- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 803402 BOOKCASE REVISION 0 : 06/16/2020 REVISION 1 : 06/22/2020 PAGE 1 OF 8 COASTERFURNITURE.COM...
-
Page 2: Parts Identification
803402 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. -
Page 3: Hardware Identification
803402 ITEM: ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION BACK FRAME HARDWARE IDENTIFICATION SHORT BOLT 8PCS (1/4" x 12mm SR) MEDIUM BOLT 8PCS (1/4" x 25mm SR) LONG BOLT 4PCS (1/4" x 45mm SR) SCREW 8PCS (7 x 50mm) LEVELER 4PCS (1/4" x 12mm BLK) - Page 4 803402 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 4 OF 8 COASTERFURNITURE.COM COASTERFURNITURE.COM...
- Page 5 803402 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 PAGE 5 OF 8 COASTERFURNITURE.COM...
- Page 6 803402 ITEM: ASSEMBLY INSTRUCTIONS STEP 5 STEP 6 COMPLETE PAGE 6 OF 8 COASTERFURNITURE.COM...
- Page 7 803402 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 667 X 356 X 1715 H (MM) Product Size : 26 " X 14" X 67 " 374mm " 1715mm 323mm " 374mm " " 597mm " 374mm " 120mm 627mm " "...
- Page 8 205443 803402 ITEM: ANTI-TIPPING INSTALLMENT INSTRUCTIONS FURNITURE TIPPING RESTRAINT WARNING Injury may result from tipping furniture. This restraint may protect against tipping furniture. Do not allow children to climb on furniture. This restraint is not a substitute for proper adult supervision.
