AurAir B1
Quick Start Guide
Overview
Flame Resistant Encasing
The AurAir encasing is flame resistant, making it
impossible to burn.
Wall Socket
This is a straight through wall
socket suitable for all countries
with a CEE 7/3 socket and
CEE7/7 plug. Countries like
Germany, the Netherlands,
Sweden, Norway and Finland.
Front Panel
When the AurAir is powered off,
only the side buttons are visible.
.
AurAir B.V
Display
All measured sensor values are displayed here. Several indicators are displayed on the right hand side,
like WiFi mode, measurement unit and countdown until next CO2 measurement indicator.
Display Button
Single click: Switch display off
Double click: Dim display
Long click: Update Firmware
Mode Button
Single click: Display graph
Double click: Display max/min values
Long click: Calibrate CO2 Sensor
Settings Button
Single click: Display cloud password
Double click: Disable password
Long click: Reset to factory settings
Issue Date: 2019/03
Version: 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B1 and is the answer not in the manual?

Questions and answers

Related Manuals for AurAir B1

Summary of Contents for AurAir B1

  • Page 1 Overview Flame Resistant Encasing Display The AurAir encasing is flame resistant, making it All measured sensor values are displayed here. Several indicators are displayed on the right hand side, impossible to burn. like WiFi mode, measurement unit and countdown until next CO2 measurement indicator.
  • Page 2 AurAir B1 Icons and Values Relative Humidity Value CO2 Value The relative humidity value is displayed on the lower left All measured CO2 sensor values are displayed here. Healthy values are displayed in green, mediocre values in side, followed by the symbol (%). Healthy values are yellow and unhealthy values in red.

  • Page 3: Display Button

    AurAir B1 DISPLAY button DISPLAY Button Single click: Switch display OFF. To switch display ON again, do another single click. Double click: Dim display. To switch display to FULL again, do another double click. Long click: Update Firmware. On the display the question is asked if you want to update the firmware.

  • Page 4: Mode Button

    AurAir B1 MODE button CO2 Graph All measured CO2 sensor values of the past 25 hours are displayed here in graphical form. Healthy values are displayed in green, mediocre values in yellow and unhealthy values in red. MODE Button Single click: Switch display to “CO2 Graph”...

  • Page 5: Settings Button

    AurAir B1 SETTINGS button Settings Various import network settings are displayed here, like admin password, cloud username and cloud password. In case you forgot the admin password, it can be seen here. The cloud username and password are needed to login into the cloud. Go to https://www.aurair.eu...

  • Page 6: Troubleshooting

    What should I do? Display the logo and waves Initialization of the AurAir failed. Pull the AurAir from the wall socket, wait for 20 seconds and for more than 3 minutes. put the AurAir back into the wall socket. The background of the For some reason the screen has not been cleared.
