McFarlane WDL-2100 Operator's Manual And Set-Up Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
OPERATOR'S MANUAL
AND
SET-UP INSTRUCTIONS
FOR THE
WDL-2100
REAR-FOLD TRANSPORT CART
& HARROW SECTIONS
Version: 13661 (02-18)
Serial Number 21285 - higher
TO THE OWNER AND OPERATORS
Before assembling or operating this unit, READ THIS MANUAL THOROUGHLY. To obtain
the best performance of the unit, familiarize yourself with each component and adjustment.
Store this manual where it can be readily available for future reference. If the harrow or
any part of the unit should be sold, be sure that the new owner receives a copy of this
manual for their reference.
1330 Dallas Street ∙ PO Box 100 ∙ Sauk City WI 53583
Phone (608) 643-3321 ∙ Toll Free (800) 627-8569 ∙ Fax (608) 643-3976
www.flexharrow.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the WDL-2100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for McFarlane WDL-2100

Summary of Contents for McFarlane WDL-2100

  • Page 1 OPERATOR’S MANUAL SET-UP INSTRUCTIONS FOR THE WDL-2100 REAR-FOLD TRANSPORT CART & HARROW SECTIONS Version: 13661 (02-18) Serial Number 21285 - higher TO THE OWNER AND OPERATORS Before assembling or operating this unit, READ THIS MANUAL THOROUGHLY. To obtain the best performance of the unit, familiarize yourself with each component and adjustment.
