- Page 1 Handheld Terminal (PDA) Light-sensitive Receiver Quick Guide...
- Page 2 Overview Light-sensitive Receiver light Display area USB interface Scan Scan HOME Scan Enter Back Button FN Button Power Button Microphone Scan window Flash lamp Speaker Camera Buckles for battery cover battery cover Connector for cradle Hot button / Custom button: 1.
-
Page 3: Removable Battery
Removable battery 1.Please turn the knob down to open the back cover. 2.Open the back cover in the direction shown 3.Remove the battery Please remove the positive and negative insulation, a yellow sticker on the battery before turning on tne device. - Page 4 Install TF/SIM card 1.Please insert the SIM card into the corresponding slots as shown below TF slot Micro SIM slot PSAM slot × 2 (Pls note: The handheld terminal is only support Micro SIM card, standard SIM card slot is for PSAM card)
- Page 5 Equipment charging THERE ARE 2 WAYS TO CHOOSE FOR CHARGING: 1.Directly by USB cable connecting with PDA. 2.By cradle to charge. Charging PDA Charging Battery 1.The battery can be fully charged after 4 hours of charging, and the standby time is over 48 hours. 2.Cradle can charge 1 battery and 1 terminal together.
- Page 6 Scan (optional) If your PDA have scan function, you can configure and test in our “scanner” app: 1.Please find the “scanner” app, and open it. ( As Pic 1) 2.In the ‘Content’ of app, you can press scan button to test the barcoding. 3.In the ‘Setting’, you can set up the scanning functions ( As Pic 1) Clear the...
- Page 7 Scanner App Output Mode: Broadcast mode：For obtaining value in the developed app； Editbox mode：Scan at any cursor； Keyboard mode：Enter data in the form of a simulated keyboard； Single mode：Support to clear previous scan...
- Page 8 Scanner App Additional content You can change the default terminator in this settings, CR and Tab *If you want to make the Symbology config such as barcode type enable/disable and check digit setting, you can kindly download the honeywell documents via the link below to set the decoding. Link for 1D version: http://bit.ly/honeywell-N431X-doc Link for 2D version:...
- Page 9 NFC (optional) If your PDA have NFC function, you can test the NFC with our demo app: 1.Please find the “NFC Scanner” app, and open it. ( As Pic 1) 2.In the home page of the app, you can read the NFC tags on NFC reading area.
- Page 10 LF 125K (optional) If your PDA have LF function, please operate it as below: 1.Please find the “LF EXAMPLE” app, and open it. ( As Pic 1) 2.In the home page of the app, you can read the LF tags on LF reading area. ( As Pic 1) ( As Pic2) LF reading area...
- Page 11 OTA(update online) Our PDA support OTA (update online) function, you can update the latest firmware by OTA, operate it as below: 1.Please enter into”Settings”— About phone. 2.Press ”System update” and enter into the updating firmware interface. 3.Press “Check now” to update the OS. * Currently our devices doesn’t support Android system upgrade ( As Pic 1) ( As Pic2)
- Page 12 FAQ: 1. How to restore factory settings? “Backup&reset” →“Factory date reset” Select“Setting”→ 2. Why can not power up the PDA? (1) If the new device does not turn on, please make sure the insulation sticker on battery has been removed. (2) It needs about 4s to press and hold the power button to turn on , so please hold the power button until the screen showing contents .
