HDMI Splitter via HDMI cable
Display one HDMI source up to 4 TVs
AB7815
EAN: 8716065328974
Packaging contents: AB7815, Power supply 5V A, Quick Install Guide

OVERVIEW

• 1 x 4 HDMI splitter, 3D and 4K support
• Display one HDMI source to multiple screens
• Maximum 4K resolution: 3840x2160 @ 30Hz
• Maximum (3D) resolution: 1080p @ 60Hz
• Compatible with HDMI High Speed (HDMI 1.4a)
• Power adapter included

SPECIFICATIONS

• Dimensions in mm. (WxHxD): 115x25x61
• Weight in grams: 211g
• Power consumption: 3W
• Power supply: 5V 1A
• HDMI input: 1 HDMI port
• HDMI out: 4 HDMI ports
• Maximum HDMI input/output cable length: 5M
• Supported resolutions 50/60hz compatible: 480i/576i/480P/576P/720P/1080i/1080P
• Supported 4K resolution: 3840x2160 @30Hz
• Supported 3D format: 1080p@30/60hz
• Audio Passthrough: DTS-HD MA, Dolby True-HD, Dolby Digital.
• HDMI standard: HDMI high speed
No rights may be derived from inaccurately presented content. Eminent cannot be held liable or responsible for inaccurately presented content.
1
©2016 EMINENT
