B889 - Fan Fold Unit
B889: FD6500A (Fan Folder)
B890-17/-27: FD6500B (Fan Fold Unit)
.
Slide 1
PURPOSE OF THE SECTION
The mechanisms of the optional Fan Fold Unit will be explained.
In the 'video' folder of this course, there are four videos to illustrate how the
Fan Fold Unit works. There is also a .doc file that contains a commentary.
Please use these for your training.
1
Advertisement
Table of Contents
Related Manuals for Ricoh B889
Summary of Contents for Ricoh B889
- Page 1 B889 - Fan Fold Unit B889: FD6500A (Fan Folder) B890-17/-27: FD6500B (Fan Fold Unit) Slide 1 PURPOSE OF THE SECTION The mechanisms of the optional Fan Fold Unit will be explained. In the ‘video’ folder of this course, there are four videos to illustrate how the Fan Fold Unit works.
- Page 2 B889 - Fan Fold Unit OVERVIEW Slide 2...
-
Page 3: Model Details
B889 - Fan Fold Unit Model Details The FD6500A can be installed with the B286 and D046/D049. When installing with D046/D049, it is necessary to install the Bridge Unit BU6500 (D407). B890-17/-27: FD6500B (Fan Fold Unit) must be connected with B890-57 (Transport and Cross Unit). - Page 4 B889 - Fan Fold Unit What is the Fan Fold Unit? The Fan Fold Unit receives output from the copier, folds it, and feeds it out to the exit at the bottom rear of the unit. Outputs can also go...
- Page 5 B889 - Fan Fold Unit Optional Manual Feeder Manual Feeder Main Machine Fan Fold Unit An optional manual feeder unit can be attached to the top of the Fan Fold Unit. Outputs made previously (or even on another machine) can be fed from this manual feeder through the Fan Fold Unit, and these outputs will be folded.
- Page 6 B889 - Fan Fold Unit Fan Fold Unit Power Switch Heater Switch Exit for Folded Output Exit for Straight- Tray for Straight- Tray for Folded Output Through Output Through Output Slide 6 Heater Switch: Turn this on manually when humidity is high, to prevent paper from wrinkling.
-
Page 7: Turning On The Power
B889 - Fan Fold Unit Turning on the Power The power on/off sequence is important. To turn the Fan Fold Unit on 1. First, switch on the Fan Fold Unit. 2. Next, switch on the main machine. The Fan Fold Unit must be turned on first. Otherwise, the Fan Fold Unit will not recognize the main machine. -
Page 8: Operation Modes
B889 - Fan Fold Unit Operation Modes If the manual feeder is installed, there are three operating modes. Full operation mode System offline mode Independent offline mode Slide 8... - Page 9 B889 - Fan Fold Unit Full Operation Mode The main machine and Fan Fold Unit are both powered on and online. If the Online indicator is not lit, press the Online/Offline button to put the folder online. Paper feeds from the main machine.
- Page 10 B889 - Fan Fold Unit System Offline Mode The main machine and Fan Fold Unit are both powered on, but the folder is offline. If the Online indicator is lit, press the Online/Offline button to take the folder offline. Each unit can be used independently of the other.
- Page 11 B889 - Fan Fold Unit Independent Offline Mode The main machine is turned off, but the Fan Fold Unit and manual feeder are turned on. If the Online indicator is lit, press the Online/Offline button to take the folder offline.
-
Page 12: Important Points
B889 - Fan Fold Unit Important Points - 1/2 The Fan Fold Unit can handle plain paper only. Do not feed translucent paper or OHP transparencies through the Fan Fold Unit. If the humidity at the work site is extremely high, turn on the heater switch of the Fan Fold Unit. - Page 13 B889 - Fan Fold Unit Important Points - 2/2 When a fan fold is adjusted, the last surface will be shorter than the others, because the lengths of the others have been increased. For example, if fan folding is increased by +0.05 inches for a job where three folds are done to create four surfaces, +0.5 will be added to the first 3 surfaces but the last surface...
- Page 14 B889 - Fan Fold Unit Components Slide 14 See the component list in the service manual. In the part names, (R) means Rear, and (F) means Front. This is necessary because there are two folding mechanisms, one towards the front of the...
-
Page 15: Drive Layout
B889 - Fan Fold Unit Drive Layout Transport Motor Fan Fold Motor Fan Fold Motor Folder Plates Fan Fold Rollers Slide 15 The transport motor controls the rollers in the paper path through clutches. The two fan fold plate motors control the movement of the folder plates, which form the folds in the paper. -
Page 16: Firmware Update
B889 - Fan Fold Unit Firmware Update - 1/2 Prepare IC card with new version of firmware. Switch off main machine. Switch off Fan Fold Unit. Remove left upper cover and lower left cover. Insert IC card into slot of MCU board as shown at left. - Page 17 B889 - Fan Fold Unit Firmware Update - 2/2 During installation: LED1 - Flashes; LED2 - On; LED3 - Off Installation completed: LED1 - Flashes; LED2 - Off; LED3 - Off When LED2 goes off, switch off the Fan Fold Unit.
