- Page 1 INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-48F-M AR-SC7P-96F-M AR-SC7P-144F-M AR-SC7P-192F-M...
-
Page 2: Scope Of Application
1. Scope of application This Installation Manual suits for AR-SC7P-xxxF-M Splitter Splice Closure (Hereafter abbreviated as FOSC), as the guidance of proper installation. AR-SC7P-xxxF-M splitter closure can install various kind of PLC or box splitter; it is especially for FTTH project. The scope of application is: aerial, underground, wall-mounting, handhole-mounting and duct-mounting. The ambient temperature ranges from -40℃ to +65℃ 2. Basic structure and configuration 2.1 Dimension and capacity Outside dimension (H×W×L) 323×192×345mm Weight (excluding outside box) About 4.0 kg Number of inlet/out ports Drop cable 24 pcs, Fiber cable 8 pcs Diameter of fiber cable Drop cable Φ5〜Φ9mm， fiber cable Φ8〜Φ20mm Capacity of FOSC Bunchy: 12-192cores 2.2 Main Components Name of components Quantity Usage Remarks Protecting fiber cable H× W×L FOSC cover 1 piece splices in whole 276×176×245mm Fixing heat shrinkable Fiber optic splice tray Max 16 trays protective sleeve and Bunchy: 6,12 cores (FOST) - Page 3 Name of components Quantity Usage Remarks Big gasket ring is used to seal FOSC cover and base. Sealing ring 1 piece Small gasket ring is used to seal entry/exit tube Fiber optic splice tray Use for fixing the fiber Configuration as 8 pcs (FOST) cable per requirement Protect elastic seal rings Plastic gasket 6 set from corruption After inject air, it is used for Configuration as pressure testing Pressure testing valve 1 set per requirement and sealing testing Fixing internal and external Configuration as Base 1 set structure per requirement 2.3 Main accessories and special tools Name of accesories Quantity Usage Remarks Heat shrinkable protective Protecting fiber splices ...
-
Page 4: Necessary Tools For Installation
Name of accesories Quantity Usage Remarks Buffer tube Hitched to fibers and fixed Configuration as with FOST, managing buffer. per requirement For the port of straight through Sealing tape 1 ring Enlarging diameter of fiber Insulating tape 1 roll cable for easy fixing 3. Necessary tools for installation 3.1 Supplementary materials (to be provided by operator) Name of materials Usage Scotch tape Labeling, temporarily fixing Cleaning Ethyl alcohol Cleaning Gauze 3.2 Special tools (to be provided by operator) Name of tools Usage Fiber cutter Cutting off fiber cable Strip off protective coat of fiber cable Fiber stripper Assembling FOSC Combo tools 3.3 Universal tools (to be provided by operator) Name of tools Usage and specification Band tape... -
Page 5: Installation Flow Chart
Name of tools Usage and specification Combination pliers Cutting off reinforced core Crossing/Paralleling screwdriver Screwdriver Scissor Waterproof, dustproof Waterproof cover Tightening nut of reinforced core Metal wrench 3.4 Splicing and testing instruments (to be provided by operator) Name of instruments Usage and specification Fusion Splicing Machine Fiber splicing Splicing testing OT DR Provisional testing Provisional splicing tools Notice: The above-mentioned tools and testing instruments should be provided by the operators themselves 4. Installation flow chart Open the enclosure Installing and fixing the splitter Determine length of fiber cable to be fixed and stripped inside FOSC Strip off protective coats of fiber cable and fiber Separate fiber cores and prepare work prior to fixing fiber cable... - Page 6 4. Installation flow chart Splice fiber and pigtail Install heat shrinkable protective sleeve and house fibers Separate fiber cores and prepare work prior to fixing fiber cable Check up comprehensively Assemble FOSC housing and fix FOSC 5. The process of installing FOSC 5.1 Step one-Open the closure Cleaning the locale and determine where to install the FOSC and then place fiber cables required. Check whether the main components and accessories have been well prepared inside the package. Open the closure 1- Demount hoop fixing bolt and pull hoop locking system out, then proceed in demounting the hoop. 2- Pull the FOSC cover upwards out, installation could begin. See Drawing 1 INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-xxxF-M...
- Page 7 Hoop (right) Hoop (left) Hoop locking system Locking spring Fiber holding trat Splice tray Fixing shelf for FOST Fixing device for reinforced core Big gasket ring Base FOSC cover Small nut (plastic) Drawing 1 5.2 Step two-Installing and fixing the splitter 5.2.1 Step one-Open the closure According to the customer's need to install, if you need to install a PLC optical splitter, the optical splitter can be installed in the card slot in the splitter tray, if you install more than 2 splitters, the splitter can be installed at different splitter tray. See drawing 2 Important issues: PLC should reserve enough fiber, and swirling the redundant fiber in the splitter tray. INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-xxxF-M...
- Page 8 Fiber Splitter tray Fiber Hoop locking system PLC splitter Fixing slot of heat shrinkable protective sleeve Drawing 2 5.3 Step Three - Determine length of fiber cable to be fixed and stripped inside 5.3.1 According to the requirement, the ports are installed with fiber cable or drop cable 5.3.2 The fibers which are in the FOSC are used for branching splice. The length of stripping cable show in 3-1 5.3.3 a part of fiber cable for straight through, a part for branching splice, The length of stripping cable show in 3-2 Important issues: 1- Reserve enough fiber cable. 2- Determine the length of stripping cable. 3- The customer can decide the stripping cable length by themselves if they have other requirement 100mm fixing length of fiber cable inside FOSC 1750mm length of protective coat of fiber cable to be stripped off 150mmlength of fiber with protective coat (from cable fixing point to FOST fixing point) 1600mmlength of protective coat of fiber to be stripped off...
