Summary of Contents for Jays Easy 2x4 Bench & Side Table
- Page 1 & s Ench aBlE Copyright © 2014 JaysCustomCreations.com Shopping List Per Bench Shopping List Per Table Item Quantity Item Quantity 2x4x8’ 2x4x8’ 2-1/2” pocket hole screws 22 2x2x8’ (optional) 2-1/2” decking screws 2-1/2” pocket hole screws 24 Wood glue Wood glue...
- Page 2 Page | 2x4 Bench And Side Table Arrows indicate pocket holes. All angles are 15 degrees. Bench pocket hole locations.
- Page 3 Page | 2x4 Bench And Side Table Build the left and right leg assemblies. Use glue and two decking screws along the long diagonal of each intersection. The lower horizontal piece is spaced 3-1/2” away so you can use a scrap piece of 2x4 for spacing.
- Page 4 Page | 2x4 Bench And Side Table Attach the seat slats from the back forward. The back seat slat rests against the back support and the rest are spaced 1/4” apart. A standard wood pencil is about 1/4”. Secure them from below with glue and pocket hole screws.
- Page 5 Page | 2x4 Bench And Side Table Arrows indicate pocket holes. Drill the pocket holes according to this spacing diagram. Attach the short side to the legs first with glue and pocket hole screws. Connect both short sides with the long sides. No spacing is required for the top slats.
