Summary of Contents for DSIC DS5 Series
- Page 1 DS5 Series OS Update How-to Windows CE6.0 and Windows Embedded Handheld 6.5 (Classic & Professional) August 05, 2014 ISO 9001 Certified Quality Management System...
- Page 2 While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of printing, DSIC Co., Ltd. can assume to no liability for any errors. Changes and corrections to the information in this document might be incorporated in future release.
- Page 3 For the most current versions of documentation, see DSIC support Web site: http://www.mobilebase.co.kr Contact DSIC Support DSIC Co., Ltd. provides a technical support email account for you to report problems or to ask questions about your product. The support account is support_pda@dsic.co.kr For additional support, See the DSIC Web site: http://www.mobilebase.co.kr...
-
Page 4: Table Of Contents
Chapter 5: OS Update How-To ............................10 OS Update - Windows CE6.0/ WEH6.5/DS5/DS5 Wide respectively........10 OS Update from Windows CE6.0 to WEH6.5 (DS5)................10 OS Update from WEH6.5 to Windows CE6.0 (DS5) ................11 DS5 Series OS update how-to August 2014... -
Page 5: Chapter 1: Terminal
Charging LED Indicator Scanner Window Network LED Indicator 3,5” Display (Phone only) 4.3” Display Scan LED Indicator Micro phone Scan Triggers LCD Back Light Controller Reset button DS5 wide Power button Modifier LED Indicator DS5 Series OS update how-to August 2014... -
Page 6: Keypad
Keypad DS5 series comes with large numeric keypad including function 1~10, full alphanumeric keypad Numeric Keypad Full Alphanumeric Keypad DS5 Series OS update how-to August 2014... -
Page 7: Chapter 2: Install Micro Sd Card
As the micro SD card is consumable, the micro SD card end its days and may be not able to save data if you use it more than over certain times. In this case, replace micro SD card to buy a new one. DS5 Series OS update how-to August 2014... -
Page 8: Chapter 3: Operating Power Of The Terminal
If the terminal stops responding, try reset to kill running applications. To reboot the terminal press RESET button. Your data in storage will be retained in terminal while not saved data will be in lost. DS5 Series OS update how-to August 2014... -
Page 9: Chapter 4: Clean Boot
Nand folder RAM (excepting Nand) Factory reset Cleared Cleared Cleared , reset Clean Cleared Retained Cleared , reset Cold Retained Retained Cleared + Reset, (back up battery fully discharged) Warm reset Retained Retained Retained DS5 Series OS update how-to August 2014... -
Page 10: Chapter 5: Os Update How-To
4. While pressing and holding together, short press RESET key for a second to enter DSIC SD Download Screen. It will take a minute. When OS image is copied and installed in complete, DONE will be displayed on the screen. -
Page 11: Os Update From Weh6.5 To Windows Ce6.0 (Ds5)
RESET key for a 4. While pressing and holding second to enter DSIC SD Download Screen. It will take few minutes. When OS image is copied in complete, 100% will be displayed on the screen. When OS image is installed in complete, DONE will be displayed on the screen.
