- Page 1 pro-xi® 100 Workstation Integrator Cabling Guide...
- Page 2 Ross Video products are not designed, intended or authorized for use in any medical, life saving, or life sustaining applications or for any other application in which the failure of the Ross Video product could create a situation where personal injury or death may occur.
-
Page 3: Safety Notices
The material in this manual is furnished for informational use only. It is subject to change without notice and should not be construed as commitment by Ross Video Limited. Ross Video Limited assumes no responsibility or liability for errors or inaccuracies that may appear in this manual. - Page 4 Maintenance/User Serviceable Parts Routine maintenance to this Ross product is not required. This product contains no user serviceable parts. If the module does not appear to be working properly, please contact Technical Support using the numbers listed under the section “Contacting Technical Support”...
- Page 5 • If the connected computer system outputs an HDMI video signal, an HDMI-to-DVI-D adapter is required. • If the pro-xi 100 outputs are connected to HDMI monitors or KVM TX units that utilize HDMI, then the appropriate cable or adapter is required.
- Page 6 Dual-Head Direct Monitor Figure 3 illustrates an operator dual-head station with a direct connections to the pro-xi 100 system. Left Monitor pro-xi 100 Workstation Integrator Right Monitor VOC 1 VOC 2 Figure 3 Operator Station — Dual-Head Monitors Single Output (Single-Head) Direct Keyboard, Video, and Mouse Figure 4 illustrates the cabling required to connect a computer system to the pro-xi 100 system.
- Page 7 Dual Output (Dual-Head) Direct Keyboard, Video, and Mouse Figure 5 illustrates the cabling required to connect a computer system to the pro-xi 100 system. Computer for Controlled System 3.5mm Stereo Audio Cable pro-xi 100 Workstation Integrator AUDIO USB B-to-A Cable (5m max.) USB B-to-A Cable (5m max.)
- Page 8 Interconnect, Dual-Head Operator Station KVM Extender Figure 7 illustrates a dual-head operator station with the pro-xi 100 system and two KVM Extenders. Dual-Head KVM Extender (TX) 3.5mm Stereo Audio Cable AUDIO KVM Extender Pair (USB A-to-B Cable) pro-xi 100 Workstation Integrator...
- Page 9 Single Video (Single-Head) KVM Extender Figure 8 illustrates a single video operator station with the pro-xi 100 system and two KVM Extenders. Single-Video KVM Extender (RX) 3.5mm Stereo Audio Cable AUDIO Keyboard Mouse Input Input pro-xi 100 Workstation Integrator DVI-I or VGA Cable (5m max.)
- Page 10 Dual Output (Dual-Head) Using Single-Head KVM Extenders Figure 9 illustrates a dual video output station with the pro-xi 100 system and two KVM Extenders. Single-Head KVM Extender (RX) 3.5mm Stereo Audio Cable AUDIO Keyboard Mouse DVI-I or VGA Cable Single-Head KVM Extender (RX)
- Page 11 Dual Output (Dual-Head) Using Dual-Head KVM Extenders Figure 10 illustrates a dual video output station with the pro-xi 100 system and two dual-head KVM Extenders. Dual-Head KVM Extender (RX) 3.5mm Stereo Audio Cable AUDIO DVI-I or VGA Cable pro-xi 100 Workstation Integrator...
- Page 12 Contact Us At Ross Video, we take pride in the quality of our products, but if problems occur, help is as close as the nearest telephone. Our 24-hour Hot Line service ensures you have access to technical expertise around the clock. After-sales service and technical support is provided directly by Ross Video personnel.
