- Page 1 User Manual 990A All-in-one Touch POS Terminal...
- Page 2 ➢ Overview Thank you for purchasing the 990A all-in-one touch POS terminal, AGT is committed to continuously improve product quality and provide better after-sales service. In order to take full advantage of our devices, we strongly recommend that you take the time to read this manual before going into software installation.
- Page 3 2. Electromagnetic Compatibility Statement FCC NOTICE This device complies with Part 15 of FCC Rules. Operations are subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 4 1. Appearance 2. Power Button 3. I/O connectors 3.1 Rear panel At the rear panel of the 990A is a row of external I/O device connectors. Detail as follow: ⚫ COM 1.2: DB9 port for connection to serial devices(RS232) ⚫...
-
Page 5: Specification
Specification Model name 990A Type 15”All In One Touch POS terminal Color Black Material ABS Housing & Magaluma Stand ISO Trick 1/2/3 Magnetic Stripe Reader Customer Display: VFD Second Screen(9.7”) WIFI Optional Peripherals Bluetooth Windows OS(7/up) SSD (128G) ROM(8G) Motherboard part... - Page 6 USB_MSR*1 USB_VFD*1 Second display port(and touch_usb) LAN*1 USB3.0*1 LINE*1 MIC*1 Operating 0 ℃ to 40℃ Temperature Storage Temperature -20℃ to 60℃ SIZE 450*245*400mm Package: carton box NW: 5.5KG with Foam packaging GW:7.0KG Power Consumption 35W（MAX） EMC/ Product Safety FCC Class A / CE Mark / LVD / CCC OS support Windows 7/8 or up, Linux, Android Accessory...
-
Page 7: Setup And Driver Installation
<F10> To store settings and exit the CMOS SETUP program How to enter and exit the COMS interface: Enter the COMS interface Boot the 990A, press the key “Del” to enter COMS interface. Leave the COMS interface Press the key “F9” >> Restore Defaults Press the key “F10”... - Page 8 2. Touch screen driver installation: 2.1 Double-click iunitouch_tool_setup_v1.2.1.0.exe to install： 1051B User Manual...
- Page 9 2.2 Software options 2.2.1 TP list 2.2.2 Mode Switch 1051B User Manual...
- Page 10 Touch ON/OFF ： touch function ON/OFF Industrial Function ON/OFF: Factory debugging function ON/OFF Industrial Function With AP： Allows factory debugging Settings to be turned off with the software (note: when selecting ON, the parameters set will only be valid when the software is running, and invalid when the software is turned off; When "OFF"...
- Page 11 Beep Sound: Beep Occasion: default Beep Frequency: Beep Duration： Beep Device Selection：default Buzzer (You can choose to use it when you have speakers ) 2.2.5 Edge Compensation 2.2.6 Mapping Area Multi Touch Setting 1051B User Manual...
- Page 12 2.2.7 FW Upgrade After modifying the parameters, click "SET" to save the parameters 1051B User Manual...
-
Page 13: Troubleshooting
➢ Trouble Shooting 1. Terminal does not boot If the terminal cannot boot after pressing the power switch check that the power cable is connected to the power socket. If the terminal power light still remains off, the fan does not operate, and there is no BIOS beeping sound, it might be the power supply problems. -
Page 14: Limited Warranty Policy
➢ Limited Warranty Policy The 990A POS terminal features a one-year-limited warranty from the date of purchase. If product is determined to be defective, we will repair or replace the product with refurbished or remanufactured parts or components during the warranty period. - Page 15 Manufacturer: AGTPOS Thank you very much for using AGTPOS product For service, please contact http://www.agtpos.com www.agtpos.com 1051B User Manual...
