TOURNAMENT ICE
8Ft-Gold Standard Manual Score Home Air Hockey Game Assembly Instructions / Manual
Thank you for purchasing a Gold Standard Games product. All of us at Gold Standard Games want you to be
completely satisfied with your game. Please feel free to contact us for help with the assembly of your product
or in the event you require any parts or other information.
989-893-1739 or
877-893-1739 or online at:
Tools Required:
1/2" Wrench or Socket
5/32" Allen Key Wrench (Supplied)
Phillips Head Screwdriver
Level
Components Received:
Game Box
8HMS-W01-MSLB - 8Ft-Gold Standard Manual Score Home Air Hockey Game
2 – 306-0006-0 521 Key For Side Access Door
Leg Box
PX-LAA-0
201-0291-0
201-0293-0
210-0063-0
210-0393-0
301-0020-0
210-0350-0
003-0002-0
003-0003-0
003-0008-0
205-0194-0
301-0167-0
210-0396-0
www.gold-standard-games.com
Leg Assy.
MR-Red Air Hockey Pucks 3 1/4
MR-White Air Hockey Mallets
Shelti Warranty Card-All Games
Manual Score Assy. Instructions
5/16-18x1 1/2" Hex Head Bolt
Sanding Disk 6"x180 Grit
Red Score Beads
Black Score Beads
Score Posts-Manual Score H.A.H
Score Rods-Manual Score H.A.H.
1/4"-20x1 1/4" Flat Hd. Socket Bolt
5/32" Allen Key Wrench
4
2
2
1
1
12
2
7
7
4
2
4
1
1
Advertisement
Table of Contents
Summary of Contents for Gold Standard Games TOURNAMENT ICE
- Page 1 8Ft-Gold Standard Manual Score Home Air Hockey Game Assembly Instructions / Manual Thank you for purchasing a Gold Standard Games product. All of us at Gold Standard Games want you to be completely satisfied with your game. Please feel free to contact us for help with the assembly of your product or in the event you require any parts or other information.
- Page 2 Assembly Instructions Step #1: Place the Gold Standard Air Hockey game on its side. Note: Keep the arrow stickers pointing up. Remove the banding and the top of the box. Step #2: Slide the air hockey game partially out of the box, slightly tip the game and remove the bottom of the box and the top side and end fillers.
- Page 3 Step #5: Remove the 4 – Score Posts, 2 – Score Rods, and 14 Score Beads from the leg box. Assemble 6 black and one red score bead on a score rod. Assemble 6 red and one black score bead on the other score rod. Slide the score posts on either ends of the score rods and bolt the score assembly to the side top rails using the ¼-20 Flat Allen Head Bolts.
- Page 4 GOLD STANDARD AIR HOCKEY MAINTENANCE TIPS Congratulations on purchasing a Gold Standard Games Air Hockey table – our tables are the very best quality tables on the market today. Here are some maintenance tips to ensure your table’s optimum player appeal and durability over the years to...
- Page 5 TABLE SURFACE REPAIR: Our laminate surface is the most durable on the market, but it still may be susceptible to damage over the air channels. A hard, sharp object (bottle, glass, mallet) smashed onto the surface over the air channel may cause a dent. However, dents in the laminate surface are easily repaired. Use clear epoxy to fill a dent in the surface.
