Summary of Contents for METER AROYA RST-W2-P-110-SMA-H

  • Page 1 AROYA...

  • Page 2: Table Of Contents

    18362-00 2.24.2020 TABLE OF CONTENTS 1. Introduction ....................1 2. Operation ....................3 2.1 Installation ....................3 3. System ......................7 3.1 Specifications .................... 7 3.2 Components .................... 12 3.2.1 Gateway (H210) ................12 3.2.2 Router (H110) and Router Climate (H111) ........14 3.2.3 Sensor Station (H310) and Sensor Nose (H311) ......
  • Page 3 Data to Cloud Data transmitted Data transmitted from Router from Sensor to Gateway Nose to Router Gateway (H210) Router (H110) Sensor Nose (H311) Data transmitted from Sensor to Gateway Sensor Nose (H311) Sensor Nose (H311) Sensor Nose (H311) Sensor Nose (H311) Data transmitted from Sensor Station to Gateway...

  • Page 4: Introduction

    1. INTRODUCTION Thank you for choosing the AROYA system from METER Group, Inc. USA. Prior to use, verify the sensor arrived in good condition. The AROYA Gateway (H210—Figure 5 and Figure 6) is powered over a Power Over Ethernet (POE) enabled device that is compliant with IEEE 802.3af Power Over Ethernet standards.
  • Page 5 INTRODUCTION G—Gatway R—Router/Router Climate S—Sensor Station/Nose Figure 1 AROYA system Bluetooth mesh network example...

  • Page 6: Operation

    PRECAUTIONS METER sensors are built to the highest standards, but misuse, improper protection, or improper installation may damage the sensor and possibly void the manufacturer’s warranty. Before integrating AROYA into a system, make sure to follow the recommended installation instructions and have the proper protections in place to safeguard sensors from damage.
  • Page 7 OPERATION Table 1 H210 Gateway Installation (continued) METER recommends mounting the Gateway on a wall with the cable ports at the bottom. Punch holes in the bottom of the mounting bracket. Make the holes large enough to countersink the screws so the heads are below or flush with the bracket surface.
  • Page 8 Tools Needed Chain/cable/rope Consider the Surroundings METER recommends installing the Router Climate in the center of each room of the greenhouse to facilitate quality communication to the Gateway. Preparation The Router Climate should be in an area where the environment is as consistent as possible.
  • Page 9 (Figure 11) until the LED flashes green. Insert sensor into slabs or larger substrate types. Mounting All system configuration work is done at METER before installation occurs at Configuration the customer site. Connect Router to Internet and Verify The Sensor Station is shipped to the customer in SLEEP mode, indicated by a solid red status LED light on the end where the cable is connected.

  • Page 10: System

    AROYA 3. SYSTEM This section describes the specifications, components of the AROYA Gateway, Router, Router Climate, Sensor Station, and Sensor Base. 3.1 SPECIFICATIONS MEASUREMENT SPECIFICATIONS ATMOS 14 Temperature and Relative Humidity (RH) Sensor Relative Humidity (RH) Range 0–100% RH (0.00–1.00) Resolution 0.1% RH Accuracy...
  • Page 11 SYSTEM Accuracy Sensor measurement accuracy is variable across a range of temperatures. Refer to the chart in Figure 3. Figure 3 Temperature sensor accuracy Equilibration Time <400 s (response time in 1 m/s air stream (τ, 63%) Long-Term Drift <0.04 °C/year, typical Vapor Pressure Range 0–47 kPa...
  • Page 12 AROYA TEROS 12 Soil Moisture, Temperature, and Electrical Conductivity (EC) Sensor Volumetric Water Content (VWC) Range Mineral soil calibration 0.00–0.70 m Soilless media 0.0–1.0 m calibration Apparent dielectric 1 (air) to 80 (water) permittivity (ε NOTE: The VWC range is dependent on the media the sensor is calibrated to. A custom calibration will accommodate the necessary ranges for most substrates.
  • Page 13 SYSTEM COMMUNICATION SPECIFICATIONS Output Gateway Ethernet (POE) Wireless communication Bluetooth mesh (Gateway, Routers, Sensors) Sensor types SDI-12 based Antenna Manufacturer Raltron Model number RST-W2-P-110-SMA-H Gain 4.15 dBi vertically polarized, dipole professionally installed NOTE: This radio transmitter IC-5123A-MGM12P0 has been approved by Innovation, Science and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated.
  • Page 14 AROYA ATMOS 14 with radiation shield Diameter 10 cm (3.94 in) Height 8.5 cm (3.35 in) Sensor Station Length 23.5 cm (9.25 in) Width 18.0 cm (7.48 in) Height 12.3 cm (4.84 in) TEROS 12 Length 9.4 cm (3.70 in) Width 2.4 cm (0.95 in) Height...

  • Page 15: Components

    SYSTEM Connector Types Gateway power RJ 45 Ethernet cable Router power RJ 45 Ethernet cable Sensor Station/ Sensor RJ 45 Ethernet cable Nose power ATMOS 14 and TEROS 12 M8 circular female plug and female thread (Sensor State/ sensor connection Sensor Nose, Router, Router Climate) Communications port M8 circular female plug and female thread (Sensor State/ Sensor Nose, Router, Router Climate)
  • Page 16 AROYA The Gateway operates using the following components: • Power over Ethernet (POE) module for continuous power • 2.4-GHz Bluetooth low-energy chip antenna Antenna Front/top cover (end cap) LED indicates active internet connection (flashing orange) NOTE: If the internet connection is slow, the light may flash green instead of orange.

