- Page 1 EXPANDER GSM NV3.3T GSM noticing module Function of alarm central unit Remotely controlled GSM GSM bug Thermostat GSM NV3.3T Cooperates with Nokia NOKIA Nokia 5110/5130/6130/6150/3330/3410 EXPANDER GSM NV3.3 T manual www.megaelektronik.pl page 1...
- Page 2 Warnings! Exact study of this instruction will provide proper and safe usage of the device. It is not allowed to conduct any repairs or modifications. Due to safety reasons installation should take place only by qualified personnel. This device is a source of electromagnetic waves, thus in specific configurations may cause distortion in proper work of other radio devices.
- Page 3 Characteristic Expander GSM NV3.3T after connecting to and external mobile phone NOKIA 5110, 5130, 6130, 6150, 3330, 3410 enables: -cooperation with every mobile phone network -efficiency and reliability as well as simple handling -quick assembly and start up -connection to all alarm systems...
- Page 4 Example of arming and disarming line IN-A Configuration of Input lines In order to prevent excessive utilization costs, especially false alarms, the device contains a set of possibilities of programming and alarm input analysis. Any device input can be configured as normally opened or normally closed.
- Page 5 Report function –exacted test Module can be remotely „asked” about it’s status via SMS. In response, module will send a SMS and in this way one can get information about current status: armed/disarmed and inputs and outputs, number of currently connected sensors and current temperature. Report is send to a number from which such request was send.
- Page 6 Technical data • Power supply +12V (+- 20%). (or 24V depending on the version) • Current consumption - 10mA in stand-by mode, 500mA in agitation mode. • Work temperature -20°C up to 50°C. • Number of input lines -3 NO or NC tripping (+) or GND configure. •...
- Page 7 Connecting module should be assembled in closed premises, with normal air EXPANDER GSM NV3.3T humidity, temperature in range -20°C up to +50°C. While selecting assembly point follow given criteria: GSM network range (provider for the used SIM card), • Availability and distance from alarm and power supply sources •...
- Page 8 Programming SMS communicators In SIM CARD memory it is possible to save four SMS regardless how many inputs will be used. Length of written message can’t exceed 160signs. Entering SMS [messages], [write message] [enter] (enter any text) [options] [save] First SMS is send in case of agitating input IN-1 Second - SMS is send in case of lack of agitating input - IN1 Third - SMS is send in case of agitating input - IN2 Fourth - SMS is send in case of lack of agitating input - IN2...
- Page 9 B NO GND R ie. 4*4 JAs above with SMS confirmation of arming and disarming Arm module using B NC PLUS ie. 1*1 input IN-A By dropout + power supply voltage First digit means delay for arming. Second digit means delay for disarming Max values are 99999*99999...
- Page 10 ie..1 Agitating first line by C 1 NC PLUS power supply voltage dropout Digit 1 or 2 stands for one or two Delay on this line is –state line equal to 1sec. Max value is 99999sec. C 1 NC GND ie.1 Agitating first line by power supply bulk...
- Page 11 D 2 NC GND ie.1 Agitating second line Digit 1 or 2 stands for one or two by power supply bulk –state line dropout Delay on this line is equal to 1sec. Max value is 99999sec. E PS ie.10*10 Controlling output OUT –S Turn on output after arming...
- Page 12 after exceeding temperature (+) –means positive +25C and a report will be sent temperature while (-) Additionally after exceeding negative temperature +40 C module will 25 –value of sent additional report. temperature Max value -50C up to +125C F T-10LR+53R H- turn on output Output OUT-1 will be turned off, L-turn off output...
- Page 13 G T +15H Output e OUT-2will be turned on if temperature is more than +15C G T -20R Module will sent a report if temperature drops below -20C If sensor is not connected please enter G T OFF Pozycje User parameters 8,9,10,11,12 (,H,I,J,K,L)-next entries Arbitrary number of...
- Page 14 KOD OUT2 ON Turn on OUT2 KOD OUT2 OFF Turn off OUT2 KOD OUTA BBB TCCC Output turn on or off on given time where; A – number of output 1 or 2 BBB - ON or OFF TCCC –switching time in sec. 1-999s ie.
- Page 15 An example of connecting auto-alarm with an additional anti-hacking systems ignition or fuel cut off Additional siren Additional sensor from siren Back up power supply Alarm unit Battery in a vehicle Entry in name Entry in number position A CODE 1234 B NC GND C 1 NO PLUS...
- Page 16 An example of usage module as an alarm central unit + simulation of inmate presence Inside temp. measurement light control Outside temp. measurement gate control Turning on and off 12 V Power supply using GSM phone Entry in name Entry in number position A CODE 1234...
- Page 17 Entry in name Entry in number position A CODE 1234 B CLIP none C OFF D OFF E OFF 2*30 F T OFF none G T OFF none H AXE +48123456789 History EXPANDER GSM NV3.3 T manual www.megaelektronik.pl page 17...
- Page 18 30.04.2006 First version Change of cooperating phones to 30.04.2008 Nokia 51xx, 61xx series 23.08.2008 PCB plate changed (transmitters in one box) Personal configure of input lines added 20.09.2008 Corrected communication with connected phone 28.11.2008 Instruction update 15.03.2009 New examples and descriptions added New phones, configure lines and temperature function added EXPANDER GSM NV3.3 T manual...
