Vive LVA1074PGR User Manual

QUICK SET UP GUIDE
Step 1: Open the battery door of the pager and insert two AA
batteries as shown. Close the battery door.
Step 2: On the pager, press and hold both UP and DOWN arrows for
5 seconds. You will see the number "1" is blinking in red, indicating that
the pager is now in programming mode.
Number
UP Button DOWN Button
Step 3: There are 10 channels on the pager for programming up to
10 individual wireless devices. Select a number for programming by
pressing the UP or DOWN arrow on the front of the pager.
Step 4: While the pager is in pairing mode, a red light should flash
over the device number (#1-10) that you are attempting to pair
the alarm with. While this light is flashing, press the button on the
transmitter once to wake it up, then hold for 5 seconds until the alarm
light on the transmitter flashes orange. Then release the button on
the transmitter.
Change Alarm Light
Change Alarm
Alarm
05 25 45
Time Delay
Cordless Pad Alarm
Step 5: The pager will beep to signal a successful connection. Then it
will re-enter programming mode in case you need to connect other
wireless devices. If you do not need to connect more devices press
and hold both the UP and DOWN arrows on the front of the pager to
exit programming mode.
Step 6: Test the connection by sitting down on the sensor pad
and standing up. The alarm should sound on the pager and the
connected channel number should flash in red while the alarm
sounds. To silence the alarm press the STOP button on the pager. If
this does not occur follow these steps again from the beginning or
contact us for help.
Note: This set up is only for the sensor pads with transmitters. If you
are trying to pair a call button or door alarm, please refer to those
specific instructions. All devices are sold separately.
