- Page 1 B W S The Blake Group PROFESSIONAL II SERIES OPERATIONS MANUAL RESIDENTIAL FILTRATION SYSTEMS WITH FLECK 2510 AIO CONTROL VALVE MODEL NO. ______________________ SERIAL NO. ______________________...
-
Page 2: Installation Information
INSTALLATION INFORMATION DATE INSTALLED:_________________________________ MEDIA TANK SIZE:______________”X________________” MEDIA INSTALLED ________________________________QTY WELL PUMP CAPACITY:____________________________GPM PIPE SIZE:__________” MATERIAL_____________________ SERVICE FLOW:__________________________________GPM BACKWASH FLOW:_______________________________GPM CURRENT WATER CONDITIONS AT STARTUP WATER TEST RESULTS: IRON________________________PPM WATER TEST RESULTS: MANGANESE_________________PPM WATER TEST RESULTS: HYDROGEN SULFIDE___________PPM WATER TEST RESULTS: FEEDWATER pH___________________ WATER SAMPLE INFORMATION City Water Supply Private Water Supply FEEDWATER IS Clear Cloudy OBJECTIONABLE CHARACTERISTICS OF WATER SUPPLY Water Seems Hard ... -
Page 3: Installation Requirements
Introduction The Aeration filter system functions as a regenerable water treatment unit utilizing oxygen instead of potentially harmful chemicals to rejuvenate and enhance the performance of the selective filtration media. The filtration media provided is specific to the water contaminant or contaminants your water treatment specialist has identified. - Page 4 Installation Instructions 1. Place the oxidizer tank where you want to install the unit making sure the unit is level and on a firm base. 2. During cold weather, the installer should warm the valve to room temperature before operating. 3.
- Page 5 9. Place the bypass valve in the by-pass position. Turn on the main water supply. Open a cold filtered water tap nearby and let run a few minutes or until the system is free from foreign material (usually solder) that may have resulted from the installation. Once clean, close the water tap.
-
Page 6: Timer Operation
CONTROLLER Timer Operation In normal operation, the Time of Day display will alternate being viewed with the Days Remaining display. This display will be in gallons (options are liters or cubic meters). As treated water is used, the Days Remaining display will count down from a maximum value to zero or (- - -). - Page 7 Day of the Week Control This control regenerates the system on a weekly schedule. The schedule is defined in Master Programming by setting each day to either “off” or “on.” The control will initiate the regeneration cycle on the days that have been set to “on” at the specified regeneration time. Control Operation during Regeneration During regeneration, the control displays a special regeneration display.
-
Page 8: Setting The Time Of Day
Setting the Time of Day 1. Press and hold either the Up or Down buttons until the programming icon replaces the service icon and the parameter display reads TD. 2. Adjust the displayed time with the up or down button. 3. - Page 9 Regeneration Cycle (55 minutes): Automatic Bypass during Regeneration The filter is factory set to regenerate at 12:00 a.m., normally a period of little or no water use. The regeneration cycle lasts approximately 55 minutes, after which filtered water service is restored.
- Page 10 SXT Programming Selections for Aeration Systems: Note the system as supplied is preprogrammed to reflect all parameters listed below Entering Master Programming Mode Set the Time of Day display to 12:01 P.M. Press and release the Extra Cycle button (to exit Setting Time of Day mode). Then press and hold the Up and Down buttons together until the programming icon replaces the service icon and the Display Format screen appears.
- Page 11 Media Filtration installation Guide/Commissioning Consult Installation Instructions supplied with this system for equipment positioning and plumbing requirements. Media filtration systems supplied by Blake Water Solutions are shipped without the media preloaded. Aeration/Oxidation filtration media selected for Iron, Manganese, Hydrogen Sulfide removal or other conditions your equipment supplier has identified are dependent on many factors and are carefully selected and applied based on reported water conditions at the time of testing.
- Page 12 The bypass valve supplied with the equipment should still be in the bypass position and the filter tank can now be completely filled with water by depressing the cycle button on the control valve to initiate backwash and slowly opening the bypass to fill the tank with water and purge any air.
-
Page 13: Troubleshooting
TROUBLESHOOTING ERROR CODES NOTE: Error codes appear in the Service Display ERROR ERROR TYPE CAUSE RESET AND RECOVERY CODE Cam Sensor Error The valve Unplug the unit and examine the powerhead. drive took Verify that all cam switches are connected to the circuit board longer than and funtioning properly. - Page 14 BLAKE WATER SOLUTIONS EQUIVALENT FLOW RATE IN GALLONS PER MINUTE Tank PER SQUARE FOOT OF BED AREA Tank Diameter Cubic Ft. Dome 3 GPM 5 GPM 8 GPM 10 GPM 12GPM 15GPM 20GPM Diameter Sq. Ft per Inch Volume Inches Bed Area of Height Cubic Ft. ACTUAL FLOW REQUIRED TO ATTAIN EQUIVALENT FLOW 6" 0.196 0.016 0.015 3.92 7" 0.267 0.022 0.02 5.34 8" 0.349 0.029 0.03 6.98 9"...
- Page 15 NOTES:...
- Page 16 B W S The Blake Group Blake Water Solutions 4 New Park Road East Windsor, CT 06088 Tel. (860) 243-1491 DISTRIBUTED BY: AIO-MANUAL Rev. APR 2018 P/N XO2510AIO...
