- Page 1 EXP8051 ALI 1449+1451 USER’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS CHAPTER 1 INTRODUCTION.......1 1.1 OVERVIEW..............1 1.2 SYSTEM FEATURES..........1 1.3 SYSTEM SPECIFICATION.........2 1.4 SYSTEM PERFORMANCE.........2 1.5 EXP8051 BOARD LAYOUT........3 CHAPTER 2 INSTALLATION........4 2.1 DRAM INSTALLATION..........4 2.2 SRAM INSTALLATION..........5 2.3 CPU INSTALLATION..........6 2.4 OTHER JUMPER AND CONNECTOR INSTALLATION ....................7 CHAPTER 3 SYSTEM BIOS SETUP....10... - Page 3 3.8 LOAD VALUES FROM CMOS......29 3.9 SAVE VALUES TO CMOS........30 RMA FORM...
-
Page 4: Chapter 1 Introduction
EXP8051 User’s Manual CHAPTER 1 INTRODUCTION 1.1 OVERVIEW The EXP8051 is complemented by a 1MB second level Write-Back cache providing workstation level computing performance , and SIMM sockets support up to 128MB of DRAM. EXP8051 motherboard offers outstanding capabilities .Four PCI Local Bus slots provide a high bandwidth data path for data-movement intensive function such as Graphics . -
Page 5: System Specification
1.3 SYSTEM SPECIFICATIONS Processor : INTEL PENTIUM CPU Clock : 60/66 MHz CPU Memory : 2MB to 128MB SRAM Configuration : 256KB/512KB/1MB BIOS Subsystem : PHOENIX/AWARD BIOS Additional BIOS Feature : Set Program Resides in ROM I/O Subsystem No. Slot : Four 16-bit ISA Bus & Four PCI 32-bit Additional Features Miscellaneous Connectors : Reset Button, Internal Battery Board Design :... -
Page 6: Exp8051 Board Layout
EXP8051 User’s Manual 1.5 EXP8051 BOARD LAYOUT · · · · · · · · · · SIMM SIMM SIMM 1 J P J P 7 J P 8 J P1 J P 9 J P1 PENTIUM J P1... -
Page 7: Dram Installation
INSTALLATION Before the system is ready to operate, the hardware must be set up for various functions of the system. To set up the EXP8051 main board is a simple task. The user only has to set a few jumpers, connectors and sockets. -
Page 8: Sram Installation
EXP8051 User’s Manual SIMM1+SIMM2 + SIMM3+SIMM4 = TOTAL Each group includes two SIMMs, each SIMM size can be 1,2,4,8,16,32MB, please install the same DRAM size in one group. 2.2 SRAM INSTALLATION J P 7 J P 8 J P1 J P 9... - Page 9 J P1 J P1 · · J P1 · · 256K 512K DATA RAM DATA RAM DATA RAM U17~ U24 U17~ U24 U17~ U24 32KX8 32KX8 64KX8 32KX 128KX8 ·· ·· ·· J P7 J P7 J P7 ·· ·· ··...
-
Page 10: Cpu Installation
J P1 J P1 J P1 · · · ·· J P1 · · · EXP8051 User’s Manual 2.3 CPU INSTALLATION J P 7 J P 8 J P1 J P 9 J P1 PENTIUM J P1 J P1 J P1... - Page 11 * : Default Setting...
- Page 12 EXP8051 User’s Manual 2.4 OTHER JUMPER & CONNECTOR SETTING · · · · · · · · · · SIMM SIMM SIMM 1 J P PENTIUM J P1 OTHER JUMPER DESCRIPTION J P1 J P1 5 J P1 J P1...
- Page 13 JUMP DESCRIPTION NORMAL JP 1 ·· JP 2 USE EXTERNAL BUILT IN BATTERY * BATTERY JP 3 · · POWER SUPPLY * · · JP 4 · · NORMAL FLASH ROM * · · · JP 6 DELAY NORMAL* ADS# ·...
