimensions 400g / (L) 16.2 x (W) 8.5 x (H) 3.0cm Jump Starter 12000mAh TX-120, Battery clamps with cable, Micro USB charging cable, Package contents Cigarette lighter socket with barrel connector, Adapter for the cigarette lighter, Home socket...
- Page 3 Product overview For 12V USB cable Input Battery clamps vehicle connection products Barrel connector 5.5 x 2.1mm 6 Micro USB DC5V/2A Input port DC12V/10A output DC15V/1A input (home USB Quick Charge DC5V/2.4A charger); DC12V/1A input (car output charger) Jump start socket for clamps 3 USB DC 5V/2.4A output port (EC5) 4 Switch button On/Off...
-
Page 4: Green Led
Charging by the USB charger cable Plug the USB charger cable to any working USB output port. Connect the Micro USB to the 5V/2A Input port of the TX-120. If all 5 LEDs are lit (that means the device is fully charged) disconnect the device to save the power. - Page 5 LEDs are OFF, charging power is about 10-20% NO LED is lighting, balance power is about 0%. (4) While charging Connect the charger with the TX-120 and the indicator light is flashing. LED flashes, charging power is ~0%–10% LED flashes, charging power is ~10%–20% LED flashes, charging power is ~20%–40%...
- Page 6 TX-120, neither charge any other devices over the USB connection, nor charge the TX-120 itself. To protect the TX-120 and keep its long lifetime, make sure the power of the TX-120 always is ≥60% when using it to start a car. Positiv Negativ start the car First (1.)
-
Page 7: Green Led On
BOOST button. Wait until the GREEN LED illuminates steadily, and then start the engine. [BOOST button = if the car battery is empty, pressing this button manually will allow the car to start if the TX-120 has more than 60% charge capacity.]... - Page 8 5V/9V USB output (blue) of the TX-120. Connect the other end of the data cable to the digital device that needs to charge. Then press the switch button. The TX-120 recognizes electronic product’s suitable parameters. The indicator lights are on and charging begins.
- Page 9 However, we suggest to recharge it every 2–3 months. How long is the lifetime of TX-120? About 3–5 years. How many times can TX-120 jump start the vehicle if it is in full charged? approx. 20 times. No response when pressing the switch button (On/Off) of TX-120 Reason: maybe low voltage protection of TX-120 is started Solution: plug in TX-120 to charge it.
- Page 10 Once the blue EC5 connector of the clamps is connected to the EC5 port of the TX-120, NEVER (!) connect the two clamps together as this will cause a short circuit.
