- Page 1 User’s Manual DigitaLinx™ HDMI™ Coax Transmission System Part #: DL-HDCX...
-
Page 2: Table Of Contents
Table Of Contents Table Of Contents ....................2 Welcome and Safety Notes ................3 Product Description and General Specifications ........4-5 Environmental Reliability Specifications .............6 Features ........................7 Installation ......................8-9 Mechanical Specifications ................10 Technical Specifications .................. 11 Mounting Options ..................12-13 Warranty Information ..................14 Customer Service .................... -
Page 3: Welcome And Safety Notes
Welcome and Safety Notes Congratulations on your purchase of a DigitaLinx™ HDMI™ Coax Transmission System. This manual contains information that will assist you in the installation and operation of this product. Please inspect the contents of the package to ensure all required material is present. -
Page 4: Product Description And General Specifications
The system can easily accommodate DVI only inputs and outputs by using Liberty’s high quality HDMI to DVI interconnects. The DVI connector is routed to the sources and display unit while the HDMI connector plugs into the DigitaLinx™ HDMI™ Coax Transmission System. The digital audio signal is not transmitted when using DVI connectors. - Page 5 Product Description and General Specifications (Continued) This is a practical application chart with actual observed distances and performance in a real application. Longer distances can be achieved at lower resolutions. Higher resolutions and color depths will result in shorter distances. Some sources do not adhere to HDMI standards and may not be transmitted the full expected distance.
-
Page 6: Environmental Reliability Specifications
Environmental Reliability Specifications The DigitaLinx™ HDMI™ Coax Transmission System recommended environmental operating limits are a temperature range from 10°C to 40°C, non-condensing humidity levels from 10-80% and an altitude ceiling of 3,000 meters (9,840 feet). Environmental limits for transportation are established as a temperature range of -25°C to 60°C, non-condensing humidity levels from 5-95%, and an altitude ceiling... -
Page 7: Features
Features High Quality Picture – No Loss of Resolution or introduced Digital Artifacts Our HDMI™ Coax Transmission System is manufactured to deliver the highest quality picture by preserving the native resolution from the video sources and eliminating any digital artifacts (pixel loss or “sparklies”). Due to the nature of digital signals any non-active connector junctions will detrimentally affect the signal, this device provides active junctions to equalize and amplify the signal (boosting) and ensures the best signal quality to the display. -
Page 8: Installation
1.) Ensure the digital video/audio source and display is turned off. 2.) Connect the digital video/audio source to the input port of the DigitaLinx™ HDMI™ Coax Transmission System. 3.) Connect the digital display to the output port of the DigitaLinx™ HDMI™... - Page 9 TX and RX unit by separate DC power units. Extra Power units are sold separately under part number DL-HDCX-PS. In addition the power supply can be connected at either the TX or RX end of the system. If there are only 4 coax...
-
Page 10: Mechanical Specifications
Mechanical Specifications Dimensions: DL-HDCX: 2.20” x 4.40” x 0.65” (56 x 112 x 16.5 mm) (LxWxH) Power Supply Jack: Two pin Phoenix connector (not polarity specific) Liberty supplied power supply is 12 VAC 600mA. Unit can accommodate a wide range 10-32 VDC or 10-28 VAC from alternative power supplies. -
Page 11: Technical Specifications
Technical Specifications Frequency Bandwidth: 6.2 Gbps Supporting Graphic Resolution: 1080p /60 deep color, or equivalent computer resolution Transmitter Input HDMI Type A receptacle 1 port Output BNC Jack 5 ports Power 2 pin Phoenix style connector Receiver Input BNC Jack 5 ports Outputs: HDMI Type A receptacle 1 port Power... -
Page 12: Mounting Options
Mounting Options Powered rack mounts in 1, 2, and 3 RU heights are available for switching systems and HDMI distribution Part #: Family Height Capacity 6 single layer full, Basic Block, or ProSeries Bricks. 52-111-000 ProSeries Or 3 double layer ProSeries Bricks full or half size. 12 single layer full, Basic Block, or ProSeries Bricks. - Page 13 Mounting Options 3 RU Rack Mount Rear View A manufactured steel plate to provide lateral ears is another mounting option. Ears: 52-000-002 Brick Bracket Plate Plate, 2 Screws Mounting Options...
-
Page 14: Warranty Information
Warranty Information 1 (One) Year Warranty Liberty Wire & Cable warrants this DigitaLinx™ HDMI™ Coax Transmission System to be free from defects in workmanship and materials, under normal use and service, for a period of one (1) year from the date of purchase from Liberty Wire & Cable or its authorized resellers. -
Page 15: Customer Service
Troubleshooting The DigitaLinx™ HDMI™ Coax Transmission System is designed for years of trouble free service, please reference the troubleshooting steps below if you are having difficulties. Recommendation: Due to variations in the implementation of the HDMI standard by manufacturers of source and display equipment, it is highly recommended that any system be mocked up and tested with appropriate cable lengths prior to installation. - Page 16 © 2009 Liberty Wire & Cable. All Rights Reserved. Liberty Wire & Cable 11675 Ridgeline Drive Colorado Springs, CO 80921 800-530-8998 www.libertycable.com...
