Summary of Contents for HAMECO HV-47
- Page 1 HV-47 soundbar User Manual www.hameco.eu...
-
Page 2: Attentions
HV-47 user manual ATTENTION This manual introduces functions, installation and operations for this camera in details. Please read this manual carefully before installation and use. 1. How to use To prevent damage to this product or any product connected to it, this product can only be used within the specified range. -
Page 3: Table Of Contents
HV-47 user manual Attentions..................... 2 1. Quick Installation Instructions............4 1.1 Product Interface............... 4 1.2 Product Use................4 2. Product Overview................4 2.1 Product Introduction..............5 2.1.1 Dimension................5 2.1.2 Accessories................5 2.2 Product Features................ 6 2.3 Technical Parameters..............7 3. -
Page 4: Quick Installation Instructions
HV-47 user manual 1. Quick Installation Instructions 1.1 Product Interface Figure 1.1 Product Interfaces 1. Speaker 4. Power Switch 7. USB 3.0 2. Lens 5. Power 8. Bracket 3. Built-in Mic 6.Line In 1.2 Product Use 1) Installation: Fix the device to the wall, over the display screen or directly put it on the desktop. -
Page 5: Accessories
HV-47 user manual Figure 2.1 Dimension 2.1.2 Accessories Standard accessories in the box User Manual 5m USB2.0 Cable Remote Control Accessories Standard Power Adapter Packing List Wall Bracket www.hameco.eu... -
Page 6: Product Features
HV-47 user manual 2.2 Product Features Features with compact design, crystal clear audio and excellent video quality, it uses advanced AI intelligent algorithms, integrates multiple AI intelligent framing technologies such as facial detection, sound positioning, and voice tracking. It automatically frame the meeting participants and adjust focus area to present the best view. -
Page 7: Technical Parameters
HV-47 user manual • Wide FOV: With 120 °super wide view angle and non-distortion lens to easily cover all participants in the meeting room; • Low noise and High Signal-to-noise ratio: Low-noise CMOS effectively guarantees the ultra-high signal-to-noise ratio of the picture. Adopting ad- vanced 2D and 3D noise reduction technology to further reduce noise while ensuring image clarity;... -
Page 8: Product Use
HV-47 user manual Module Features Description Controller Remote Control Infrared remote control USB Interface 1*USB3.0 (Type-B), compatible with USB2.0 Audio Port 1*3.5mm linear input Physical Interfaces Power Connector HEC3800 power socket (DC12V) Wall Bracket Standard wall mount bracket 2. Product Use 3.1 Remote Instructions... -
Page 9: Menu Settings
HV-47 user manual 3.2 Menu Settings 3.2.1 Main Menu Press [MENU] button in MJPG, YUY2, NV12 or H264 compression encoding formats. 1) Language Move the pointer to (Language) in the main menu, press to select the language. 2) Setting... - Page 10 HV-47 user manual 3) Explosure In the main menu, move the pointer to (Exposure), and press [HOME] to enter the exposure page, as shown below. Mode: automatic, manual, shutter priority, brightness priority Exposure Compensation: on/off (only valid in auto mode) Compensation Level: -7~7 (only valid when “Exposure Compensation”...
- Page 11 HV-47 user manual 4) Color Move the pointer to (Color) in the main menu, and press [HOME] to get into the color page, as shown below WB Mode: automatic, manual, white balance, a key, specified color tem- perature AWB Sensitivity: high, medium,...
- Page 12 HV-47 user manual 6) Noise Reduction Move the pointer to (Noise Reduction) in the main menu, press [HOME] to get into the noise reduction page, as shown below. 2D Noise Reduction: 3D Noise Reduction: Settable: Auto, Off, 1-7 Off, 1-8 7) Version Move the pointer to (version) in the main menu.
- Page 13 HV-47 user manual 8) Restore Default Move the pointer to (Reset) in the main menu, press [HOME] to get into the reset page, as shown below. Notice: Color style and video format will not be restored to factory default...
-
Page 14: Maintenance And Troubleshooting
HV-47 user manual 4. Maintenance and Troubleshooting 4.1 Product Maintenance 1) If camera is not used for long time, please turn off power adapter switch and AC plug. 2) Use soft cloth or tissue to clean the camera cover. -
Page 15: Copyright Statement
HV-47 user manual 5. Copyright Statement All the contents in this manual and its copyright are owned by the company. No one is allowed to imitate, copy, or translate this manual without the com- pany’s permission. This manual contains no guarantee, standpoint expres- sion or other implies in any form.