- Page 9 120mm fixing length of fiber cable inside FOSC 150mm length of fiber with protective coat (from cable fixing point to FOST fixing point) 150mm length of fiber with protective coat (from cable fixing point to FOST fixing point) 1700 mmlength of protective coat of fiber to be stripped off Fiber cable Fusion with other fibers and be winded after being striped off) 2000mm length of protective coat of fiber to be stripped off Temp. locating mark Temp. locating mark (straight through after being winded) Drawing 3-2 5.4 Step four - Strip off protective coat of fiber cable and fiber 5.4.1 Strip off protective coat of fiber cable from the temp. Locating mark with the cutter and the stripper, please refer to Drawing 3 for stripping length. Stripping length also could be decided according to installation requirement. See Drawing 4 Important issues: If it is difficult to pull all the protective coat of fiber cable at one time, strip it off section by section to avoid fiber breakage. Entry terminal fiber cable Strip terminal fiber cable Temp. locating mark Cutter Drawing 4 5.4 Step Five - Separate fiber cores and prepares work prior to fixing fiber cable 5.5.1 Wind 2 layers of insulation tape on protective coat of fiber core for protection. ...
- Page 10 Important issues: 1. Inlet/outlet tubes are to be selected accurately to make it easy for splicing and sealing. 2. Reserve reinforce core for 40mm, then cut off the unnecessary Fiber Fiber with protective coat Fiber Fiber Adhesive tape Fiber with Reinforced core protective coat Fiber cable 5.6 Step Six - Encapsulate, fix fiber cable and reinforced core 5.6.1 Install the normal cable in the small port: according to the diameter of the cable, choose the suitable sealing ring. Demount the nut, gasket and sealing ring of the corresponding entry/exit tubes, insert them into fiber cable in sequence, and then insert fiber cables into entry/exit cable. Fix cable and reinforced core: according to the diameter of the cable, use the suitable hose clamp jammed in the slot of reinforced core device. Then put the hose clamp INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-xxxF-M...
- Page 11 on the cable, let the cable 5mm above the hose clamp, tighten the nut in order to fix the cable. After that, release the reinforced core device, through the core and screws. Finally put the small sealing gasket, gasket ring, nut through the tube, tighten the nut in order to seal properly. 5.6.2 Install the mini cable in the small port: First according to the mini cable way and put it into the sealing ring, fixed the mini cable reinforced core, and then together through cable access port, fixed mini cable components, then tighten the nut in order to seal properly. 5.6.3 The big port for straight splice and part branch: should be based on the actual installation of the cable diameter, use the appropriate double-hole sealing. Unscrew the two fastening screws, platen, double hole ring and washer, and then put the tube into the ports, At last put the gasket, double hole ring, and the plastic platen, and finally tighten two fastening screws to ensure sealing. 5.6.4 Uncutting cable and the fix the reinforced core: according to the diameter of the cable, choose the right hose clamp, jammed in the slot of reinforced core base. Then put the hose clamp on the cable, let the cable 5mm above the hose clamp, tighten the nut in order to fix the cable. After that, release the reinforced core plate, through the core and screws; fix the direct through cable in the storage tray. 5.6.5. Demount the nut of fixing device of reinforced core with special wrench (plastic one), set the reinforced core into fixing slot, tighten the nut, and retighten it with metal wrench (metal wrench to be provided by operator). See drawing 6. Important issues: tighten the reinforce core fixing screws. Reinforced core plate INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-XXXF-M...
- Page 12 INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-xxxF-M...
- Page 13 5.7 Step seven - Fiber splicing 5.7.1 Follow user manual of fusion splicing machine to splice fiber. Important issues: pay attention to the twist and bend of fiber 5.8 Step eight - Install heat shrinkable protective sleeve and house fibers 5.8.1 When having completed splicing the fibers, the first fiber ring should be housed on the farthest side of FOST, the remaining fiber should be winded, forming a ring with diameter not less than 60mm. then put it into FOST (Fiber Optic Splice Tray) together with heat shrinkable protective sleeve. ( Firstly fix heat shrinkable protective sleeve into the slot, then enlarge the diameter of fiber ring properly.) See drawing 7 Important issues: pay attention to the twist and bend of fiber 5.9 Step nine – Check up comprehensively 5.7.1 Follow user manual of fusion splicing machine to splice fiber. Important issues: pay attention to the twist and bend of fiber INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-xxxF-M...
- Page 14 INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-xxxF-M...
- Page 15 5.10 Step ten – Assemble FOSC housing and fix FOSC 5.10.1 Put the desiccant into the closure 5.10.2 Put FOSC cover on base directly. 5.10.3 Install plastic hoop between FOSC cover and the base, tighten hoop locking system, which is to be fixed by hoop fixing bolt then. 5.10.4 All nuts (plastic ones) of base need to be retightened once more. 5.10.5 FOSC installation (1) Wall-mounting: Installation of closure on the wall mounting accessories, then fixed on the wall by expansion screw. See drawing10 (2) Pole-mounting: Installation of closure on the pole accessories, then fixed on the pole with hose clamps. See drawing11 INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-xxxF-M...
- Page 16 INSTALLATION MANUAL HORIZONTAL FIBER OPTIC SPLICE CLOSURE AR-SC7P-xxxF-M...
