Summary of Contents for Seiki T Series
- Page 1 Seiki Vinyl Cutter Plotter User’s Manual T Series...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION I GENERAL INFORMATION ....... 1 1. I ..............1 NTRODUCTION 2. G ..........2 ENERAL RECAUTIONS 3. P ............3 ACKAGE ONTENTS SECTION II INSTALLATION .......... 4 1. I ..........4 NSTALLATION OF TAND 2. I ............. -
Page 4: Section I General Information
Thank you for purchasing the Seiki cutting plotter. Now you can take advantage of this great new technology and gain the freedom design. Your new Seiki T Series is a vinyl cutter that connects to your computer, enabling you to quickly and... -
Page 5: General Precautions
Seiki Cutting Plotter 2. General Precautions Read all instructions before using Seiki cutting plotter WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK: • Connect to properly grounded outlet only.(Figure 1-1) Figure 1-1 • When the machine is on, DO NOT connect or disconnect cables. -
Page 6: Package Contents
Seiki Cutting Plotter 3. Package Contents Check that the package contains the following before using your cutting plotter. If any item is missing or damaged, please contact your vendor or distributor where the cutting plotter was purchased. Document User’s Manual... -
Page 7: Section Ii Installation
Seiki Cutting Plotter Section II Installation 1. Installation of Stand Figure 2-1... -
Page 8: Installation Of Pen
Seiki Cutting Plotter 2. Installation of Pen ① Using pen you can plot the characters or graphics that you have designed on the paper, when plotting, you should reduce the down force in order to avoid damaging the paper. Meanwhile... - Page 9 Seiki Cutting Plotter ② Install the blade as (Figure 2-3). Blade (Diameter is 2mm) Blade holder body Blade holder shell Blade–exiting pole Figure 2-3 ③ Adjusting the stretch of the blade extending outside (Figure 2-4) Figure 2-4...
-
Page 10: Installation Of Pen/Blade Holder
Seiki Cutting Plotter ④ Extend the tip of blade by the stretch required for the desired cutting media (T<5mils) as (Figure 2-5). Figure 2-5 4. Installation of Pen/Blade Holder ① Turn off the power. ② Loose the locking-screw of the holder bracket, then put the blade holder or pen holder in the V breach and ensure the blade tip or refill to reach to the protection-strip. -
Page 11: Section Iii Operation
Seiki Cutting Plotter ④ Section III Operation 1. Cutting Plotter Components Figure 3-1 ① Left cover ② Blade/pen holder bracket ③ Blade/pen holder ④ Tool carriage ⑤ Top bean ⑥ Pinch-roller ⑦ Control panel ⑧ Right cover ⑨ Serial port... -
Page 12: Operation Of Control Panel
Seiki Cutting Plotter ⑪ Fuse ⑫ Power switch ⑬ Pinch-roller holder with handle 2. Operation of Control Panel Figure 3-1 ① Two Line LCD ② Power indicator light ③ Off-line indicator light ④ Setting indicator light ⑤ Function keys (from left to right, up to down) : Reset, Leave, Setting, Test and Origin. -
Page 13: Loading Media
Seiki Cutting Plotter 3. Loading Media ① Adjust the place of pinch-rollers according to the paper- width. Cutting plotter has 2-4 pinch-rollers and they can be moved on the guide rail. When moving, ensure the handle of the pinch-roller is been lifted up, then hold the back of the pinch-roller holder and move it to the left or right. - Page 14 Seiki Cutting Plotter program and the cutter should output a square and a triangle. ! Attention: • Turn off the power of the computer and machine before connecting or disconnecting the cables.
-
Page 15: Section Iv Features Of Functions
Seiki Cutting Plotter Section IV Features of functions 1 Functions realization ① Plotting function: when the machine is on, and the Leave indicate light is off. The machine is online and ready to cut when computer outputs graphical data to it. - Page 16 Seiki Cutting Plotter ③ Setup status: In online status, when press the “Setup” key, the setup indicate light is on. You may set the baud rate of serial port. If you press “setup” key once more, it will restore to online status.
-
Page 17: Specifications
Seiki Cutting Plotter 3 Specifications Model SK720T SK870T SK1100T SK1350T Item The widest paper for 720mm 870mm 1100mm 1350mm entering The widest paper for 620mm 780mm 1010mm 1260mm cutting Force 10-500g Speed 10-800mm/s (32 ips) Memory Interface RS-232(Serial) Language DMPL/HPGL... -
Page 18: Section V Troubleshooting Guide
Q3. Why does the machine run abnormally? Reasons: the software setting isn’t proper the cutting software has been damage by virus in computer the protection function isn’t closed the out device selection doesn’t match to the Seiki cutting plotter... - Page 19 Seiki Cutting Plotter Q4. Why does the pattern deviate? Reasons: Media doesn’t be placed correctly. The working area is too dirty; two sides of moving paper meet different resistances may lead to deflection of paper. Deformed or different types of pressing wheels may lead to paper deflection.
- Page 20 Seiki Cutting Plotter Q7. Why do you fail to tear off vinyl paper after cutting? Reason: You didn’t set a blade proper size. Before cutting, please test the pressure of the blade and adjust it. If there shows any dotted line, you need to change new blades Q8.
- Page 21 Seiki Cutting Plotter The speed can be regulated a little faster. Besides, the compensating function should be eliminated in the process and at the same time seamless connection should be chosen.
