VisionAid CLOVER 6 User Manual

Handheld video magnifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CLOVER 6
Handheld Video Magnifier
User Guide

Advertisement

Table of Contents
loading

Related Manuals for VisionAid CLOVER 6

Summary of Contents for VisionAid CLOVER 6

  • Page 1 CLOVER 6 Handheld Video Magnifier User Guide...
  • Page 2 Rev A-2 Contents Precaution ................. 1 Quick Start................. 4 Overview ................4...

  • Page 3: Table Of Contents

    Compositions ..............7 Accessories ...............13 Stand .................18 Handle ................19 Operation ........22 Power Button ........22 Settings Menu ........24...
  • Page 4 Magnification ........27 Brightness ......... 28 Color Mode ........29 Lighting ..........31 Freeze ..........32 Image Storage ........33...
  • Page 5 Playback .......... 37 Multi-Selection ........41 Line and Mask ........44 Live Panning ........47 Focus Control ........48 USB Transfer ........51...
  • Page 6 Power Frequency ........51 Memory ........... 52 Auto power saving ........53 Restore ..........53 Hardware Reset ........54 Troubleshooting ......54...
  • Page 7 The unit does not turn on ......55 Black screen or White screen ......56 The image does not change ......57 Smudges or blemishes on the screen ....58 Specifications ......59...
  • Page 8 Precaution Before using CLOVER 6 for the first time, you must charge its battery. Refer to Battery and Charging section for more details. Always operate the unit in a place where the temperature is between 10°and 35°C(50°and...
  • Page 9 95°F). Keep the unit away from wet areas, rain, and other sources of liquids. Do not submerge the unit.
  • Page 10 Do not attempt to repair the unit. Any unauthorized attempt will void the product warranty. Contact your distributor to service. Use the supplied power adapter and battery.
  • Page 11 Quick Start Overview Thank you for purchasing CLOVER 6. CLOVER 6 is a handheld video magnifier, and all operations are supported by the high contrast tactile buttons. Equipped with the 1080P FHD touch screen,...
  • Page 12 hand gesture provides easier and more natural way for certain features. Dual 13M cameras and fast switch mechanism to fulfill the full-range distance viewing requirement. When stand on the table, amazing details reveal with 2-35 times lossless magnification.
  • Page 13 The handle is flexible enough to be rotated to any angles and satisfy all holding requirements, which is also friendly for left hand user. Transform the handle into stand for comfortable desktop reading.

  • Page 14: Compositions

    Compositions...
  • Page 15 1. LCD screen 2. Freeze 3. Zoom In 4. Zoom Out 5. Enhanced Color...
  • Page 16 6. Near View Camera 7. Distance View Camera 8. LED Lights 9. Handle...
  • Page 17 10. Power Button 11. Charging Port...
  • Page 18 12. Micro SD Card Slot 13. USB Port 14. HDMI Output...
  • Page 19 User Manual Power Adapter Cleaning Cloth...

  • Page 20: Accessories

    Strap Pouch HDMI Cable Accessories Charging the battery Connect the supplied power cable to the unit’s charging port, and connect the power adapter into an AC outlet to start charging.
  • Page 22 Power LED ❑ Charging when the unit is off, the power LED will be green, and then auto turn off when fully charged. A fully Charging will take about 2.5 hours, and will support the unit working continuously for about 3 hours ❑...
  • Page 23 ❑ When the unit is on and the power adaptor is not connected, the power LED will be green when the battery is high and will be red when the battery is low. When the red light starts to flash, you will need to charge the battery ❑...

  • Page 25: Stand

    Stand Unfold the stand as the following figure shows.

  • Page 26: Handle

    Handle Rotate the handle as the picture shows and hold it at your most comfortable position.
  • Page 28 When the handle is open as picture shows, the device will switch automatically from distance camera to near view camera.

  • Page 29: Operation

    Operation Power Button ❑ Press and hold the Power button for 2 seconds to turn on the unit when it is off.
  • Page 30 ❑ Press and hold the Power button for 2 seconds when it is on to get into choosing page: Sleeping Mode or Turn Off . Tap the Sleeping icon or no operation in 3 seconds to get into Sleeping Mode. When in Sleeping Mode, long press Power button for 3 seconds to wake up the unit.

