LOBSTER ARF-800P Instruction Manual
  1. Manuals
  2. Brands
  3. LOBSTER Manuals
  4. Wire Feeders
  5. ARF-800P
  6. Instruction manual

LOBSTER ARF-800P Instruction Manual

Auto rivet feeder
Hide thumbs

Advertisement

Quick Links

Download this manual
Professional model of auto rivet feeder to install blind rivets.
･Thank you very much for purchasing "LOBSTER" auto rivet feeder. To ensure correct operation,
please carefully read this instruction manual and keep it in a safe place for later reference.
･This is Original instructions.
MANUFACTURER
12-8 Shijo-cho, Higashi-Osaka City
Osaka 579-8053, Japan
Telephone: +81(72)981-7466 Telefacs: +81(72)981-9420
URL https://www.lobtex.co.jp/
INTRODUCTION
IMPORTANT SAFETY
I N S T R U C T I O N S
NOMENCLATURE
TECHNICAL DATA ...
PREPARATION BEFORE
OPERATING THE AUTO
RIVET FEEDER
PROCEDURES FOR CHANGING
RIVETS AND RIVETER
MAINTENANCE
STORAGE
ORDERING PARTS
TROUBLESHOOTING
PARTS TABLE
PRINTED IN JAPAN

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARF-800P and is the answer not in the manual?

Questions and answers

Summary of Contents for LOBSTER ARF-800P

  • Page 1 Professional model of auto rivet feeder to install blind rivets. ･Thank you very much for purchasing “LOBSTER” auto rivet feeder. To ensure correct operation, please carefully read this instruction manual and keep it in a safe place for later reference.

  • Page 2: Important Notices

    This machine is a feeder to supply “LOBSTER” brand blind rivets to a vacuum type air riveter. It is not designed, produced or sold for any other purpose. This instruction manual shows how to operate and perform maintenance and inspection in order to use safely and efficiently.
  • Page 3 Be sure to read the following Important Safety Instructions carefully and make sure that you understand them thoroughly before using this machine. Always wear protective goggles while using the machine. The rivets may jump out by accident and cause injuries. Do not put your hands in the machine or close to the moving parts while you are using the machine.
  • Page 4 ⚠ Otherwise, the machine may not be able to achieve performance as specifi ed, or it may be dislodged, leading to breakage, injury, or damage. Accidents or injury may result. Accidents or injury may result. Otherwise, your hair, clothes, or accessories may be caught in the machine. Otherwise, it may operate abnormally, leading to injuries.
  • Page 5 If you fi nd any fault, arrange to have an inspection and a repair. Repair work should only be carried out by a qualified technician. Please contact your nearest “LOBSTER” distributor, representative, or direct to Lobtex Co.,Ltd.,Osaka. If the machine is repaired by someone without the necessary qualifications and experience, the machine may not perform to optimum standards, and accidents or injury may result.
  • Page 6 ⚠ Store it in a dry and high place where it can be locked away or is out of the reach of children. Otherwise, it may cause injury. Use the equipment according to the capacity of the machine and in accordance with its design specifi...
  • Page 7 Indicator LED Frame head holder Slide switch cover Height adjuster screw Instruction seal Stopper bolt Start button Power switch Rivet loading port Rivet feeding unit Power supply jack port Air supply port Air cock Warning seal Warning seal Check at the time of purchase. AC Adapter (w/ ferrite core) Power cable For details, refer to the separate sheet.
  • Page 8 F r a m e h e a d holder diameter 19 mm R i v e t d i a m e t e r 21 mm 2.4 mm (Type3) 23 mm 3.2 mm (Type4) 4.0 mm (Type5) Power supply (V) AC 100 240 (50 60Hz)
  • Page 9 Use R1A1・ AR2000SV・ AR2000MV・ ARV011M・ ARV015MX・ ARV022M・ or ARV025M Use a riveter appropriate for the frame head holder. Frame head holder notation Riveter A (19 mm) AR2000SV B (21 mm) AR2000MV R1A1 C (23 mm) ARV011M ARV015MX ARV022M ARV025M If the old type of frame head which diameter is 22 mm is used, it needs to be changed to frame head which diameter is 21 mm (Optional Frame Head CJM Code No.
  • Page 10 Set the angle of the rivet feeding unit to an angle of your choice. (It can be adjusted to three diff erent angles, from directly above 0°, 30°, and 60°. It is set at 0° in the factory default settings.) Shut off...
  • Page 11 0° 30° 30° 0° 60° 60° Angle adjuster plate Set the front urethane cover in position and fi x the acrylic cover again. Tighten pan head screws (M4) making sure not over tighten and crack the acrylic cover. Alignment of rivet feeding unit (Alignment of frame head holder and suction nozzle) If the angle of the rivet feeding unit is set to 30°...
  • Page 12 Loosen the stopper bolt. Rivet feeding unit Stopper bolt Hex key wrench Move the rivet feeding unit until it is aligned then align the suction nozzle visually with the feeder unit. Suction nozzle M o v e i n e i t h e r Move the rivet feeding unit until it is direction to ensure aligned with the suction nozzle and...
  • Page 13 Connect an air tube with an outer diameter 6 to the air supply port. Use an air tube of 4 or more inner diameter. 6 air supply port Air regulator Set up the compressor, and be sure to install an air filter, air regulator and air lubricator (3-device set) between the compressor and the machine.

