Allanson ACL-SC3C4A-DMX Quick Start Manual

ACL-SC3C4A-DMX
DMX/RDM 3CH CV DECODER (Sub-Controller)
W ith the standar d RDM remote device management protocol, it supports DMX512 signal bi-dir ectional
communication, achieves remote management of reading and writing DMX address (DMX mas ter controller
must recognize the RDM protocol). Equipped with DMX standar d XLR-3, green terminal interf ace. Realize
0-100% dimming or di erent lighting e ect; workabl e with singl e color, bi-c olor or RGB LED lamps.
1. Pr oduct Par ameter:
ACL-SC3C4A-DMX
Input Signal:
DMX512, RDM
Input Voltage:
12~24Vdc
Curr ent Load: 4A×3CH Max. 12A
Output Power:
Max. 144W/432W/576W(12V/36V/48V)
DMX512 Sock et:
XLR-3, Green Terminal

2. Product Size:

64mm
115mm
125mm
3. Con guration Diagram:
Green
Power Input LED Lamps
Connection Terminal
Sock et
(with ampli er
Sock et
function)
ACL-SC3C4A-DMX
warranty
5 years
0~100%
Dimming Range:
Working Temper atur e: -30°C ~65°C
Package Size:
L135×W70×H50(mm)
305g
Weight (G.W.):
1 2 2 1
3 3
1 2 3 4 5 6 7 8 9 10
DIP ON
Addres s XLR-3
Dip Switch
1
Dip Switch Operation:
4.
0
OFF
RDM Mode: The dip switch 1-10 ar e OFF.
1 2 3 4 5 6 7 8 9 10
1
ON
DIP 4 ON
0
OFF
DMX Mode:
1 2 3 4 5 6 7 8 9 10
1
ON
DIP 4 ON
0
OFF
Self-testing Mode:
1 2 3 4 5 6 7 8 9 10
1
ON
DIP 4 ON
4.1 How to set DMX addr ess via dip switch:
FUN =OFF ( the 10th dip swit ch
=OFF ) DMX
DMX addres s value=the total value of (1-9), to get the plac e value when in "ON" position,
otherwise will be 0.
E.g.1: Set Initial Addres s To 32. E.g.2: Set Initial Addres s To 37.
OFF
1 2 3 4 5 6 7 8 9 10
1 2 3
ON
DIP ON DIP
001+004+032=37

4.2 Self-testing Mode:

FUN =ON (
10th dip swit ch = ON) Self-tes ting Mode
the
1=on 2=on 3=on
Dip Switch 1-9=o
Self- test Static Static Static Static
Black Red Green Blue
Function
3 4 5 6 7 8 9 10
1 2
Static 7 Colors
Static Static
Cyan Jumping
Green Yell ow
Static
Static Static Static 7 Colors
Red Blue Purpl e White Smooth
[Attn] When se ver al dip switches ar e on, subjected to the highes t switch value .
As the gure above shows, the e ect will be 7 colors smooth at 7 speed level.

4.3 DMX Dimming Instruction:

Each DMX decoder occupied 3 DMX
addres ses when connecting the DMX consol e.
e.g., the default ed initial addres s is 1, please nd
their corr esponding relationships in the form.
ACL-SC3C4A-DMX
FUN=OFF (the 10th dip swit ch=OFF)
Setting DMX addr es ses with dip swit ch 1-9
FUN=ON (the 10th dip swit ch=ON)
Mode
E.g.3: Set Initial Addres s To 178.
OFF
1 2 3 4 5 6 7 8
4 5 6 7 8 9 10
ON ON DIP ON
002+016+032+128=178
4=on 5=on 6=on 7=on 8=on
Static Static
Static Static 7 Colors
Purpl e Cyan
Yell ow White J umping
OFF
For changing e ects (Dip Switch 8 9=on): /
ON
DIP switch 1-7 is used to realize 7 speed
levels. (7=on, the fas tes t level)
DMX Consol e DMX Decoder
CH1 0-255 PWM 0-100% (LED R)
CH1
CH2 0-255 CH2
PWM 0-100% (
CH3 0-255 CH3 PWM 0-100% (
2
www.allansonled.com
OFF
9 10
ON
9=on
7 Colors
Smooth
LED G)
LED B)