  • Page 17: Router (H110) And Router Climate (H111)

    SYSTEM Back/bottom cover (end cap) Red LED indicates power status Antenna Figure 6 AROYA Gateway—back/bottom view 3.2.2 ROUTER (H110) AND ROUTER CLIMATE (H111) The AROYA Router/Router Climate receives data from the sensor stations and transmits data to the gateway wirelessly. The Router acts as a range extension for the network and funnels the data to the Gateway device.
  • Page 18 AROYA Blue LED indicates power ON Front/top Ethernet Antenna M8 connectors cover (end cap) POE port (RJ 45) Figure 7 AROYA Router—front/top view The AROYA Router Climate receives data from the Sensor Stations/Sensor Noses and transmits data to the Gateway wirelessly. The ATMOS 14, located in a radiation shield and attached to the Router Climate, collect microclimate data that is also transmitted to the Gateway.

  • Page 19: Sensor Station (H310) And Sensor Nose (H311)

    SYSTEM Solar panel ATMOS 14 in radiation shield Router M8 connectors Antenna Figure 8 AROYA Router Climate with ATMOS 14 sensor 3.2.3 SENSOR STATION (H310) AND SENSOR NOSE (H311) Figure 9 Figure 10 show the AROYA Sensor Station and Figure 11 Figure 12 show the AROYA Sensor Nose.
  • Page 20 AROYA Antenna TEROS 12 sensor Solar panel Fuction button Figure 9 AROYA sensor station with TEROS 12 sensor...
  • Page 21 SYSTEM Sensor port Serial communications port Antenna connection Figure 10 AROYA sensor station connections—bottom view The AROYA Senosr Nose is another version of the station with a different form factor allows the TEROS 12 prongs to be inserted into the side of slabs of soil. The Sensor Nose is powered with a lithium-ion battery that is solar charged.
  • Page 22 AROYA Antenna Function button Solar panel Serial communications port Sensor port Figure 11 AROYA sensor nose—top view Serial label Antenna Sensor port Serial communications port connection Figure 12 AROYA sensor nose—bottom view...

  • Page 23: Service

    The AROYA Sensor Station, Sensor Nose, Router, and Router Climate, and Gateway should be returned to METER in the event that it quits working for any reason or if the battery no longer holds a charge. Please refer to Section 4.2...

  • Page 24: Troubleshooting

    AROYA 4.3 TROUBLESHOOTING Table 6 lists common problems and their solutions. If the problem is not listed or these solutions do not solve the issue, contact Customer Support. Table 6 Troubleshooting Problem Possible Solutions GATEWAY Check that the device is powered on by observing the red light is on. Confirm internet connectivity through the orange flashing light.

  • Page 25: Terms And Conditions

    NOTE: For products purchased through a distributor, please contact the distributor directly for assistance. 4.5 TERMS AND CONDITIONS By using METER instruments and documentation, you agree to abide by the METER Group, Inc. USA Terms and Conditions. Please refer to metergroup.com/terms-conditions...

  • Page 26: Appendix A. Compliance Certifications

    METER Group, Inc. USA. The use of accessories other than those recommended, or changes to this product that are not approved by METER Group, may void the compliance of this product and may result in the loss of the user’s authority to operate the equipment.
  • Page 27 APPENDIx A U.S.A. DIGITAL EMISSIONS COMPLIANCE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 28: Canada

    METER Group Inc., USA. L’utilisation d’accessoires autres que ceux recommandés ou des changements à ce produit qui ne sont pas approuvés par Meter Group Inc. peuvent annuler la conformité de ce produit et mettre fin au droit de l’usager d’utiliser l’équipement.
  • Page 29 APPENDIx A FCC § 15.19 LABELING REQUIREMENTS This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
  • Page 30 AROYA Cet équipement génère, utilise et peut émettre de l'énergie de radiofréquence et, s'il n'est pas installé et utilisé conformément au manuel d'instructions, peut provoquer des interférences nuisibles aux communications radio. Le fonctionnement de cet équipement dans une zone résidentielle est susceptible de provoquer des interférences nuisibles, auquel cas l'utilisateur devra corriger les interférences à...
  • Page 31 APPENDIx A DÉCLARATION CLASSE A DU CANADA Cet appareil numérique de la Classe A est conforme à toutes les exigences du Règlement canadien sur les équipements causant des interférences. RADIO PRECAUTION STATEMENT Radio transmitters IC-5123A-MGM12P0, IC-25859-H110A00, and IC-25859-H310A00 have been approved by Innovation, Science, and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated.
  • Page 32 (ne tient plus la charge), l'utilisateur doit renvoyer la station du capteur, le nez du capteur, le routeur ou le routeur de climat à METER Group, Inc. USA. Ne mélangez pas cette batterie avec le flux de déchets solides. Contactez le service...
  • Page 33 18367-00 2.24.2020 METER Group, Inc. USA 2365 NE Hopkins Court Pullman, WA 99163 T: +1.509.332.2756 F: +1.509.332.5158 E: info@metergroup.com W: metergroup.com METER Group AG Mettlacher Straße 8, 81379 München T: +49 89 1266520 F: +49 89 12665220 E: info.europe@metergroup.com W: metergroup.de...
