Sony KDL-32EX40B Setup Guide (Operating Instructions) Setup Manual
Lcd digital color tv
Hide thumbs
Also See for KDL-32EX40B Setup Guide (Operating Instructions):
- Service manual (35 pages) ,
- Specifications (2 pages) ,
- Setup manual (50 pages)
Table of Contents
Advertisement
Quick Links
LCD
Digital Color TV
Setup Guide
(Operating Instructions)
KDL-40EX40B / 32EX40B
Setting up your TV
To watch TV
Additional Information
Sony Customer Support
U.S.A.: www.sony.com/tvsupport
Canada: www.sony.ca/support
United States
Canada
1.800.222.SONY
1.877.899.SONY
Please Do Not Return
the Product to the Store
4-180-189-
(1)
Advertisement
Table of Contents
Related Manuals for Sony KDL-32EX40B Setup Guide (Operating Instructions)
Summary of Contents for Sony KDL-32EX40B Setup Guide (Operating Instructions)
- Page 1 Digital Color TV Setup Guide (Operating Instructions) KDL-40EX40B / 32EX40B 4-180-189- Setting up your TV To watch TV Additional Information Sony Customer Support U.S.A.: www.sony.com/tvsupport Canada: www.sony.ca/support United States Canada 1.800.222.SONY 1.877.899.SONY Please Do Not Return the Product to the Store...
- Page 2 Motionflow, BRAVIA Sync, and trademarks or registered marks of Sony Corporation. “XrossMediaBar” is a trademark of Sony Corporation. “XMB” is a trademark of Sony Corporation and Sony Computer Entertainment Inc. “PlayStation” is a registered trademark and “PS3” is a trademark of Sony Computer Entertainment Inc.
-
Page 3: Table Of Contents
® The BRAVIA Full HDTV Experience Thank you for choosing Sony! Your new BRAVIA opens the door to the “Full HDTV Experience.” This document will help you get the most out of your TV. Please take a moment to register your TV at: U.S.A.: http://productregistration.sony.com... -
Page 4: Checking The Accessories
Checking the accessories Table-Top Stand (1)* Fixing screws for Table-Top Stand (M5 × 16) (4) Assembling Screws for Table-Top Stand (M5 × 16) (4) Remote control (1)* Size AAA batteries (2) *1 Assembling the Table-Top Stand is required. Refer to other leaflet to assemble the Table-Top Stand. -
Page 5: Setting Up Your Tv
Setting up your TV Some TV models are packaged with a detached Table-Top Stand so you can mount your TV to a wall right away. If you are not mounting the TV to a wall, you will need to attach the Table-Top Stand. -
Page 6: Connecting The Tv
Connecting the TV The following chart shows the high-definition (HD) and standard-definition (SD) video formats supported by your BRAVIA TV inputs. * For supported PC formats refer to the i-Manual. Recommendation of the F type plug 1.5 mm Projection of the inner wire from the connection part must be less than 1.5 mm. - Page 7 Shown with a Set Top Box with HDMI connection Set Top Box Cable System or VHF/UHF Antenna System CABLE / ANTENNA Shown with a Set Top Box with COMPONENT connection Set Top Box Cable Antenna VIDEO IN (MONO) AUDIO (Continued)
- Page 8 ® Shown with HD BRAVIA Sync™ Basic Connection *Rear of TV PC IN VIDEO IN AUDIO (MONO) AUDIO AUDIO CABLE / ANTENNA SAT IN DVD IN VIDEO 2/BD IN OPT IN OPT IN COAX IN AUDIO IN AUDIO IN AUDIO IN VIDEO 1 VIDEO VIDEO...
- Page 9 Shown with PC Connection with SD VCR/DVD Rear of TV PC IN VIDEO IN AUDIO PC/HDMI 1 AUDIO IN (MONO) AUDIO AUDIO CABLE / ANTENNA Splitter VCR/DVD Combo Cable/Antenna Notebook PC...
