Summary of Contents for Spark SPARK TITAN SF-X8
- Page 1 CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD SPARK TITAN SF-X8 USER MANUAL SF-X8 SPARK TITAN USER MANUAL...
-
Page 2: Table Of Contents
4.1 WORKING CONDITION REQUIRED ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 4.2 SAFETY TIPS 5 MACHINE OPERATION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.1 PREPARATION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.1.1 INSTALL MACHINE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A10 5.1.2 FILL IN SPARK FABRICA GRANULE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.2 CONNECT MACHINE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.3 INITIAL SETTING ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪ 5.3.1 SET CHANNEL MODE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A14 ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪... - Page 3 If the information contained in the manual or the product speci cations are changed, Spark Fabrica will not inform you further and responsible for any errors or omissions.
-
Page 4: Product Introduction
This product belongs to the cold reworks simulation special e ects equipment, using CST technology, heating special metal powder, and sparking silver spark fountain which is safer than the traditional cold reworks.It has three controllable variables: height, density and duration. -
Page 5: Product Accessories
A special metal powder has the characteristics of high content, little residue, belonging to a special consumables with no smoke, odor and other toxic gas when sparking. Only the consumables provided by Spark Fabrica are allowed to be used. Spark Fabrica shall not be liable for any damage to machines, personnel and property caused by the use of consumables not provided by the company. - Page 6 Update Box Optional 120ohms Terminal Resistance Optional √ Certification √ ROHS Net Weight 24kg Weight Gross Weight 26kg Machine Dimensions - L*W*H 400mm*335mm*313mm Dimensions Packing Dimensions - L*W*H 915mm*510mm*515mm Granule Granule Spark Fabrica Granule SPARK TITAN USER MANUAL SF-X8 |...
-
Page 7: Screen Operation Guide
DMX/CAN OUT POWER IN(20A) POWER OUT(11.5A) Movement heating status indicator, chang liang that is heating. 3 PIN DMX/CAN IN 5PIN DMX/CAN IN POWER IN 3 PIN DMX/CAN OUT 5 PIN DMX/CAN OUT POWER OUT SPARK TITAN USER MANUAL SF-X8 |... -
Page 8: Menu Setting
Press ▲ key or ▼ key to modify parameters. The parameters will ash a er the modi cation, NOTICE and please press < 0K > key to save the change. NOTICE Press ◀ key will return to previous page. SPARK TITAN USER MANUAL SF-X8 |... -
Page 9: Status Icons
Lack Of Time PCB Too Hot Sub PCB Connected 2/3 Channel Mode Optional 3.4 RDM RDM allows the console with RDM function to set the DMX address and starting temperature of Spark Tide. 3.5 DMX PARAMETER LIST First Channel Function 0~10... -
Page 10: Operation Notes
Keep people or ammable materials at least 10 feet (3 meters) away from the machine, and make sure that debris does not fall on ammable objects. Do not use the machine at temperature above 122 'F (50℃). Do not use the machine indoors. SPARK TITAN USER MANUAL SF-X8 |... -
Page 11: Safety Tips
Do Not touch the sparks.During heating up and operation, do not touch the housing. Ensure nothing drop(s) into the nozzle of Spark Tide unit. Do Not cover output nozzle port. The product is very hot during operation and it remains hot for a long time a er operation has stopped. -
Page 12: Machine Operation
Install the machine on a rm and level ground, and the maximum tilt angle shall not exceed 15 degrees. = 0° ≥ 15° ≥ 15° 5.1.1 INSTALL MACHINE Install the product on truss by using the attached accessories. SPARK TITAN USER MANUAL SF-X8 |... -
Page 13: Fill In Spark Fabrica Granule
Spark Fabrica Granule is the consumable specially designed for spark machine, to simulate cold fountain re- works e ect for stage. *Tear the vacuum package of granule, and ll in the Spark Fabrica Granule through the granule lling port on the top of the machine. -
Page 14: Connect Machine
5 PIN DMX 5 PIN DMX DMX/CAN IN DMX/CAN IN DMX/CAN OUT DMX/CAN OUT 3 PIN DMX 3 PIN DMX DMX/CAN IN DMX/CAN IN POWER POWER POWER OUT POWER OUT POWER POWER IN POWER IN SPARK TITAN USER MANUAL SF-X8 |... -
Page 15: Initial Setting
Setting Range Default Set Temperature 400-640 DMX Address 1~512 DMX Channel Mode Density 30~100 Auto Heating ON/OFF Tilt Sensor ON/OFF Working Mode Rainy/Sunny Rainy TFT BackLight ON/OFF Safety Addresss 0~512 OFF(0) Restore Default Yes/No SPARK TITAN USER MANUAL SF-X8 |... -
Page 16: Set Channel Mode
DMX signal.Automatic heating function can be set to on or o , and the concrete operation please refer to “3.2 MENU SETTING”. *When spark machines connect DMX signal, the heating function can be started only on the Sim Pyro Console. 5.3.1 SET CHANNEL MODE This machine has 2 channel mode and 3 channel mode, the speci c setting please refer to “3.2 MENU SETTING”. -
Page 17: Swipe Rfid Time Card
If the customer breaks the card swiping function or cancels the card swiping function at the customer's request, no quality guarantee and a er-sales service will be provided by Spark Fabrica. Spark Fabrica shall not be liable for any accidents and losses about this. -
Page 18: Adjust Sparking Height
And make sure no falling residue y to ammable material. According to the particle size of granules,the maximum height can reach 10 meters. If spark machines are a ected by wind, sparking height will be reduced, sparking direction will also be a ected by the wind and inclined. -
Page 19: Spark Through Remote Controller
Sparking stops automatically a er 30 seconds,and clearing material stops a er 5 seconds. The remote controller has 4 height levels. One remote controller is recommended to control 4 units at most. SPARK TITAN USER MANUAL SF-X8 |... -
Page 20: Clear Material
*Use a damp cloth to remove dust and debris from the surface of the machine. *Unused Spark Fabrica Granule should be stored in a cool, dry place, vacuum packed insealed foil bags, and prote- cted from moisture, heat, hot surface, open re and other ignition sources. -
Page 21: Machine Maintenance
A er a period of using, check if there is any consumable accretion inside the nozzle. Do necessary cleaning up if there has some, or it may a ect spark performance, even damage the machine. SPARK TITAN USER MANUAL SF-X8 |... -
Page 22: Failure Handling
1. Check wire connection of temperature sensor. Temp Sensor Temperature sensor 2. Replace temperature sensor. E2 Unconnected disconnected. 3. Replace main board. PCB Too Hot Stop operating machine until main board Main board too hot. temperature return to normal. SPARK TITAN USER MANUAL SF-X8 |... - Page 23 Use illegal or copy RFID card will lock the Illegal Card machine. If so ,seller will stop providing Machine locked because of using illegal or copy RFID card. warranty and a er sale service. To unlock Machine Locked the machine,please contact seller. SPARK TITAN USER MANUAL SF-X8 |...
- Page 24 www.sparkfabrica.com marketing@sparkfabrica.com +86 138 7585 1139...
