Summary of Contents for mawa Saim SCT Series
- Page 1 Saim SCT Series Thermal Imaging Riflescope...
- Page 2 1．Description The Saim series is a low-cost Thermal Imaging Riflescope, which can be mounted on various firearms for night hunting and target observation. Its compact size and lightweight design make it easy to carry. What makes it outstanding is long operation hours, good concealment and great ability to detect, recognize and identify objects or targets fast and easy.
- Page 3 ➢ Install the batteries correctly as shown in Figure 2. ➢ When done, covering and pushing the battery cover till you hear “click” to ensure both sides of the cover is installed correctly. Attention! ⚫ Disposable batteries are ONLY supported! Risks are existing to use rechargeable batteries due to nonstandard quality.
-
Page 4: Operation
4. Operation 4.1 Power On/Off When the device is off, long press the P button for 3s and wait for 6s until the thermal image appears to start up the device. When the device is on, long press P button for 5s until the shutdown option menu appears, select the “√”... - Page 5 4.6 Reticle On/Off ➢ Firstly, press and hold down the P+C button and simultaneously click the M button four times to invoke the reticle function for the first time use. ➢ Then, long press P + M + C button simultaneously for 7 seconds to active the Shortcut button for switching the reticle on/off.
-
Page 6: Shortcut Menu
6. Shortcut Menu In the normal display mode, short pressing the M button to bring up the shortcut menu. The page includes image mode, image sharpness, E-zoom, display brightness, reticle color, reticle pattern, for detail as shown in table1. Table1. Shortcut Menu Times to press M Operation... - Page 7 Reticle color and pattern setting (in shortcut ➢ Short pressing the P button menu3) to perform reticle color setting-white, black, red and 3 times green. ➢ Short pressing the C button to perform the reticle pattern settings. Exit Shortcut Menu and return to the previous 4 times ——...
- Page 8 7.1 Ultraclear mode Ultraclear Mode will give more image details in harsh weather such as heavy fog, rain and snow. 7.2 Wi-Fi The Saim SCT series is equipped with wireless communication with external devices (computer, smartphone) via Wi-Fi. ➢ Turn on Wi-Fi in the main menu. Then the device will be recognized by an external device.
- Page 9 7.4.1 Zeroing Before implementing zeroing setting, please make sure that the reticle is on and zeroing type is selected in advanced menu. ➢ Select the ‘Zeroing’ option by P or C button, and short press the M button to enter the interface as shown in figure 6.
- Page 10 ⚫ Press and hold down the M button to save and exit when done. Notes: ➢ To ensure the accuracy of the position, aiming the bull’s-eye again and repeat the operations until the bull’s-eye is hit. ➢ In the zeroing interface, the reticle moves one pixel with a short pressing M or C button to the corresponding direction while ten pixels movement with a long-pressing.
- Page 11 time to perform calibration, and press the same button again at the same position for cancellation. The number of the defective pixels calibrated is displayed at the bottom of the screen. ➢ Repeat the above process till all defective pixels are calibrated, then long press the M button to save and exit.
- Page 12 Short press the M button to return to the main menu. 8. Shortcut Buttons Instructions To quickly realize the frequently used functions, the Saim SCT series made the default shortcut buttons of the most commonly used functions in the observation interface.
-
Page 13: Specification
9. Specification Model Saim SCT35 Resolution, pixels 384× 288 Pixel size, μm Frame rate, Hz Objective lens, mm Field of view 7.5°× 5.7° Display 1280× 960 LCOS Magnification, x 2.86-11.44 Battery type CR123× 2 Max. Operation time, h Wi-Fi & Recorder √...