-
Page 10: Securing The Tv
An alternative way to secure the TV is with an optional Sony Support Belt Kit. Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV model name. -
Page 11: Organizing The Ac Power Cord
Organizing the AC power cord Running initial setup Complete your cable connections before proceeding with the Initial Setup. Connect the TV to your nearest power outlet. Press POWER on the TV. When you switch the TV on for the first time, the Language menu appears on the screen. -
Page 12: Using A Wall-Mount Bracket
Prepare the TV for the Wall-Mount Bracket before making cable connections. For product protection and safety reasons, Sony strongly recommends that you use the Wall-Mount Bracket designed for your TV and the installation should be performed by a Sony dealer or licensed contractor. -
Page 13: Installing The Tv Against A Wall Or Enclosed Area
Installing the TV Against a Wall or Enclosed Area Make sure that your TV has adequate ventilation. Allow enough space around the TV as shown below. Operate the TV at temperatures between 41°F and 95°F (5°C and 35°C). Installed with stand inches (30 cm) 4 inches... -
Page 14: To Watch Tv
To watch TV To watch programs GUIDE OPTIONS HOME To use the TV features Press HOME to display TV Home Menu/ to access TV Settings and other ™ media and network related content. Settings Picture & Display Adjust the picture and screen settings Turn on the TV. -
Page 15: To Use I-Manual
To use i-Manual Welcome to i-Manual “BRAVIA” TV Features Watching TV Introduces convenient features such as TV Guide, Favorites, etc. Playing a Disc Using the Home Menu You can find how to customize your TV settings, etc. • Images and illustrations may differ from what you are watching on this TV. Your BRAVIA TV comes with an on-screen manual. -
Page 16: Playing A Disc
Playing a disc Playback The Playback feature allows you to play a desired disc by simply inserting it into the disc slot. Insert a disc into the slot with the playback side facing away from you. For a video disc, playback starts automatically. -
Page 17: Troubleshooting
Press POWER on the TV to turn it off, disconnect the AC power cord, and contact Sony Customer Support (information provided on the front cover) with how many times the indicator flashes. When the STANDBY indicator is not flashing Check the items in the tables below. -
Page 18: How To Care For Your Bravia
How to Care for Your BRAVIA Safety is very important, please read and follow the safety documentation (Safety Booklet) separately provided. Unplug the TV and other connected equipment from the wall outlet before you begin cleaning your TV. • Wipe the LCD screen gently with a soft cloth. •... -
Page 19: Specifications
Specifications Model name KDL- 40EX40B System Television system NTSC: American TV standard ATSC (8VSB terrestrial): ATSC compliant 8VSB QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality) Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69 Analog Cable: 1 - 135 / Digital Cable: 1 - 135 Panel system LCD (Liquid Crystal Display) Panel... - Page 20 To Customers Sufficient expertise is required for TV installations. Be sure to subcontract the installation to a Sony dealer or licensed contractor and pay adequate attention to safety during the installation. For Customers in the United States Lamp in this product contains mercury.
-
Page 21: Safety Information About Built-In Bd Player
BD player, trying to insert another disc may cause malfunction. • Sound may jump or picture distortion may occur if a lens is dirty with dust. For repair, contact Sony Customer Support (information provided on the front cover). -
Page 22: Precautions About Built-In Bd Player
Precautions about built-in BD player • The TV has a region code located on the rear of the unit. • Do not use cleaning discs or disc/lens cleaners (including wet or spray types). These may cause the apparatus to malfunction. •... - Page 24 United States Software Canada Updates: NOTE: If your TV is connected to the Internet, you can check for software updates by selecting Settings, Product Support and then Automatic Software Update. © 2010 Sony Corporation Printed in U.S.A. http://productregistration.sony.com http://www.SonyStyle.ca/registration http://www.sony.com/tvsupport http://www.sony.ca/support...