- Page 14 EXP8051 User’s Manual CONNECTOR DESCRIPTION CONNECTOR PIN OUT SIGNAL NAME LED POWER NOT USED JP18 : GROUND KEY LOCK KEYBOARD INHIBITOR GROUND + 5V DATA OUT JP17 : DATA OUT SPEAKER DATA OUT JP16: GROUND RESET IN RESET KEYBOARD CLOCK...
-
Page 15: Chapter 3 System Bios Setup
SYSTEM BIOS SETUP PHOENIX BIOS SYSTEM CONFIGURATION SETUP Use the EXP8051 to record changes in your hardware and to control it's special features. The setup program uses a number of menus in which you can specify changes to your hardware and turn the special features on or off. -
Page 16: System Setup
EXP8051 User’s Manual Save Values to CMOS ¯ Move Enter Select F1 Help ESC Exit Save & Exit 3. Select an option by moving the highlight with your up-and- down arrow keys and press. <Enter>. 4. After making your changes, select Save Values to CMOS to make them operative. - Page 17 ¯ Move ESC Exit PgUp Previous Value F5 Previous Configuration F1 Help PgDn Next Value F6 Default Configuration...
-
Page 18: Fixed Disk Setup
EXP8051 User’s Manual 3.2 FIXED DISK SETUP Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. MAIN MENU · System Setup · Fixed Disk Setup · Advanced System Setup · Boot Options · Security and Anti-Virus · Green PC Features... -
Page 19: Advanced System Setup
Selecting either option and pressing <Enter> displays a menu like this: Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. IDE ADAPTER 0 MASTER (C: 541MB) Autotype Fixed Disk: [Press Enter] Type: [User] 541 MB Cylinders: [ 1120] Heads: Sectors / Track: Write Precomp: [None] Multi-Sector Transfers:... - Page 20 EXP8051 User’s Manual Load Values from CMOS Save Values to CMOS ¯ Move Enter Select F1 Help ESC Exit F10 Save & Exit Selecting “Advanced System Setup” from the Main Menu displays the following menu: Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd.
-
Page 21: Memory Cache
3.3.1 Memory Cache Selecting "Memory Cache" from the Advanced Setup menu displays a menu like the one shown here. The actual features displayed depend on the capabilities of your system's hardware. Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. MEMORY CACHE External Cache: [Enabled]... -
Page 22: Memory Shadow
EXP8051 User’s Manual 3.3.2 Memory Shadow Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. ADVANCED SYSTEM SETUP Warning! Items on this menu, if set incorrectly, could cause your system to malfunction. · Memory Cache · Memory Shadow · Advanced Chipset Control ·... - Page 23 Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. MEMORY SHADOW System Shadow: [Enabled] Video Shadow: [Enabled] Shadow Memory Regions: C800 - CBFF: [Disabled] CC00 - CFFF: [Disabled] D000 - D3FF: [Disabled] D400 - D7FF: [Disabled] D800 - DBFF: [Disabled] DC00 - DFFF: [Disabled] E000 - E3FF:...
- Page 24 EXP8051 User’s Manual 3.3.3 Advanced Chipset Control Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. ADVANCED SYSTEM SETUP Warning! Items on this menu, if set incorrectly, could cause your system to malfunction. · Memory Cache · Memory Shadow ·...
-
Page 25: Advanced Chipset Control
Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. ADVANCED CHIPSET CONTROL PCI FEATURES CPU/PCI Write Buffer: [Enabled] CPU/PCI Write-Byte-Merge: [Enabled] CPU/PCI Write-Fast: [Disabled] CPU/PCI Write-Burst: [Disabled] CPU/PCI Read Buffer: [Disabled] PCI Read-Line Command: [Disabled] CPU/PCI Burst Read: [Disabled] PCI/CPU Write Buffer: [Enabled] PCI/CPU Read Buffer: [Disabled]... - Page 26 EXP8051 User’s Manual NOTE: The contents of this menu depends on the chipset installed on your motherboard, and chipsets vary widely. Consult your dealer or the <F1> help screens before changing the items on this menu. Incorrect settings can cause your system to malfunction.
