Digital Night Vision Binocular
NV-900 is a state-of-art Night Vision Binocular with viewing range up to 1300 FT
through a large, 4" LCD Display. This Binocular can be used day and night, can take
high resolu�on pictures and record HD Videos on a Micro SD card. The NV-900 is
waterproof up to IPX4 standards and comes with a shock-resistant carrying case. This
device is perfect for hun�ng, camping, hiking, and wildlife observa�on.
We appreciate your business and trust to our brand. Your sa�sfac�on is our No.1
Goal!
WARNING:
Carefully Read this User's manual before operating!
Inappropriate operation may cause unrepairable damage
to the lens or the circuit.
Model Number: NV-900
USER'S MANUAL
NV-900 USER'S MANUAL

Advertisement

Table of Contents
loading

Summary of Contents for Rainier NV-900

  • Page 1 4” LCD Display. This Binocular can be used day and night, can take high resolu�on pictures and record HD Videos on a Micro SD card. The NV-900 is waterproof up to IPX4 standards and comes with a shock-resistant carrying case. This device is perfect for hun�ng, camping, hiking, and wildlife observa�on.

  • Page 2: Table Of Contents

    CONTENTS 1. Exterior Features and User Interface 2. Opera�on 4-11 2.1. NV-900 Opera�on Interface 2.2. Take Picture and Record Video 2.3. Replay / Delete Picture & Video 2.4. Screen Display Icons 2.5. Setup the Device and Basic Opera�ons 2.6. Advanced Opera�ons 2.7.

  • Page 3: Exterior Features And User Interface

    1. Exterior Features and User Interface...
  • Page 4 Exterior Features Table： Viewing Screen Shade Zoom In / Up Key (When in Menu) Wrist Strap Slot IR Bu�on Brightness Bu�on Wrist Strap Slot Wrist Strap Slot Wrist Strap Slot Tripod Mount Interface Objec�ve Lens Focus Dial Ba�ery Compartment 1 (AA x 4pcs) Infrared LED Light Ba�ery Compartment 2...

  • Page 5: Opera�On

    2.Operation 2.1. NV-900 Operation Interface Bu�on Func�on Bu�on Func�on MENU / BACK Bu�on / Power On/Off Playback Bu�on (Press and hold for 3 Seconds) Brightness Se�n Zoom In “1.0X∼5.0X” / Delete Picture & Video Infrared Light Se�ng Zoom out IR1/IR2/IR3 “5.0X∼1.0X”...

  • Page 6: Take Picture And Record Video

    2.2 Take Picture and Record Video (1) Make sure the Photo/Video Func�on Switch is on the desired mode – Photo or Video. (2) Adjust the Focus/Brightness/IR Se�ng to op�mal level. (3) Press the “REC” Bu�on to start taking photo or recording video. 2.3 Replay / Delete Picture &...

  • Page 7: Screen Display Icons

    2.4 Screen Display Icons Photo Count Remaining Recording Time Elapsed Recording Time No SD Card When the device is in When the device is in When the device is When an SD card is not photo mode, the number video mode and not in video mode and inserted in the card slot, of photos remaining...

  • Page 8: Setup The Device And Basic Opera�Ons

    2.5 Setup the Device and Basic Operations (1) LOAD BATTERIES OR CONNECT TO POWER BANK First, open the two ba�ery compartments on the bo�om of the binocular, the ba�ery compartments’ cover can be removed by turn the securing screws counter-clockwise with a screw driver or simply a coin.

  • Page 9: Advanced Opera�Ons

    Next, this device’s large 4” LCD Screen offers 3 levels of brightness that you can select from. Lastly, the NV-900 offers up to 5X of digital Zoom. You can adjust the Zoom with the Zoom In/Out Bu�on to find the most op�mal viewing se�ng.
  • Page 10 Video Output jack. (5) TIMELAPSE FUNCION Time lapse func�on allow your NV-900 take photo/video at preset �me intervals with star�ng and end �me. This feature can be turned on in “MENU” “Timelapse”. This feature is useful in surveillance applica�on.

  • Page 11: Menu Selec�On Tree

    2.7 MENU Selection Tree "Time lapse Start �me”, "Time Lapse End �me", "Interval �me", "Video Length" only work under "Time lapse" is "ON".

  • Page 12: Troubleshoo�Ng

    2.8 Troubleshooting What if my unit does not turn on? 1. Re-install the ba�eries, making sure of the correct polarity (+/- terminals) orienta�on (refer to the instruc�ons in the ba�ery compartments). 2. Replace all ba�eries with new ba�eries. 3. Clean the ba�ery compartment, especially the contact terminals. What if my observed image is too bright? The ambient light level is too high, and/or the IR light is at 100% level.

  • Page 13: Nv-900 Specifica�Ons

    3. NV-900 Specifications Product Name: Digital Night Vision Binocular Model No：NV-900 Patent No：004596146-0001（EURO）201830003244.4（China） patent in USA pending approval Hardware: • 1/3 CMOS & image-intensifier tube • Infrared Illuminator: 850NM 3W Infrared LED • Magnifica�on(op�cal): 4.5 • Digital Zoom: 1X-5X • Field of View: 9°...
  • Page 14 9 x 7 x 2.5 Inch (230 x 178 x 64 mm) o 2 lbs. (0.9 KG) W/O Ba�ery and 2.4 lbs. (1.1 KG) with 8 x AA Ba�eries Package Content: • 1 NV-900 Digital Night Vision Binocular • 1 Shock-Proof Protec�ve Carrying Case • 1 32G Micro SD Card •...

  • Page 15: User Tips

    4. User Tips The le� figure indicates that the Micro SD card is not inserted. Please shut down before the card is inserted. 1. Correctly insert Micro SD card into the card slot and do not abruptly remove the card or ba�ery. (Before using the Micro SD card, format the card first to ensure that the card is not locked, and Follow the logo under the card slot to insert the card in the right orienta�on.

  • Page 16: Appendix

    5. Appendix FCC NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec�on against harmful interference in a residen�al installa�on. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc�ons, may cause harmful interference to radio communica�ons.
