Surprise sound SE-120 Owner's Manual

SE-120
Owner's Manual
Revision 1.0
Description
The SE-120 is a guitar speaker emulator and load box. The input is
connected to the speaker output of a guitar amplifier, and the outputs
are line or mic level filtered or unfiltered signals.
emulates the sound of a close-miced guitar speaker cab. There is an
internal dummy speaker load for amplifiers rated at up to 120 watts
and a THRU jack to connect speakers or dummy loads instead of
using the internal load.
Inputs and Outputs (on back panel)
INPUTS: These ¼" mono jacks are used to connect to the speaker
output of a guitar amplifier. Use the correct jack based on the output
impedance of the amplifier (4, 8 or 16 ohms). A speaker cable must
be used for this connection.
THRU IN: This ¼" mono jack is used as the input from the amplifier's
speaker out jack only when an external speaker or dummy load is
connected to the THRU OUT jack of the SE120. When a cable is
plugged into this jack the internal dummy load is disconnected. This
jack is not used if the internal dummy load is used.
THRU OUT: This ¼" mono jack is used to connect to a speaker or
dummy load. This jack is not used if the internal dummy load is used.
If the internal dummy load is used then nothing should be connected
to the THRU jack
UNFILTERED OUT: This ¼" mono jack is the line or microphone
level unbalanced and unfiltered output. If this output is used then
software or other hardware speaker emulation should be used.
FILTERED OUT: This ¼" mono jack is the line or microphone level
unbalanced and filtered output. If this output is used then software or
other hardware speaker emulation is not needed.
XLR: This jack is the line or microphone level balanced output. This
output can be used simultaneously with the other outputs. This output
can be switched between filtered, unfiltered and off (center position)
with the switch on the right side of the jack. The ground can be
floated using the switch on the left side of the jack.
TM
The filtered output
Controls (on front panel)
UNFILTERED VOL: These controls set the volume of the unfiltered
outputs. The toggle switch sets the coarse volume range and the
knob provides fine volume control.
FILTERED VOL: These controls set the volume of the filtered
outputs. The toggle switch sets the coarse volume range and the
knob provides fine volume control.
BRIGHT: This knob is used to control the high frequency response of
the filtered outputs. Turning clockwise mimics the effects of moving a
microphone closer to the center of a speaker.
CAB: This 3-way toggle switch controls the low frequency response
of the filtered outputs. The 3 settings mimic different speaker cabinet
sizes.
Operating Instructions
Connect the speaker output of a guitar amplifier to the appropriate
input jack on the SE-120 using a speaker cable.
If you want to use the internal dummy speaker load, use one of the
4, 8 or 16 ohm input jacks
If you want to use a speaker cab, use the THRU IN jack.
you must connect a speaker cab to the THRU OUT jack or
damage to the amplifier may result.
Connect one or more of the output jacks to a mixer, recording device
or computer. If using the FILTERED OUT ¼" jack it is recommended
to switch the XLR jack to the off setting (center position) by using the
toggle switch to the right of the XLR jack. This will improve the bass
response.
Set the output volume using the VOL controls. Set the volume as
high as possible without audible clipping.
Adjust the BRIGHT and CAB controls for the sound you want.
The SE-120 will become quite warm when using high power
amplifiers. Keep about 1" of clearance above and 0.5" below the unit.
Keep in mind that running amplifiers at maximum power will shorten
the life of the output tubes.
In this case