  • Page 31: Settings Menu

    ❑ Press other buttons when holding the Power button will make combo function, refer to the following instructions for more details Settings Menu ❑ Slide the corresponding control bar to adjust volume/brightness.
  • Page 32 Volume Control Bar Brightness Control Bar ❑ Use the tap gesture on the specific icon to activate/inactivate the setting.
  • Page 33 Auto Focus LED Light Vibration Power saving Line/Mask Gallery...

  • Page 34: Magnification

    ❑ No operations for 8 seconds or short press the Power button to exit. Magnification ❑ Press the Zoom In button / Zoom Out button to increase/decrease magnification, and hold the button for continuous increasing/decreasing.

  • Page 35: Brightness

    ❑ In addition to the Zoom button, use the pinch and zoom gesture on the touchscreen to adjust the zoom level. • Magnification Range: 2x – 35x (near view) Brightness In addition to control bar, hold the Power button and press the Zoom In button /Zoom Out button to increase/decrease the screen brightness.

  • Page 36: Color Mode

    Color Mode A color mode is a pre-defined color combination. Full color mode is suitable for picture, map viewing, and enhanced contrast mode is combined with different foreground and background colors and can help to read clearly. ❑ Press the Enhanced Color button to cycle through the color combination list...
  • Page 37 ❑ Press and hold the Enhanced Color button for 3 seconds to enter the Customized Color Page, use the tap gesture to activate/inactivate the enhanced color combination. ❑ No operations for 8 seconds or tap the Exit icon or long press the Enhanced Color button to exit the Customized Color Page.

  • Page 38: Lighting

    ❑ Press the Power button + Enhanced Color button to quickly return to the full color mode. Lighting In addition to the setting menu, hold the Power button and press the Freeze button to turn on/off the LED lights.

  • Page 39: Freeze

    And the Left/right LED lights can be controlled separately by tapping the related icon Freeze Freezing an image on the LCD screen can be useful for further reading, and also further zooming in or zooming out or changing the color mode for a better view.

  • Page 40: Image Storage

    ❑ Press Freeze button to lock/unlock the image. ❑ For the locked image with increased magnification, you can use the gesture to navigate around freely. Image Storage ❑ Long press the Freeze button for 3 seconds to store the current image.
  • Page 41 ❑ The Voice Record icon will appear after the storage. Tap and hold the Mic icon to begin the recording and release the icon to finish. ❑ You can replay the recorded voice by pressing the Play Icon (or pressing the Freeze button ❑...
  • Page 42 latest record will be saved with the image. ❑ For a better recording quality, please approach to the Mic as the picture shows and speak aloud.
  • Page 43 ❑ No operations for 5 seconds or tap other inactive area or press the Power button to close. Note: When the saved images reach to the maximum capacity (2 GB, Memory Full icon appears),...

  • Page 44: Playback

    you will need to delete some pictures first in Playback mode before the next successful saving. Playback ❑ Press the Power button get into the Settings menu and tap the Gallery icon to enter the picture gallery. Page up/down the gallery by the slide bar on the right side of the screen (or press Zoom button) .
  • Page 45 ❑ Tap the picture to choose (or press Zoom button) . The thumb picture with the voice label can play the recorded voice by tapping the Voice icon on the top-right side. Tap again (or press the Freeze button ) to playback the picture. ❑...
  • Page 46 ❑ When in the gallery, select the target image which needs to be deleted, tap the trash icon and the same trash label will appear right on the image. Tap the trash icon again to delete or Power button /any other places on the screen to cancel. ❑...
  • Page 47 icon again to confirm or Power button /any other places on the screen to cancel. ❑ Pictures can be transferred to the external SD card when it is inserted. Choose the specific picture first and then tap the Transfer icon to start.