-
Page 27: Pci Devices
PCI INT-5 Level/Edge Selection: [Edge] PCI INT-6 (INTB#) Level/Edge Selection: [Edge] ¯ Move ESC Exit PgUp Previous Value Previous Configuration F1 Help PgDn Next Value Default Configuration Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. PCI DEVICES PCI INT-7 (INTC#) Level/Edge Selection: [Edge] PCI INT-8 (INTD#) Level/Edge Selection: [Edge]... - Page 28 EXP8051 User’s Manual Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. PCI DEVICES PCI Device, Slot #3: Enable Device: [Disabled] Enable Master: [Disabled] Use Default Latency Timer Value: [Yes] Latency Timer Value: [0040] IRQ Line: [None] PCI Device, Slot #4:...
-
Page 29: Boot Option
3.4 BOOT OPTIONS Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. MAIN MENU · System Setup · Fixed Disk Setup · Advanced System Setup · Boot Options · Security and Anti-Virus · Green PC Features Load ROM Default Values Load Values from CMOS Save Values to CMOS ¯... -
Page 30: Security And Anti-Virus
EXP8051 User’s Manual 3.5 SECURITY AND ANTI-VIRUS Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. MAIN MENU · System Setup · Fixed Disk Setup · Advanced System Setup · Boot Options · Security and Anti-Virus · Green PC Features... - Page 31 Fixed Disk Boot Sector: [Normal] ¯ Move ESC Exit PgUp Previous Value Previous Configuration F1 Help PgDn Next Value Default Configuration "Supervisor Password is" shows whether supervisor password is set or not. "User Password is" shows whether user password is set or not. Setting Supervisor Password requires a password on entering Setup.
-
Page 32: Green Pc Features
EXP8051 User’s Manual 3.6 GREEN PC FEATURES Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. MAIN MENU · System Setup · Fixed Disk Setup · Advanced System Setup · Boot Options · Security and Anti-Virus · Green PC Features... - Page 33 Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. GREEN PC FEATURES Power Saving Mode: [Enabled] System Doze Timer: [10 sec] System Standby Timer: [10 sec] System Suspend Timer: [10 sec] Wakeup System During Suspend: [Disabled] Wakeup Time at (hour): [0 hr] Wakeup Time at (minute): [0 min]...
-
Page 34: Load Rom Default Values
EXP8051 User’s Manual [On] DMA1(LAN Card) : [On] DMA3(LAN Card) : [On] LPT IO Address: [On] PCI Master Event: [Off] ¯ Move ESC Exit PgUp Previous Value Previous Configuration F1 Help PgDn Next Value Default Configuration 3.7 LOAD ROM DEFAULT VALUES Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. - Page 35 NOTICE Default values have been loaded. [Continue] 3.8 LOAD VALUES FROM CMOS Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. MAIN MENU · System Setup · Fixed Disk Setup · Advanced System Setup · Boot Options · Security and Anti-Virus ·...
- Page 36 EXP8051 User’s Manual NOTICE Previous values have been loaded. [Continue] 3.9 SAVE VALUES TO CMOS Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. MAIN MENU · System Setup · Fixed Disk Setup · Advanced System Setup · Boot Options ·...
- Page 37 Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd. NOTICE Changes have been saved. [Continue]...
- Page 38 RMA FORM When the motherboard can not work well, please fill this form to describe related situations. If the space is not enough to use, you can attach separate paper. MODEL : MODEL NO : HARDWARE CPU: Brand ______________, Model _____________, Speed ______________ CO-PROCESSOR: Brand ____________, Model ____________, Speed __________ MHz SIMM: Brand _________, Speed _________ ns, Q'ty ________ pcs, Total...
- Page 39 <B> ERROR MESSAGES ON YOUR SCREEN (PLEASE SHOW US THE WHOLE SENTENCE) <C> PROBLEM DESCRIPTION...
