- Page 1 Multi-DC Power Distribution Box LDG Electronics 1445 Parran Road, PO Box 48 St. Leonard MD 20685-2903 USA Phone: 410-586-2177 Fax: 410-586-8475 ldg@ldgelectronics.com www.ldgelectronics.com...
- Page 2 LDG pioneered the automatic, wide-range switched-L tuner in 1995. From its laboratories near the Nation's Capitol, LDG continues to define the state of the art in this field with innovative automatic tuners and related products for every amateur need.
- Page 3 Ok, but at least read this one section before you transmit: 1. Connect the Multi-DC’s input to a source of DC power between 12 and 15 volts DC using the supplied cable. The power supply should be able source 3 amps or higher.
- Page 4 The Multi-DC panel has seven coaxial DC jacks: one input and six outputs. All are 2.5 by 5.5 mm, the standard size for most LDG products. Cables for each are provided.
- Page 5 Installation The Multi-DC is intended for indoor use only; it is not water resistant. If you use it outdoors (Field Day, for example) you must protect it from rain. Position your Multi-DC in a convenient spot on your operating desk, anywhere within reach of its interface cables.
- Page 6 Care and Maintenance Your Multi-DC is maintenance-free. The outer case may be cleaned as needed with a soft cloth slightly dampened in a mild household cleaning solution. As with any modern electronic device, your Multi-DC can be damaged by temperature extremes, water, impact or static discharge.