  • Page 48: Multi-Selection

    ❑ Long tap the Transfer icon for 3 seconds, all the pictures will be chosen and transferred to the external SD card. Multi-Selection ❑ When in the gallery, long tap on the specific picture(or long press the Freeze button ) to activate/inactivate the Multi-selection.
  • Page 49 ❑ With Multi-selection enabled,a small box will appear at the lower right corner of each picture. Tap (or use Zoom button and Freeze button ) to choose all the target pictures. Then multi-transfer or multi-deletion can be applied accordingly. ❑ Tap the corresponding the Trash icon /Transfer icon to to pop up the choose box.
  • Page 50 in the choose box to delete/transfer all the chosen pictures. Tap the Exit icon or press the Power button to back to the multi-selection. ❑ Long tap on the screen or tap the Exit icon again( press the Power button or long press the Freeze button )to exit the multi-selection mode.

  • Page 51: Line And Mask

    Line and Mask Press the Locate icon to activate the Line/Mask function. Tap the icon switches among different modes. The icon will disappear automatically in 8 seconds with no operation or press Power button twice.
  • Page 52 The function below can only be achieved with the Locate icon appears. Without the icon, the live panning is usable. One horizontal line ⚫ ❑ Use finger to slide up/down on the screen to change the position of the line; left/right to decrease/increase the width of the line.
  • Page 53 ❑ Use finger to slide left/right to change the position of the line; up/down to increase/decrease the width of the line. ⚫ Horizontal mask ❑ Use finger to slide up/down to change the position; left/right to narrow/enlarge the distance between the masks.

  • Page 54: Live Panning

    ❑ Use finger to slide left/right to change the position of the masks, and slide up/down to enlarge/narrow the distance between the masks. Live Panning In the higher zoom level, use slide gesture to navigate the image for seeing more without moving the paper.

  • Page 55: Focus Control

    ❑ Quickly tap the image center twice to re-center the image. ❑ Quickly tap the image edge twice to jump to the start/end point. Focus Control The autofocus system works well in the most situations. In addition, some methods are provided to control the focus.
  • Page 56 ❑ Tap on the screen for 2 seconds to trigger the focus manually. HDMI Output Connect to the external screen for a better and larger viewing.

  • Page 58: Usb Transfer

    USB Transfer Connect the device to the PC via USB cable. The pictures can be transferred from the device to the Power Frequency Power Frequency provides the options of 50HZ and 60HZ power frequency according to customer region.
  • Page 59 Long press the Power button + Enhanced color button for 3 seconds can adjust the frequency. Memory The unit will memorize automatically the most recent settings such as color mode, magnification, beep when power off normally and use them in the next power on...
  • Page 60 Auto power saving If no operation and no moving for over 5 minutes, the unit will get into Sleeping mode automatically and will turn off in 10 minutes. Restore ❑ Hold the Freeze button and the Enhanced color button at the same time for 3 seconds to reset...
  • Page 61 to the default factory settings. Auto power off when resetting is done. Hardware Reset When the unit is hung, press the Power button +Zoom In button + Zoom Out button at the same time to trigger the hardware reset.
  • Page 62 Troubleshooting The unit does not turn on • Connect to the power adapter • Charge the battery...
  • Page 63 Black screen or White screen • If the unit is sitting on a flat pure surface, the screen may be black or white, Lift the unit off to ensure change happens. • Adjust the magnification • Adjust the color mode •...
  • Page 64 • Restart the unit The image does not change • If the unit enter the freeze mode, the image will not change • Press power button to check the current status • Restart the unit...
  • Page 65 Smudges or blemishes on the screen • Adjust brightness • Clean the LCD screen and camera Please contact your local distributor if problem is not solved...
  • Page 66 Specifications • Display: 5.5 inch IPS touch screen, anti-glare Screen Resolution: 1920*1080...
  • Page 67 • Camera: Dual 13M auto-focus Camera Video Resolution: 1920*1080 • Magnification： Approximately 2x ~ 35x • Color Mode： True color Up to16 user-defined Enhanced Colors • Brightness: LCD brightness adjustable • Video Mode: Near-view, Distance-view...
  • Page 68 • Vibration: Screen vibration feedback On/Off control • Snapshot: Image Storage and Playback Storage capacity: approximately 2GB • Locate: Reading Line/Mask function • Size: <= 160*91*21mm (Device folded) • Weight: <270 grams (Battery included) • Battery： Nearly 3 hours continuous use...
  • Page 69 Charges in approximately 2.5 hours • Power Adapter Input: 110-240V; Output: 5V/3A...
