- Page 1 LUDES AIR 270 ASSEMBLY AND OPERATION INSTRUCTIONS...
-
Page 2: Safety Instructions
Safety Instructions This device is not to be operated by people with reduced physical, sensorial or mental capabilities or lack of experience and / or knowledge (including children). This device is a technical tool to be used in closed areas or receptacles. Protect your eyes and skin from UV light. - Page 3 Assembly Instructions general information The UV plant LUDES AIR 270 needs to be installed and operated in a horizontal position. The scope of delivery contains the assembly system. - Assembly should be carried out by authorized qualified staff only. The current electrical instructions (DIN 0100, BGR A3, BGV A3, u.a.) should be considered.
- Page 4 Operation Instructions scope of delivery: complete LUDES AIR 270 housing 230 V AC 50Hz power supply for UV ray supply voltage 3x UV-C lamp 90 W intended use: This product is intended for air disinfection and: ° has to be operated with 230 VAC 50Hz power supply °...
- Page 5 More electrical work is not carried out. Please contact the manufacturer or distributor !!! operating time counter – OTC ** This chapter is only relevant if the OTC configuration has been chosen ** The system operates as a time counter. The counting starts if the system is switched on. With every switch on the so called “Startup Procedure” is carried out. To ensure operability the LED’s flashes one after another: red, yellow and green 1se- cond each.
- Page 6 procedure Option 1: Option 2: after removing it from the ceiling directly at the ceiling (recommended option) • disconnect the equipment • disconnect the equipment • pull the power plug • pull the power plug • remove the UV system from the ceiling •...
- Page 7 For warranty claims, we shall only be liable under the national legal warranty. The general terms and conditions of C+R Automations- GmbH are holding. We explicitly point out that the warranty does not apply to damage caused by: °...
- Page 8 C+R Automations- GmbH Nürnberger Straße 45 90513 Zirndorf Tel. +49 (0)911 656587-0 info@crautomation.de www.crautomation.de...