- Page 18 B889 - Fan Fold Unit DETAILS Slide 18...
- Page 19 B889 - Fan Fold Unit Feed Path Straight- Junction Straight-through Mode through Gate Sensor Solenoid The junction gate solenoid stays off, and the path that goes down to the folder is blocked. Paper goes past the straight-through sensor, and out of the machine without being folded.
- Page 20 B889 - Fan Fold Unit Feed Path Junction Folding Mode Gate Solenoid Relay Sensor-1 The junction gate solenoid turns on, and the path that goes down to the folder opens. Paper goes down to the folder mechanism, past relay sensor 1.
- Page 21 B889 - Fan Fold Unit Folding - 1/8 Fan Fold Fan Folder Plate (R) Entrance Sensor Fan Fold Plate Motor (R) When the paper’s leading edge passes the entrance sensor, fan fold plate motor (R) turns on. This lowers the fan fold plate (R).
- Page 22 B889 - Fan Fold Unit Folding - 2/8 Fan Fold Plate Fan Fold HP Sensor (R) Plate (R) Fan Fold Rollers (F) Fan Fold Plate Motor (R) Fan Fold LED (F1) and Sensor (F2) Fan fold plate (R) guides the paper between fan fold rollers (F).
- Page 23 B889 - Fan Fold Unit Folding - 3/8 Fan Fold Fan Fold Plate Motor (F) Plate (F) Fan Fold Rollers (R) Then the fan fold motor changes direction, and the fan fold rollers move the paper back. Fan fold plate motor (F) turns on. This lowers fan fold plate (F).
- Page 24 B889 - Fan Fold Unit Folding - 4/8 Fan Fold LED (R1) & Sensor (R2) When the fold passes between the fan fold LED (R1) and the fan fold sensor (R2), a pulse count begins. Slide 24...
- Page 25 B889 - Fan Fold Unit Folding - 5/8 Fan Fold Plate Fan Fold HP Sensor (F) Plate (F) Fan Fold Plate Motor (F) After the leading edge is fed the correct distance, fan fold plate motor (F) reverses and the fan fold plate (F) lifts. It stops when the HP sensor detects the edge of the plate.
- Page 26 B889 - Fan Fold Unit Folding - 6/8 Fan Fold Plate (R) Fan Fold Plate Motor (R) Fan fold plate motor (R) turns on. This lowers fan fold plate (R). The plate pushes the paper between the fan fold rollers (L). This makes the second fold.
- Page 27 B889 - Fan Fold Unit Folding - 7/8 The second fold is made. The process continues as described earlier. Slide 27 The cycle repeats until all the folds are completed: The fold plate motors alternate the raising and lowering of the fold plates to push the paper into the front and back fan fold rollers that form the folds.
- Page 28 B889 - Fan Fold Unit Folding - 8/8 Fan Folder Entrance Sensor Fan Fold Rollers (R) When the trailing edge of the paper passes the fan folder entrance sensor, there are no more folds to make. The fan fold rollers feed the folded output out of the Fan Fold Unit.
-
Page 29: Drive Mechanism
B889 - Fan Fold Unit Drive Mechanism Fan Fold Motor Fan Fold Rollers (R) Fan Fold Rollers (L) The fan fold motor drives the two pairs of fan fold rollers through gears and timing belts. Slide 29 The diagram also shows the LED/sensor pairs that detect when paper comes out through the fold rollers. - Page 30 B889 - Fan Fold Unit Do Not Adjust These Knobs These knobs control the pressure that is applied by the fan fold rollers. These are adjusted at the factory. DO NOT ADJUST IN THE FIELD. Slide 30...
- Page 31 B889 - Fan Fold Unit Do Not Adjust these Screws These screws adjust the fan fold rollers. These are adjusted at the factory. DO NOT ADJUST IN THE FIELD. Slide 31...
- Page 32 B889 - Fan Fold Unit Types of Folding - 1/2 A: Long Fold The folded edges are aligned B: File Fold The folded edges are aligned. The leading edge protrudes from the bottom, so that the output can be filed in a ring binder.
- Page 33 B889 - Fan Fold Unit Types of Folding - 2/2 Types C and D are adjusted folds. This ensures that the surfaces at the top and bottom of the stack are always the longest, with smaller folds hidden inside the stack.
- Page 34 B889 - Fan Fold Unit Slide 34...
