LC-42/46/52D85X
TV (Rear)
INPUT 3 terminals
INPUT 4 (HDMI)
terminal
Headphone jack
SERVICE ONLY
terminal*
* Usually do not connect anything to this terminal as
it is reserved only for service personnel.
Regarding the headphone jack
Use headphones with a stereo mini plug (Ø 3.5 mm).
Be sure to unplug headphones from the jack when they are not
in use.
The speakers do not output volume when headphones are
plugged in.
The "Audio" menu cannot be operated when headphones are
plugged in.
You can set the volume to different levels for each input source.
INPUT 2 terminals
INPUT 1 terminals
MONITOR OUT terminals
Antenna input terminal
Volume display when headphones are plugged in
2 – 2
RS-232C terminal
INPUT 5 (HDMI)
terminal
INPUT 6 (HDMI)
terminals
INPUT 7 (PC)
terminals
AC INPUT terminal
DIGITAL AUDIO
OUTPUT terminal
