Summary of Contents for Leister 155.414
- Page 1 User manual Roof structure profile kit Art. 155.414 UNIROOF AT/ST Leister Technologies AG Galileo-Strasse 10 CH-6056 Kaegiswil/Switzerland Tel. +41 41 662 74 74 Fax +41 41 662 74 16 www.leister.com sales@leister.com...
- Page 2 Application only in Europe allowed Of patent Reasons is the kit in North America not be used! Page 2 06.02.2020...
- Page 3 Easy welding of profiles welding with 30-40 mm UNIROOF nozzle Page 3 06.02.2020...
- Page 4 Step 1: assemble rollercover Page 4 06.02.2020...
- Page 5 Step 2: assemble guidingroller Page 5 06.02.2020...
- Page 6 Step 3: assemble flange for pivot axis Page 6 06.02.2020...
- Page 7 Step 4: assemble flange for pivot axis Page 7 06.02.2020...
- Page 8 Step 5: change guidingroller Page 8 06.02.2020...
- Page 9 Step 6: ajust pressure roller Page 9 06.02.2020...
- Page 10 Step 7: ajust guide Page 10 06.02.2020...
- Page 11 Step 8: change nozzle from 40mm to 30mm Page 11 06.02.2020...
- Page 12 Step 9: ajust nozzle adjust nozzle flat Adjust nozzle centered on structural profile Page 12 06.02.2020...
- Page 13 Step 10: Setting the transport axis Setting the Right wheel as close to the structure profile. the recommended transport axis is the 300mm axis. Page 13 06.02.2020...
-
Page 14: Assembly Drawing
assembly drawing Page 14 06.02.2020... -
Page 15: Part List
Part list Pos. Number Part 153.701 Pressure roller complete 153.262 Decor-Kit guiding 155.326 Overlap welding nozzle 153.015 Flange Page 15 06.02.2020... - Page 16 Your authorised Service Centre is: Leister Technologies AG Galileo-Strasse 10 CH-6056 Kaegiswil/Switzerland Tel. +41 41 662 74 74 Fax +41 41 662 74 16 www.leister.com BA Dach Strukturprofil-Kit / 02.2016 sales@leister.com Artikel Nr. 155.895 Page 16 06.02.2020...
