Features
- Post-Installation Adjustments Leveling, tilt and in-out adjustment knobs make it easier that ever to flush and level
the flat-panels for a seamless video wall
- Locking Safety Screws
- Spring lock to lock or unlock the mount from the closed position.
- Cable/Electrical Access
- Complied to VESA : 200mm x 200mm, 400mm x 600mm
BKT-529 Specifications
Suitable LCD / TV
Load Capacity
Depth (Kept Position)
Depth (Popped Out)
Wall Mount Plate
Depth to wall
Colour
Complied to VESA
Product Dimension
Solid Concrete Mounting
1
3
www.remacotech.com
BK T S e rie s - Vide o Wall Mount T V Brac ket
:
46" to 70"
:
70kg
:
113mm (+/- 10mm with Micro-adjustment)
:
300mm (+/- 10mm with Micro-adjustment)
:
505 x 545mm
:
120 to 260mm
:
Black
:
400 x 400mm, 400 x 600
+/- (x)
2
4
Email : remaco@remacotech.com
+/- (Z)
+/- (Y)
+/- (Y)
+/- (Z)
LOCK
Wood Stud Mounting
1
3
Tel : 6366 9266
2
Fax : 6366 9280
