Operating Instructions
MIHM-VOGT Laboratory Furnace
with Controller P6
for
2
2
3
3
4
4
4
5
5
5
7
11
11
12
12
14
16
16
16
18
18
19
19
20
20
21
23
23
23
24
24
24
24
25
25
25
27
28
Advertisement
Table of Contents
Related Manuals for MIHM-VOGT KM
Summary of Contents for MIHM-VOGT KM
-
Page 1: Table Of Contents
9.2.5 How to replace the power element of the 2 heating circuit (only for furnace types BL, TL) 9.2.6 How to change the air circulation fan Warranty Circuit diagrams Index MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... -
Page 2: Delivery Form
- 2 - Dear customer, We thank you for your decision to buy a high-quality MIHM-VOGT furnace. It will support you with your work for many years, because it was developed and built using the latest technology. Improper use can cause damage, therefore we ask you to carefully read through this working instructions and to follow it. -
Page 3: Technical Data
Safety warning{ XE "Safety warning" } The MIHM-VOGT laboratory furnace is exclusively designed for the elimination of wax and for • the preheating of casting rings. We are not liable for damages due to another use. The sockets at rear are exclusively intended for the connection of a MIHM-VOGT fume extraction hood, a MIHM-VOGT exhaust blower, or a MIHM-VOGT catalyzer. -
Page 4: Installation And Electrical Connection
XE "Transportation protection" } is to be removed from the heating muffle. The laboratory furnaces type KM, SL and GL are to be connected to an earthed plug 230 V, the laboratory furnaces type BL and TL are to be connected to a CEKON plug 230/400 V AC. If necessary, the exhaust blower{ XE "Exhaust blower"... -
Page 5: Service Of The Controller
Program step keys{ XE "Program step keys" }{ XE "Key:S1 ... S4" }: to activate the cursor 6.3.2 Setting of individual programs { XE "Individual programs" }{ XE "Program:Individual" } MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... - Page 6 "Holding time" }. Steps 'S2' to 'S4' are programmed in the same way. If one step is not required, set all values in this line on '0'. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20...
-
Page 7: Examples Of Programming
'01'): Press the load program key{ XE "Load program key" }{ XE "Key:Load program" } and enter the program number '01'. Confirm by pressing 'S2' = 'yes'. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20 Time... - Page 8 Example of programming{ XE "Examples" }: Shock heat{ XE "Examples of programming:Shock heat" } Heating speed Temperature Holding time °C/min. °C Min. Step 4: Step 3: MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20...
- Page 9 'S2' = 'yes'. STORE PROGRAM Example of programming{ XE "Example" }: 3-step heating with cooling step{ XE "Examples of programming:3-step heating with cooling step" } MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20...
- Page 10 3.) Steps 'S2', 'S3' and 'S4' are set in the same way. 4.) The program is stored by pressing the memory key{ XE "Memory key" }{ XE "Key:Memory" and confirmed with 'S2' = 'yes'. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20...
-
Page 11: Setting Of Individual Text
After pressing the 'Start/Stop' key to start the process, the stand-by display appears. The line 'S4' now shows the word 'RUN' instead of 'STNDBY'{ XE "Process run" }. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... -
Page 12: Start Of A Program With The Delay Start Feature
} and then heats up to the new temperature set XE " " (850 °C). The final temperature may be changed as often as required. The original parameters of the program remain untouched. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... - Page 13 XE " " step which is recommended especially in case of shock-heat investments{ Shock-heat XE " investments }. Therefor the furnace is heated up as follows: " MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20...
-
Page 14: Continuous Operation Of The Rear Sockets In Case Of Shock-Heat Investments
This function may be deactivated by another pressure on the 'S4' key. Data is stored by pressing the 'S2' key = 'yes'. Pressing 'S1' = 'no' stops the menu, and the stand- by display appears again. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... - Page 15 Time °C/min °C 0 STNDBY 0 TEMP. 0 MO 12:13 0 MO 13:05 3.) After pressing the memory key MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20...
-
Page 16: Special Functions
An acoustic signal indicates the end of the program. If you do not want this acoustic signal in general, you may turn it off by pressing the 'S3' key. (The MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... - Page 17 1, Tuesday = 2 ... Sunday = 7. The current time is to be altered manually with the summer/winter time switch{ XE "Summer time" }{ XE "Winter time" }! Key 'S1': 'S1' is used to go on further: MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20...
-
Page 18: Correction Program
'S1' key switches on the air circulation fan for a fast cooling process (only possible in case of furnaces with integrated air circulation). DOOR OPEN TEMP. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... -
Page 19: "Controller:initialisation
}, order No. 73210) must be installed inside the pipe{ XE XE " " "Pipe" }. With this measure, the catalyzer's pipe may be extended up to approx. 3 - 5 m MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... -
Page 20: Error Signals
"Sensor" } Temperature inside the heating Open the door and wait until the muffle is significantly below room heating muffle has reached room temperature. temperature. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... -
Page 21: 8.2 Further Errors And Their Causes
No mains voltage. Check fuses in the circuit breaker box, Yellow pilot light of On/Off check connection management. Call switch is off. customer service if necessary. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... - Page 22 1050 ° C and held for activating the circuit breaker. approx. 3 hours. If this does not help, change the insulation and call customer service if necessary. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20...
-
Page 23: Maintenance And Care
It is unlikely that these limit values will be reached during servicing of the laboratory furnace. It is nevertheless recommended that respiratory masks type FFP2 are worn on a voluntary basis. MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... -
Page 24: How To Change The Thermocouple
Proceed accordingly in reverse order to put in the new front electronic unit. Do not mix up the thermocouple connections (red = „+“, white = „-“). MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... -
Page 25: Nd Heating Circuit
No. 1. Replaced parts will become the property of Mihm-Vogt. Guarantee claims are to be submitted with the invoice to a Mihm-Vogt specialist dealer who will carry out the repair. - Page 26 Mihm-Vogt specialist incorporation in the appliance of parts whose use has not been approved by Mihm-Vogt or which...
-
Page 27: Circuit Diagrams
- 27 - 9.4 Circuit diagrams{ XE "circuit diagram" } MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... -
Page 28: Index
Individual programs Correction program Individual text Cursor Information Start time Installation Delay start feature 11, 15 Delivery form Door filling 1 ... 9 Doorstone Casting time MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20... - Page 29 Use area Power element Process run Program Entering Voltage Individual Loading Start Storing Warranty Program '00' Program '99' Winter time Program number Program step keys Programming MIHM-VOGT GmbH & Co. KG, Dental-Gerätebau, Dunantstr. 7, D-76131 Karlsruhe, Tel.: +49/721/96174-0, Fax: +49/721/96174-20...
