Platinum Health PHB3300 Quick Start Manual

Carousel Sliding Bath Bench with Swivel Seat
ASSEMBLY AND OPERATION MANUAL
Thank you for investing in Carousel Sliding Bath Bench with Swivel Seat. Safe and
comfortable bathing is only a few steps away. Please be sure follow all instructions carefully
to ensure safe and trouble-free operation for years to come.

IMPORTANT SAFETY INFORMATION

READ ALL SAFETY INFORMATION BEFORE USING
It is the users responsibility to ensure the appropriateness of this device for the user in
question before using.
• NEVER use this device with individuals who are severely mentally, cognitively, physically
or vision compromised.
• ALWAYS attach safety belt and adjust to a snug fit around users hips.
• NEVER leave a compromised user unattended.
• ALWAYS ensure that the legs are properly adjusted to ensure that the bench is level side
to side and front to back.
• NEVER exceed the maximum weight capacity of 330 lbs.
NOTE: Failure to follow the above noted safety instructions can lead to severe injuries.

ASSEMBLY

STEP 1
Remove all parts from the box and remove all plastic
packaging. Ensure all parts are present as shown
here. In the event of missing parts, please call cus-
tomer service at 1-888-550-2410.
STEP 2
Insert the curved upper leg sections into frame of
shower chair as shown. Slide parts together until the
brass tension spring buttons pop out of the holes.
NOTE: only two tension spring buttons will show the
other two tension spring buttons need to be pressed
so the legs slide into the tube.
Model PHB3300/PHB3400G
