SINGULARITY COMPUTERS Arterial Assembly Manual

Hide thumbs
1
Table Of Contents
2
3
4
5

Advertisement

Table of Contents

vv
Revision 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Arterial and is the answer not in the manual?

Questions and answers

Summary of Contents for SINGULARITY COMPUTERS Arterial

  • Page 1 Revision 1.0...
  • Page 2 | Arterial Assembly Manual Table of Contents Step 1: Install Feet .............................. 2 Step 2: Install Corner Pieces ........................... 2 Step 3: Assemble Chassis ..........................3 Step 4: Install Distribution Plate ........................3 Side Panel Window Installation ........................4 Pressure Testing ..............................4 Filling &...
  • Page 3 | Arterial Assembly Manual Step 1: Install Feet • Feet x4 • M4 x 14mm Fasteners x4 • Bottom Panel x1 • M4 Nuts x4 Parts Involved • M4 Washers x4 Attach the Feet to the Bottom Panel using 4x M4 x 14mm, M4 Nuts and M4 Washer.
  • Page 4 | Arterial Assembly Manual Step 3: Assemble Chassis • All parts assembled so far • M4 x 10mm Fasteners x12 Parts Involved • Side Panels x2 Attach the Bottom Panel and Top Panel to the Side Panels using 12x M4 x 10mm fasteners. Select your Side Panel orientation depending where you want the cable routing and pass-throughs to be.
  • Page 5 | Arterial Assembly Manual Side Panel Window Installation • Side Panel Window • M4 x 10mm Fasteners x4 Parts Involved The side panel window is installed with x4 M4 x 10mm fasteners. Pressure Testing We strongly recommend pressure testing with an air pressure tester prior to filling your loop.