  • Page 14: Turn On The Power Switch

    Load rivets into the rivet loading port. Pay close attention to the volume of rivets loaded, since loading rivets of a volume which exceeds Load rivets the specifi ed basket capacity may cause rivets to back-up. (Refer to page 7) Turn the air valve clockwise to turn on the Air cock air supply.

  • Page 15: Optional Parts

    When changing rivet diameter or riveter frame head diameter, follow the procedures shown below. When changing rivet diameter or frame head diameter, replace with optional parts. Prior to changing and replacement of any parts or components, always disconnect the air hose and power cable. ⚠...
  • Page 16 Replacement of pickup plate Remove the front urethane cover. (Refer to step of instruction on page 9.) Loosen the hexagon socket head cap bolts from 4 locations on right and left sides (2 on each side) with a hexagonal key wrench (3 mm opposite fl ats). Hex socket bolt Do not loosen screws other than those specifi...
  • Page 17 Replace with the pickup plate appropriate for the size, and re-assemble in the reverse order. Adjusting the height may need to be verifi ed to the corresponding rivet size. (See page 11) Optional parts Pickup plate U (Type3) with M6 screw Code No. 65329 Pickup plate U (Type4) with M6 screw Code No.
  • Page 18 To increase the working life of the machine, it is recommended that you maintain and service the machine as recommended in this manual. Contact the place of purchase or your nearest “LOBSTER” dealer for any overhauls and repair work required.
  • Page 19 If a problem occurs, check the following. If the problem persists after checking the items in the table below, contact your nearest “LOBSTER” dealer or contact Lobtex. 1 The power supply plug or power Connect the power supply plug or supply jack is disconnected.
  • Page 20 ARF-800P main unit...
  • Page 21 Pickup plate unit (Type 3) Steel Pickup plate unit (Type 4) Steel Pickup plate unit (Type 5) Steel Plain washer M6 Steel Brush cylinder unit Refer to page 21 Middle plate unit Aluminum Steel Basket unit Refer to page 22 Hex socket bolt M5 ×...
  • Page 22 Brush cylinder unit Hex socket bolt M5 × 10 Steel Brush Nylon, Steel Brush holder fi xture Steel Brush holder Stainless Quick exhaust valve Φ4 Urethane tube 70 Plastic Air joint Cushioning material Rubber Handle Aluminum Brush whirl-stop Steel Hex socket bolt M4 × 5 Steel Urethane cushion Plastic...
  • Page 23 Basket unit Basket plate Aluminum Platform Aluminum Platform base plate Steel Basket coupler R Steel Basket coupler L Steel Platform base Aluminum Platform pipe Steel Pin (A-type) Steel Compression spring 8 × 65 Steel Spring washer M5 Steel Hex socket bolt M5 × 10 Steel O-ring S-10 Rubber...

  • Page 24: Pickup Unit

    Pickup unit Pickup platform Aluminum Pickup platform base Steel Pickup platform pipe Steel Hinge pin Steel Compression spring 8 × 65 Steel Speed controller Angle plate base Aluminum Hex socket bolt M5 × 20 Steel Cross recessed fl at head screw M4 × 8 Steel Pickup side plate Steel...
  • Page 25 Rivet feeding unit Head mounting plate Steel Collar Aluminum Cross recessed fl at head screw M3 × 5 Steel Finger holder Steel Finger Steel Finger cap Steel Finger pusher Steel O-ring S-35 Rubber Compression spring 3 × 20 Steel Frame head holder (19) Plastic Frame head holder (21) Plastic...
  • Page 26 Rivet rotating unit Rotating shaft Aluminum Hex socket bolt M5 × 10 Steel Bush holder Aluminum Suction nozzle (3) Steel Bush 16 × L20 Copper Suction nozzle (4) Steel Gear box Aluminum Suction nozzle (5) Steel Spur gear Steel Clearance block R Aluminum Rackgear Steel...
  • Page 27 F r a m e h e a d holder diameter 19 mm 21 mm Rivet diameter 23 mm 2.4 mm (Type3) 3.2 mm (Type4) 4.0 mm (Type5) For example, the model number of above fi gure will be ARF-800P-40-C.
  • Page 28 “Optinal parts required when charging the rivet size of ARF800P” Model Model number Required optional parts number after converting Pickup plate unit Suction nozzle Frame head holder Remaining parts Remaining parts Frame head holder (21) Remaining parts Remaining parts Frame head holder (23) Pickup plate unit (Type 4) Suction nozzle (Type4) Remaining parts...
  • Page 29 Model Model number Required optional parts number after converting Pickup plate unit Suction nozzle Frame head holder Pickup plate unit (Type 3) Suction nozzle (Type3) Remaining parts Pickup plate unit (Type 3) Suction nozzle (Type3) Frame head holder (21) Pickup plate unit (Type 3) Suction nozzle (Type3) Frame head holder (23) Pickup plate unit (Type 4)
  • Page 30 BE LIABLE FOR DAMAGES OR COSTS INCURRED BY THE BUYER OR SUBSEQUENT USER IN RE- PAIRING OR REPLACING DEFECTIVE GOODS. ® ROUTINE MAINTENANCE AND REPAIR OF LOBSTER RIVET TOOLS CAN BE PERFORMED BY AN AVERAGE MECHANIC. ® HOWEVER, IF YOU HAVE A LOBSTER...
