- Page 1 ASSEMBLY INSTRUCTIONS PULL DOWN SCREEN SKU: NOV-29-001/NOV-29-002/NOV-29-003 NOV-29-004/NOV-29-005/NOV-29-006 2021 V1.0 IMPORTANT NOTICE THIS BOOKLET CONTAINS USEFUL INFORMATION ABOUT WARRANTY & CARE INSTRUCTIONS. PLEASE KEEP FOR FUTURE REFERENCE.
-
Page 2: Parts List
ASSEMBLY INSTRUCTIONS PARTS LIST Part Part Name Screen Housing Top Panel Right Side Panel Left Side Panel Screw Bolt Allen Key... -
Page 3: Safety Advice
Failure to do so can and will void your warranty. • Nova Outdoor Living holds no responsibility for any damages caused due to normal wear and tear, incorrect assembly, mis-use and/or negligence. • We reserve the right to make changes for product improvements. -
Page 4: You Will Need
ASSEMBLY INSTRUCTIONS ASSEMBLY YOU WILL NEED: Gloves Knife Hammer Tape measure Safety Hat Electric Screw Driver Ladder STEP 1 Position the Top Panel (B) between the pergola’s legs, clip over and then securely fasten with 6x screws (E). - Page 5 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 2 Clip the screen housing (A) to the top panel (B) and securely fasten with 4x screws (F).
- Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 3 Unscrew the 90° angled profile from right panel (C).
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 4 Position the 90° angled profile onto the vertical pergola leg ensuring it is positioned as illustrated. The angled profile needs to be aligned with the inner side of the pergola leg. Securely fasten with screws (E).
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 5 Unscrew the 90° angled profile from left panel (D).
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 6 Position the 90° angled profile onto the vertical pergola leg ensuring it is positioned as illustrated. The angled profile needs to be aligned with the inner side of the pergola leg. Securely fasten with screws (E).
- Page 10 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 7 Pull down the screen and slide the zippers attached to the canvas in to the plastic guide rail of part C and D respectively.
- Page 11 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 8 Once the screen is attached to the side panels (C & D), position vertically against the legs of the pergola.
- Page 12 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 9 Securely re-fasten side panels (C & D) to each of the 90° angled profiles.
- Page 13 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 10 Test your pull down screen by simply pulling the screen down and lifting it back up.
- Page 14 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 11 Enjoy your new pull down screen and pergola.
- Page 15 This material can be left outside all year round. 5 YEAR LIMITED EXTENDED WARRANTY ON ALUMINIUM FURNITURE Aluminium products from Nova are covered by a 5 year limited warranty. This warranty protects you from manufacturing faults / defects. This warranty applies to residential domestic use within the UK only.
